Contact SupplierIndustrial Segment - High Precision Laboratary Weighing Balance , Heavy Duty Platform Weighing Machines, Ratio - Counting & Weighing Machines , Heavy - Duty Dormant Weighing Machines, Convertion of Mechanical Dormant in to Electro Mechanical With Intelligent Terminal Billing & Printing Machine optional ( Customized Solutions )
DescriptionVibrating steel yard, no loose weight, clear graduations on Stainless Steel inclined index plate, main poise on steel rollers cannot travel beyond zero. Steel notch protects bar. Notches accurately cut by special machinery. Tumbler locking device Minor poise slides on a rigid brass index bar.
The lever system enclosed in a strong cast iron frame is capable of withstanding loads for excess of rated capacity. The cast iron platform is mounted on ball bearing seated in beds on the stool to provide universal motion and avoid undue wear of the inter-changeable, hardened, steel knife edges & bearings which are easily replaceable when required.
Model | Platform Size | Strength | Capacity | Major | Minor |
---|---|---|---|---|---|
635 x 580mm | 375kg | 300kg | 300kg x 10kg | 10kg x 100gm | |
780 x 705mm | 750kg | 500kg | 500kg x 20kg | 20kg x 100gm | |
985 x 905mm | 1250kg | 1000kg | 1000kg x 50kg | 50kg x 200gm |
