| Model | Nominal Pressure (KN) | Length of Table (mm) | Distance Between Frames (mm) | Throat Depth (mm) | Stroke (mm) | Open Height (mm) | Main Motor( kW) | Overall Dimensions (L x W x H) |
| 63T/2500 | 630 | 2500 | 2050 | 250 | 100 | 320 | 5.5 | 2500 x 1300 x 2110 |
| 63T/3500 | 630 | 3200 | 2600 | 250 | 100 | 320 | 5.5 | 2500 x 1300 x 2110 |
| 80T/2500 | 800 | 2500 | 2050 | 300 | 100 | 320 | 7.5 | 2500 x 1400 x 2300 |
| 80T/3200 | 800 | 3200 | 2600 | 320 | 100 | 320 | 7.5 | 3200 x 1500 x 2300 |
| 80T/4000 | 800 | 4000 | 3200 | 320 | 100 | 350 | 7.5 | 4000 x 1500 x 2400 |
| 100T/2500 | 1000 | 2500 | 2050 | 320 | 120/150 | 320/350 | 7.5 | 2500 x 1600 x 2400 |
| 100T/3200 | 1000 | 3200 | 2600 | 320 | 120/150 | 370/400 | 7.5 | 3200 x 1600 x 2600 |
| 100T/4000 | 1000 | 4000 | 3200 | 320 | 120/150 | 370/400 | 7.5 | 4000 x 1600 x2700 |
| 125T/3200 | 1250 | 3200 | 2600 | 320 | 120/150 | 370/400 | 7.5 | 3200 x 1600 x 2600 |
| 125T/4000 | 1250 | 4000 | 3200 | 320 | 120/150 | 370/400 | 7.5 | 4000 x 1600 x 2700 |
| 160T/3200 | 1600 | 3200 | 2600 | 320 | 200 | 460 | 11 | 3200 x 1700 x 2700 |
| 160T/4000 | 1600 | 4000 | 3200 | 320 | 200 | 460 | 11 | 4000 x 1700 x 2800 |
