Contact SupplierOur organization assures distribution of wholesale as well as retail consignments of the goods as per the jointly decided period. We are a quality centric organization, offering the best-in-class products that are manufactured using the experts approved and certified raw material procured from reliable sources.
Gemini HR Cables :
Construction :
Main Features of Gemini Heat Resistant (105oC) Wires :
Application : HR wires are required when the operating temperature is on higher side
Cross Sectional Area of Conductor Sq. mm | No of Strand/ Dia of strand No./ (mm) | Nominal Insulation Thickness (mm) | Approx. Overall Diameter (mm) | Conductor Resistance at 20oC Max. ohms/km | Current Rating (Amp.) |
---|---|---|---|---|---|
0.05 | 16/0.2 | 0.6 | 2.4 | 39 | 5 |
0.75 | 24/0.2 | 0.6 | 2.6 | 26 | 8 |
1 | *14/0.3 or 32/0.2 | 0.6 | 2.7 | 18.1 | 13 |
1.5 | *22/0.3 or 48/0.2 | 0.6 | 3 | 12.1 | 17 |
2.5 | *36/0.3 or 80/0.2 | 0.7 | 3.6 | 7.41 | 24 |
4 | 56/0.3 | 0.8 | 4.3 | 4.95 | 31 |
6 | 84/0.3 | 0.8 | 5.1 | 3.3 | 40 |
