Contact SupplierOur Horizontal Boring Machine is precisely designed by our experienced technicians ensuring high degree of dimensional accuracy. Boring Machine that we offer is widely used in automobile, railway, engineering and many other industries. We provide machine that is corrosion and abrasion resistant. Our Horizontal Boring Machine is available in different sizes and technical specifications. We offer a highly durable Horizontal Boring Machine to our valued buyers.
StandardAccessories
Special Accessories
Unit | mm | mm | mm | mm | mm | mm | mm | mm |
---|---|---|---|---|---|---|---|---|
Alloy Steel work spindle hardened & ground-diameter | 80 | 100 | 110 | 100 | 110 | 125 | 130 | 150 |
Morse taper number | 5 | 6 | 6 | 6 | 6 | 6 | 6 | 6 |
Max. Longitudinal movements fo working spindle | 510 | 510 | 510 | 510 | 510 | 600 | 600 | 600 |
Number of spindle speeds | 9 | 9 | 9 | 9 | 9 | 9 | 9 | 9 |
Range of spindle speeds – R.P.M. | 15 to 300 | 15 to 300 | 15 to 250 | 15 to 250 | 15 to 250 | 15 to 250 | 15 to 250 | 15 to 250 |
Longitudinal work spindle Feeds nos. | 9 | 9 | 9 | 9 | 9 | 9 | 9 | 9 |
Max. Height of the spindle axis from table surface | 925 | 1000 | 1100 | 1000 | 1100 | 1200 | 1500 | 1800 |
Min. Height of the spindle axis from table surface | 25 | 30 | 30 | 30 | 30 | 30 | 30 | 30 |
Dimensions of the rotary table | 900 x 1105 | 1030 x 1375 | 1100 x 1450 | 1030 x 1375 | 1100x1450 | 1220x1675 | 1200x1675 | 1500x2000 |
Longitudinal table traverse | 1625 | 1775 | 1925 | 1775 | 1925 | 2050 | 2050 | 2950 |
=Long. Table traverse feeds (Including one rapid) | 10 | 10 | 10 | 10 | 10 | 10 | 10 | 10 |
Transvesal table travel feeds (Including one rapid) | 10 | 10 | 10 | 10 | 10 | 10 | 10 | 10 |
Vertical head stock travel feeds (including one rapid) | 10 | 10 | 10 | 4 | 4 | 10 | 10 | 10 |
Max. Cross movement of the table | 1000 | 1100 | 1300 | 2690 | 2800 | 2950 | 3200 | 3950 |
Max. Distance between stay bearing & facing head | 2400 | 2690 | 2800 | 555 | 600 | 650 | 650 | 700 |
Facing head diameter | 505 | 555 | 600 | 11500 | 13000 | 18000 | 19000 | 21000 |
Weight approx. In kgs. | 8500 | 9500 | 11000 | 9500 | 11000 | 16000 | 17000 | 19000 |
Rotary table automatic feeds (including one rapid) | 10 | 10 | 10 | 10 | 10 | 10 | 10 | 10 |
Max. Cross movement of the table | - | - | - | 1100 | 1300 | 1500 | 2000 | 2000 |
