Home Elevator

Listing ID #4171891

Schneider Lift designs and constructs one of the best residential elevators in the market, providing superior quality, expertise, and design that can be combined into new or existing architecture. The lift is a Simple yet an extremely powerful Vertical Transportation solution for your row house, Bungalow, Villa, Duplex Apartment or Pent House. This Elevator does not require a Machine Room for gearless type and is fitted inside the Lift Shaft and works at single phase current Supply. A little unit is required for pressure-driven type for containing the Hydraulic unit. The Elevator can be made for conveying limit of up to 300/500 Kilograms.
Apt for
Height: Up to 15 M
Travel Speeds:0.32 Mps / 0.50 Mps
Carrying Capacity: Up to 300/500 Kgs
Benefits:
Luxury cabin
Automated controls; commercial grade elements
Holeless design does not require digging for hydraulic cylinder
The sky range of home lifts from Schneider lift is a highly customizable and scalable offering from Schneider. Specially built for installation in homes these lifts are energy efficient and can operate on a simple single phase connection. The aesthetics and intricate beauty of these lifts augment the aura of any and all homes. Easy to use and easy to maintain, it is a great value addition embodying both elegance and high end technology.
This Design Guide is intended to assist architects, contractors, home owners and elevator professionals in planning for the sky Home Elevator installation. We strongly recommend that you contact our local Lift representative to discuss and become familiar with the code requirements in your area.
Types of Elevator
Hydraulic Drive System:
The hydraulic system offers premium ride quality, a sophisticated control system and quieter operation. A small area outside the elevator hoist-way is required to accommodate the controller and the hydraulic pump unit. This area can be adjacent to the elevator hoist-way or in a remote location. Another advantage to the hydraulic drive system is that manual lowering operations are much easier for those with limited strength or mobility. There is a manual lowering valve on the pump unit which allows the hydraulic fluid to drain from the cylinder, controlling the lowering of the cab in instances of power outages.
In-line Drive System:
The in-line drive elevator system offers a simple, economical solution. It is a geared direct drive electric motor. No machine room is required, making this a popular choice where space is a prime consideration. All of the drive components, including the controller box, can be mounted within the hoist-way. However, it is recommended that the controller, which can be located up to 50 feet away, be located outside of the hoist-way for easier service access. Manual lowering is accomplished either by use of the standard manual lowering hand wheel, or by use of the optional battery powered lowering. Another advantage of the in-line drive is that no hydraulic fluid is required and therefore there is no chance of a toxic leak.
