Contact SupplierTablet Press- TabXpress-PUV
High Speed Single Sided Central Drive & Pre-Compression Tablet Press GMP Model
Application & Process :
TabXpress-PUV Tablet Press Machine is used for production of simple and precise tablets from powder in Pharmaceutical and relevant Industries.
The TabXpress-PUV is high speed single sided central drive pre-compression rotary tablet presses is suitable for medium size batch production with uniform tablet size and weight. The PUV-20/27/30 designed in an effort to exceed the cGMP requirements and ensure the most economical and efficient tablet production. The TabXpress-PUV features a unique ergonomics design for easy to operate, easy to fast change over, easy to clean with minimum down time.
The Machine Ergonomics Design Concept :
The TabXpress-PUV has been completely new designed according to the most modern ergonomic aspects.
Salient Features :
Optional Features :
Safety Features :
Technical Specification :
Model | TabXpress PUV- 20 | TabXpress PUV- 27 | TabXpress PUV -30 |
No. of Station | 20 | 27 | 30 |
Type of Tooling | D | B | BB |
Output-tablets per Hour | 29,000 to 72,000 | 39,000 to 97,000 | 43,000 to 108,000 |
Max. Operating Pressure-Main | 100 kN | 65 kN | 65 kN |
Max. Operating Pressure- Pre-Press | 10 kN | 10 kN | 10 kN |
Max. Tablet Diameter | 25 mm | 16 mm | 11 mm |
Depth of Fill | 20.5 mm | 17.5 mm | 17.5 mm |
Upper punch penetration | 3 to 6 mm | 3 to 6 mm | 3 to 6 mm |
Total Power consumption | 6.25 HP / 4.7 kW | 6.25 HP / 4.7 kW | 6.25 HP / 4.7 kW |
