Contact SupplierTechnical Specifications
Sr.No. Discription Model-AHDLM-1 Model-AHDLM-1 Model-AHDLM-1 Model-AHDLM-1 Model-AHDLM-1
1 Size length of Bed 1675(5’-6”) 2135(7’-0”) 2745(9’-0”) 3048(10’-0”) 3660(12’-0”)
2 Width Of Bed 324 324 324 324 324
3 Height of Centre 254 254 254 254 254
4 Swing Over Bed 455 455 455 455 455
5 Swing Over Cross slide 255 255 255 255 255
6 Swing in Gap 725 725 725 725 725
7 Admit Beween Centre 555 535 990 1600 2500
8 Spindle Bore 54 54 54 54 54
9 Aprox Weight 1200KG 1300KG 1400KG 1600KG 1800KG
10 Tail stock taper MT-4 MT-4 MT-4 MT-4 MT-4
11 Tail Stock Ram Travel 175 175 175 175 175
12 Lead Screw Dia. 38 38 38 38 38
13 Lead Screw Thread 4TPI 4TPI 4TPI 4TPI 4TPI
14 No. Of Spidle Speed 8/30 TO 495 RPM
15 Range of Thread 1 To 6MM/ 2 To 24 TPI
16 Electric Motor Speed 2HP/1440RPM 2HP/1440RPM/75MM Motor Pully 3Hp/1440 RPM 3HP/1440RPM
Standard Accessories:
1.Chuck Plate
2.Face Plate
3.Chaingear Set(inch & MM)
4.Sleady Rest
5.Tool Post Key
6. 2 Nos. Dedcenter
7. 1 No.Sleeve and Motor Pully
