Hard Narrow Web Embossing Machine 2, Certification : ISO 9001:2008 Certified

Listing ID #7455692

Narrow web hard hologram embosser is designed for producing 160MM width hologram products, such as hologram labels, narrow web hologram film, hologram aluminum foil, etc.

Specifications:

• Max embossing dimension: 160*156MM/sheet
• Embossed film thickness: 0.012MM-0.12MM
• Max rewind & unwind rolls diameter: 500MM
• Temperature scope: 0-180¡æ(Adjustable)
• Embossing speed: 0M-30M/Min(Adjustable)
• Counter scope: 0-99999 (Adjustable)
• Shim size:< 160*156*0.05 MM
• Shim lift: 5,000M-10,000M/Shim
• Voltage std.: 220V 50HZ
• Power consumption: 3KW
• Compressed air needed: 0-5Kg/cm2 (Adjustable)
• Embosser dimension: 1300MM*750MM*120MM
• Embosser weight: 250KG
