Contact SupplierDesigned for smaller milling machines.
Table diameter 100 mm
table is graduated 360 degrees.
Worm gear ratio -1:36, which means that the 1 handle rotation shall turn the table by 10 degrees.
Center height in vertical position: 2-116" (50 mm approx)
hand wheel is graduated in divisions of 10 min & can be set to zero.
Can be mounted both in horizontal & vertical position.
​specifications of round vice:-
made of high grade close grain caste iron.
Designed to fit our 4" (100 mm) rotary tables perfectly.
The moving jaw has v-grooves to hold round objects.
again these vices are drilled in a manner that these can fit to a 3 as well 4 slot table.
The drills are counter bored to ensure that the fixing screws sets perfectly ensure perfect movement.
prod. Code dia. Of base jaw width jaw depth jaw opening height
amrrv-105 105 mm 77 mm 21 mm 40 mm 32 mm
