Design Standard :   BS-1873
Face To Face Dimensions :   ANSI B 16.10/BS-2080/DIN 3300
Size Range :   15mm to 500 mm.
Pressure Rating :  150/300/600/900/1500/2500 class and ND-10, ND-16, ND-25, ND-40, ND-64.

• From bar stock in carbon steel or stainless steel (304, 316, 304L, 316L. 321)
  Hastalloy B & C & Alloy 20 for sizes 15 mm to 50 mm.
• Castings in carbon steel to ASTM A 216 Gr. WCB, WCC, LCB, LCC.
• Casting in stainless steel to ASTM A 351 Gr. CF 8/CF 8M/CF 8C/CF 3/CF 3M Alloy 20.
  Hastalloy B & C.
• Castings in C.I. to I.S. 210 G.R.20.
• Castings in Alloy Steel to ASTM A 217 C5, WC6, WC9, WC12.

• Screwed to BSP/BSPT/NPT flanged to ANSI, DIN or BS standards. Socket weld to ANSI B 16.11. Butt-weld to ANSI B 16.25.

• Outside screw rising stem rising hand wheel construction threads are away from fluids and easy to lubricate.
• Body and bonnet made from high quality casting with liberal sections.
• Seat ring screwed into the body are replaceable.
• Back seat ring features facilitate repacking of the stuffing box on line with valve in fully open position.
• Swinging eye bolts facilitate easy access to the stuffing box.
• Plug type disc designed to give leak tight seatring over a long period of in built wear life.
• Stellite seat ring and disc can also be offered on special request.
• The valves of higher pressure and bigger sizes are provided with thrust bearings and also with gear drive arrangements and flange also can be offered for different standards.
