Contact SupplierMax. Workpiece diameter 350mm
Min. Workpiece diameter 20mm
Tooth width 150mm
Max. module 8
Min. module 1
Table travel longitudinal150mm
Table travel cross 10mm
Vertical adjustment of table 175mm
Swivel range horizontal 0 - 180
Shaving cutter diameter 174 - 260 mm
Shaving wheel spindle turning speeds 45 - 385 Umin
Shaving Cutter drive motor 3KW
Feeds of table 6 - 285 mmmin
Min. workpiece diameter 20mm
Electrics 38050 VHz
Total power requirement 12KW
Weight of the machine ca.5.60T
