Maximum high pressure 100 to 150 ton
total required of power 28 hp
facility two feeder facilitates for production of fly ash bricks & paver block.
Accessories two rollers pan-mixer, panel board, conveyer belt, power pack, fully sensor type machine, trolley, tool box.
Electric power 10 hp
main press 7.5 + 7.5 = 15 hp
pan mixer-2 nos 2 hp
conveyer 1 hp
vibrator 28 hp
man power 1 skilled 9 unskilled 10 persons
approx production 10 bricks in a stocked bricks size
230x100x75mm 17,000 to 19,000 bricks 8 hr.
3 solid block in a stocked solid block size
300x200x150mm 4,000 to 4,500 solid block 8 hr.
4 paver block in a stocked paver block size
60, 80, 100mm 4,500 to 5,000 paver block 8 hr.
Oil tank (power pack) 68 no. Hydraulic oil 425 ltr.
Wooden pallets 22" x 30" (inch) thickness 18 mm -
shed 50 x 35 ft
height 16 ft
area required 10,000 to 15,000 square ft.
Note: engineering drawing for civil work and shed for the machine installation.
