PARTH AT A GLANCE
BALL VALVE-FLANGE END & SCREW END
Size: ½” to 8”
The on/off function accomplished by means of a flow controlling ball located in the centre of the valve body and placed between two teflon valve seats which serve as a "bubble tight" seal off.
TECHNICAL DATA:
Construction: 3 piece design, Single piece stem (Spindle) Reinforced Ball, Teflon seated, full bore.
Design and manufacturing std.: As per Manufacturer's Standard
End Connections : Flanged as per ANSI B 16.5 (150 #) & as per BS 10 (Table D/E/F) & DIN STD
ENGINEERING OPTIONS:
1. S.S. 304/316 Parts can be supplied
2. Glass-filled PP/PTFE BALL on request
AVAILABLE M.O.C.:
PP (POLYPROPYLENE)
HDPE (HIGH DENSITY POLYETHYLENE)
ISOTACTIC PP
PVDF (POLYVINYLIDENE FLUORIDE)
DIAPHRAGM VALVE-FLANGE END & SCREW END
Size: ½” to 4”
Diaphragm valves utilise a movable elastomeric membrane on "diaphragm" to constrict the flow.
TECHNICAL DATA:
Construction: Weir type design, Soft seated, Raising stem
Design and manufacturing std.: As per Manufacturer's Standard
End Connections: Flanged as per ANSI B 16.5 (150 #) as per BS 10 (Table D/E/F) & DIN STD
ENGINEERING OPTIONS:
1. S.S. 304/316 Parts can be supplied
2. Teflon coated Rubber, EPDM Rubber, Viton Rubber on request
AVAILABLE M.O.C.:
PP (POLYPROPYLENE)
HDPE (HIGH DENSITY POLYETHYLENE)
ISOTACTIC PP
PVDF (POLYVINYLIDENE FLUORIDE)
NON RETURN VALVE-FLANGE END & SCREW END
Size: 1” to 8”
Non-return valves are widely choosen for heavy duty use in Industries, Chemical, Turf and Irrigation application. As the name indicates, valves are used for one way flow.
TECHNICAL DATA:
Construction: Ball type design, Soft seated
Design and manufacturing std.: As per Manufacturer's Standard
End Connections: Flanged as per ANSI B 16.5 (150 #) as per BS 10 (Table D/E/F) & DIN STD.
ENGINEERING OPTIONS:
1. Teflon coated Rubber, EPDM Rubber, Viton Rubber on request
AVAILABLE M.O.C.:
PP (POLYPROPYLENE)
HDPE (HIGH DENSITY POLYETHYLENE)
ISOTACTIC PP
PVDF (POLYVINYLIDENE FLUORIDE)
Size: 1” to 4”
FOOT VALVE-FLANGE END & SCREW END
Size: 1” to 8”
Foot valves are generally places at the inlet of the suctions pipe of centrifugal pump to prevent priming at the suction pipe.
TECHNICAL DATA:
Construction: Ball type design, Soft seated
Design and manufacturing std.: As per Manufacturer's Standard
End Connections: Flanged as per ANSI B 16.5 (150 #) as per BS 10 (Table D/E/F) & DIN STD.
ENGINEERING OPTIONS:
1. Teflon coated Rubber, EPDM Rubber, Viton Rubber on request
AVAILABLE M.O.C.:
PP (POLYPROPYLENE)
HDPE (HIGH DENSITY POLYETHYLENE)
ISOTACTIC PP
PVDF (POLYVINYLIDENE FLUORIDE)
Size: 1” to 4”
BUTTERFLY VALVE-FLANGE END
Size: 4” to 12”
Design and manufacturing std.: As per Manufacturer's Standard
TECHNICAL DATA:
Construction: 1 piece.
End Connections: Flanged as per ASA 150.
ENGINEERING OPTIONS: 1. Liner EPDM, Nitrile, Vitron, Neoprene stem- SS 316.
AVAILABLE M.O.C.:
PP (POLYPROPYLENE)
ISOTACTIC PP
PVDF (POLYVINYLIDENE FLUORIDE)
‘Y’ TYPE STRAINER-FLANGE END & SCREW END
Size: ½” to 4”
Design and manufacturing std.: As per Manufacturer's Standard
End Connections:
Flanged as per ANSI B 16.5 (1:50#) as per BS 10 (Table D/E/F) & DIN STD.
ENGINEERING OPTIONS:
1. Screen 60 Mesh, 80 Mesh, 100 Mesh, J20 Mesh or special design PP screen.
2. Rubber GasketTefion Coated, EPDMHubber.
AVAILABLE M.O.C.:
PP (POLYPROPYLENE)
Size: ½” to 4”
FLOW INDICATOR-FLANGE END
Size: 1” to 6”
Sight glasses are commonly used for inspection of fluid Passing through particular assembly.
TECHNICAL DATA:
Construction: 3 piece Design, Full Bore, Borosil Glass, Teflon Seated
Design and manufacturing std.: As per Manufacturer's Standard
End Connections: Flanged as per ANSI B 16.5 (150 #) as per BS 10 (Table D/E/F) & DIN STD.
ENGINEERING OPTIONS:
1. S.S. 304/316 Parts can be supplied
2. Glass length as per your request
AVAILABLE M.O.C.:
PP (POLYPROPYLENE)
HDPE (HIGH DENSITY POLYETHYLENE)
ISOTACTIC PP
PVDF (POLYVINYLIDENE FLUORIDE)
Corrosion is the major problem that every industry now a days facing a lot. Many chemicals aggressively corrode most metal equipments resulting in process leaks, flow restrictions and it decreases the life of a plant
Parth Plastic Industries was started with vision of providing a permanent solution to corrosion problems with high quality reliable products that perfectly match with industry standards.
Parth Plastic Industries an ISO 9001:2000 company been in operation since 1991 manufacturing products like Polypropylene, High density Polyethylene, Isotactic PP, and Poly Vinylidene Fluoride (PVDF) Ball Valve, Diaphragm Valves, Non-return Valves, Foot Valves, Flow Indicators and PP, HDPE Y-type Strainers and pipe fittings.
The company is also involve in manufacturing of specially engineered products like Trays used in Tray Dryers, Scrapers, Shovels, Spades, Scoops that could be employed by the chemical process industry to handle corrosive materials.
Features of PP/HDPE/ISOPP/PVDF Valves:
Corrosion Resistance: 'Parth' valves & fittings are ideally suitable for aggressive and non-aggressive chemicals, acids, alkalies, salt etc.
Sturdy construction: Valve body can withstand pressure upto 15 kg/cm2. Handle, Spindle are PP moulded with metal inserted for sturdiness and long life.
Temperature: HDPE valve withstand temperature up to 70ºC, PP valves upto 90ºC, Isotactic PP valves upto 100 ºC and PVDF valves upto 170 ºC for continuous use.
Easy to operate: PP valves are easy to operate with low maintenance and gives tight sealing with low torque.
Economical: PP/HDPE/ISOPP/PVDF valves are more economical than GI, SS or CS valves.
Light weight: Due to light weight valves are easy to handle and to install.
