Contact SupplierKey Features:
1.Configurable measuring range
2.Configurable parameters via LCD Display, keypad
3.Integrated operating pressure measurement up to 40 bar
4.Suitable for non-corrosive gaseous media and vapour
5.Corrosion resistant field housing
6.Oil and grease free for oxygen applications
Key Specifications:
1.Measuring range: 0 ~ 160 mbar to 0 ~ 2.5 bar
2.Maximum static pressure: 40 bar
3.Design: Differential pressure measurement, with or without integrated operating pressure measurement (25 bar or 40 bar)
4.Electrical output: differential pressure & operating pressure — 4-20mA 2-wire connection
5.Maximum pressure load: one-sided overpressure-proof up to the rated pressure of the measuring system, resistance to under-pressure on the (+) and (-) side
6.Linearity:
7.Ambient temperature: -20 °C to +70 °C
8.Admissible media temperature: -20 °C to +70 °C
9.Characteristic curve: linear
10.Pressure connection: inner thread G 1/4 cutting ring screw connection for 8 or 10 mm pipe
11.Measuring membrane: 1.4305 NiBe for differential; Al2O3 for operating pressure
12.Protection: IP65 as per EN 60529, with integrated ceramic sensor
Application areas:
1.Filter condition monitoring
2.Flow measurement and control
3.Pump Control
