Operation:
This system consists of a closed circuit manufacturing facility from feeding of Sugar / Water Phase to loading the Volumetric Liquid Filling Machine to prepare Sugar solution.
With....
This system consists of a closed circuit manufacturing facility from feeding of Sugar / Water Phase to loading the Volumetric Liquid Filling Machine to prepare Sugar solution.
With vacuum system or mechanical system or manually the Sugar and Water, are loaded.
The Sugar Syrup Vessel is supplied with high speed stirrer.
Electrical heating (In small model)
Steam heating facility (In bigger size model) .
The sugar   syrup is prepared at required temperature & is transferred to Manufacturing Vessel by vacuum or by transfer pump.
The product during emulsion formation is re-circulated through In-Line Homogenizer / Liquid Transfer Pump.
The Pump also discharges the product in the Storage Vessel.
The Storage Vessel is then taken to the filling area ( if it is small capacity ) and is connected to again Liquid Transfer Pump. Or Storage Vessel remain fixed (Â In bigger size ) & pump transfer the Liquids in the float tank which is connected with filling machine.
The entire Plant can be operated by centralized operating panel by one operator
The plant is equipped with an electrical control panel with digital   temperature indicators / controllers and digital timers.
Minimum two batches per shift of the same product can be assured in this plant.
This plant conforms to cGMP standards (Paint Free Construction).
Â
The Salient Features:
It is possible to operate the Plant by one operator and one helper.
All material transfers are done by vacuum or by transfer pumps.
All cGMP vessels (paint free construction)
Silicon (food grade) gaskets are used.
The entry of stirrer & high speed emulsifier can be from top or from bottom (as per customer requirement) or In-line Emulsifier.
All vessels can be sterilized due to internal pressure of 1 Kg. / Sq. cm.
Customer can use CIP & SIP facilities of CIP & SIP connections equipped  in the entire plant
The control panel indicates all values of temperature & time of the plant digitally. Ampere is indicated on Ampere meters.
Tri clover joints are given with all the inlet & outlet connections which are very easy for cleaning & replacement.
All contact parts are of SS 304 / SS 316 (SS316 - L / as per customers requirements.)
All pipes, pipe fittings and valves are of SS304 / SS316 ( as per customer requirement ), internally electro polished, with tri-clover ended joints.
A micro processor based automatic operating plant can be designed ( as per customer requirement ).
