Contact SupplierSTAND | C shaped, corrosion resistant, Anti Fungus treated, single mould modular stand |
---|---|
NOSEPIECE | Quintuple, Reversed (Inward Tilt) nosepiece, with rubber grip |
VIEWING BODIES | 30. Inclined Siedentopf Binocular / Trinocular tubes, 360. rotatable, IPD 55-75 mm with dioptric adjustment |
MECHANICAL STAGE | Double Plate 180mmx148mm. X-YÃ� travel 76mmx50mm, spring clip Double Slide holder |
CONDENSOR | Movable ABBE condenser, with aspheric lens NA 1.25 & daylight blue filter. Centrable |
FOCUSING SYSTEM | Ergonomic low position co-axial coarse and fine focusing system on ball bearing guideways. Tension adjustment ring and unique Focus lock provided |
ILLUMINATION | Koehler Illumination, 6V 20W Halogen Lamp, Universal Power SupplyÃ� 100 V to 240 V, ACÃ� 50-60Ã� Hertz,Ã� CE Compliant. Optional 6V 30W Halogen Lamp |
EYEPIECES | WF 10X/22mm with Eye-guards. Optional WF 10X/18mm, WF 15x/16mm, WF 20x/12mm |
OBJECTIVES | Infinity Objectives, Semi Plan / Full Plan / Phase Plan Achromats |
EXR 300 - SI Semi Plan | 4x/NA 0.10, 10x/NA 0.25, 40x/NA 0.65 SL, 100x/NA 1.25 SL, Oil |
EXR 310 - PI Plan | 10x/NA 0.25, 20x/ NA 0.40, 40x/NA 0.65 SL, 100x/NA 1.25 SL, Oil Optional for SI Series & PI Series: 2.5x/NA 0.08, 20x/ NA 0.40 SL, 60x/NA 0.85 4x/NA 0.10, 10x/NA 0.25, 40x/NA 0.65 SL, 100x/NA 1.25 SL, Oil |
EXR 310 - PIP Phase Plan | 10x/NA 0.25, 20x/ NA 0.40, 40x/NA 0.65 SL, 100x/NA 1.25 SL, Oil Optional for SI Series & PI Series: 2.5x/NA 0.08, 20x/ NA 0.40 SL, 60x/NA 0.85 SL |
OPTIONAL ACCESSORIES | Dual viewing attachment, Flip Top Condenser, Phase Contrast Kit, Dark Field Kit, Fluorescence attachment, Green filter, Polarizing kit, Video adapter, Photo adapters for 35mm SLR camera, CCD Camera and Digital Still Camera, 10x Photo eyepiece |
OPTICAL SYSTEM | Infinity Optical System (IOS) |
