Contact SupplierWe are a renowned and customer centric firm, which is engaged in delivering a comprehensive range of Electronic Universal Testing Machine. It is equipped with electronic digital display for load and elongation.
Technical Specifications:
1st Measuring Range : 0-80 KN
Load Resolution : 0.02 KN
2nd Measuring Range : 0-160 KN
Load Resolution: 0.04 KN
3rd Measuring Range: 0-400 KN
Load Resolution: 0.1 KN
Resolution of Piston Movement (Displacement): 0.1 mm
Clearance for tesile at fully descended working piston : 50-700 mm
Clearance for compression test at fully descended working piston : 0-800 mm
Clearance between columns: 500 mm
Straining / Piston speeds (at no load): 0-150 mm
CONNECTED LOAD
HP @ (Voltage: 440 V, Phase: 3, Hz : 50 ) : 2.3
Standard Accessories:
For tension test:
Clamping for round: 10-25 mm
Specimens diameters : 25-40 mm
Clamping jaws for flat: 0-15 mm
specimens thickness: 15-30 mm
Width : 65 mm
For compression test:
Pair of compression plates of diameter: 120 mm
For transverse test:
Table with adjustable rollers width of rollers: 160 mm
Diameter of Rollers: 30
Maximum clearance between Supports: 500 mm
Radius of Punch tops: 12,16 mm
