We share a forefront with the famed organizations, supplying superior quality Shaperl Machine at affordable rates. Delivering orders within the promised time is our forte as we are supported by wide distribution network and fastest transportation facilities.
| Model No | SSM 24 | SSM 30 | SSM 36 | SSM 40 |
|---|---|---|---|---|
| Length of ram stroke | 660 | 800 | 930 | 1025 |
| Length of ram | 1225 | 1600 | 1750 | 1900 |
| Width of ram | 300 | 300 | 300 | 330 |
| Max. Distance from table to ram | 450 | 520 | 560 | 600 |
| Min. Distance from table to ram | 50 | 50 | 60 | 60 |
| Vertical travel of tool slide | 140 | 160 | 185 | 200 |
| Swiveling range of tool on either side | 60 degree | 60 degree | 60 degree | 60 degree |
| Table size | 610 * 380 | 760 * 400 | 900 * 450 | 1015*508 |
| Horizontal travel of Table | 600 | 700 | 810 | 940 |
| Vertical travel of Table | 350 | 430 | 500 | 550 |
| Nos. of speeds | 4 | 4 | 4 | 4 |
