Durable Use Bitzer Compressor

Listing ID #4121639

  • 14. Evaporator structureSpiral groove
  • 19. Water feeding pressure0.1Mpa-0.5Mpa
  • 2. Refrigeration capacity15.59kW
  • 1. Daily capacity3000kg/24hrs
  • Supply Type Manufacturer, Exporter, Supplier
  • Preferred Buyer Location All over the world
View More Details
Send Enquiry

Company Information

  • Member Since 19 Years
  • Nature of Business Retailer
  • Year of Establishment 1972

Ask for more detail from the seller

Contact Supplier

Product Details no_img_icon

  • 12. Rated current 22.5A
  • 1. Daily capacity 3000kg/24hrs
  • 23. Noise(in 2M) 72dBA
  • 15. Evaporating temp. -20℃
  • 25. Outsize 1700*1470*1240 (mm)
  • 8. Power of circulating water pump 0.12kW
  • 21. Design ambient temp. 25℃
  • 24. Unit weight 800kg
  • 5. Input power of compressor 9.92kW
  • 22. Design water inlet temp. 18℃
  • 17. Flake ice temp. -5℃
  • 3. Refrigerant R404a
  • 19. Water feeding pressure 0.1Mpa-0.5Mpa
  • 18. Thickness of flake ice 1.5mm-2.2mm
  • 4. Installed power 11.346kW
  • 13. Cooling way Air cooling
  • 10. Power of salt water pump 0.016kW
  • 16. Condensing temp. 40℃
  • 7. Power of reducer 0.37kW
  • 11. Supply power 380V/3P/50Hz
  • 2. Refrigeration capacity 15.59kW
  • 20. Water diameter 5/8"
  • 6. Motor power of cooling fan 0.92kW
  • 14. Evaporator structure Spiral groove

Snowell Hot Sale Duralble Use Bitzer Compressor 3 Tons/day Flake Ice Maker Machine for Freezing Fish



Remark: the ambient temperature range is from 5℃ to 50℃.
Technical data maybe improved without further notice.



Our Advantages:

1. There are three refrigerant options:
R507,R404A,and R22.

2. Safety and Sanitation
We adopt stainless steel, pure aluminium alloy, and special treatment to prevent corrosion and make sure the ice flakes are clear and safe.these ice flakes are spread used in fishing industry,concrete cooling,bakery cooling and so on.And anti-corrosion also extend the 3t ice flake machine's service time.

3. High relaibility and low breakdown rate
We adopt the newest ice machine making technology in the world and use world famous components like Bitzer, Danfoss etc to ensure the products quality is the best.and the structure is designed for resisting to high load and long timeuse,according to our test,our ice machine can produce quality ice and stand over 30000 hours of constant operation without breakdown.

4. High efficiency and energy saving
We optimize the internally-scraping evaporator to make the ice falling reach 100%, which make the heat-exchang moreefficient than others. Meanwhile, we use special kind of alloy material and patente processing technology to improve thethermal conductivity. Be equal with the same capacity compressor, our 3tons flake ice machine can produce more ice than other brand.it enlarge customer's profit and reduce user's ice making cost.

5. Sample installment,operation and maintenance
Snowell ice making machine is designed on the basis of modules, so its installment,operation and maintenance is quitesample. User just need to connect the system with water and power, press the button,ice comes out. While you plan toreplace the parts, you just need to take down the old and install the new.and our ice flake machines are designed to easy to move from one place to another.

6. Great adaptability and stable quality
Snowell Flake Ice Maker normal working temperature is 5℃~40℃,the special designed type can work in -30℃~60℃
