Construction
Heavy fabricated outer body is metallic painted with clear coating for longer life, large sized die pressed powder coated door for easy loading, The machines are epoxy coated inside for rust prevention.
Drying Chamber
Thermally insulated stainless steel basket, double walled prevent heat loss & maintain uniform temp. Drive Balanced cast iron pulleys & flexible plumber block housing with double ball bearing to sustain all loads.
Suction
Moisture evacuation is through balanced centrifugal high suction blower directly mounted on motor for silent operation.
Lint Screen
Sliding lint screen is provided in the front panel for easier operation.
Steam / Electric Radiator
Copper coils with aluminium fins for steam heated and fin type elements for electric heated are provided with sliding mesh to prevent dust on radiator.
Diesel / PNG Operated
The most economical & automatic operating system, Diesel / PNG burner is fitted in a heat exchanger made of numerous seamless pipes for quick air heating with sliding mesh.
Capacities
The Drying Tumbler comes in four capacities
| Drying Tumbler | Basket Size mm | Volume It | Power Required | Air Delivery ft3 / hr | Air outlet dia mm | Door Opening dia mm | Heating | Dimensions mm | Net Wt Kg | ||||
| Model | Kg | Drive Motor | Suction Motor | Steam Consumption | Electric | Diesel Fired | |||||||
| BT 15 | 15 | 800x460 | 231 | 1.0 hp | 1.0 hp | 1500 | 200 | 450 | 20 kg/hr | 09 kw | 1.25 It/hr | 950x1120x1750 | 340 |
| BT 30 | 30 | 950x950 | 670 | 1.0 hp | 1.0 hp | 1500 | 200 | 600 | 30 kg/hr | 12 kw | 1.50 It/hr | 1150x1500x1850 | 580 |
| BT 60 | 60 | 1250x970 | 1190 | 2.0 hp | 2.0 hp | 3000 | 200 | 600 | 60 kg/hr | 24 kw | 3.00 It/hr | 1350x1780x2300 | 940 |
| BT 120 | 120 | 1600x1200 | 2411 | 3.0 hp | 2 x 2.0 hp | 6000 | 200 | 800 | 120 kg/hr | NA | 5.50 It/hr | 1750x2100x2700 | 2010 |
