| Working Surface Size (Length x Width) | mm | 1500*1250 |
| Distance From Spindle Center to Column | mm | 400+100=500 |
| Guideway Type | Â | Linear |
| X-axis Travel | mm | 1250 |
| Y-axis Travel | mm | 1500 |
| Z-axis Travel | mm | 500 |
| Positioning Accuracy (JIS B6330) | mm | 0.010 |
| Repeatability Accuracy (JIS B6330) | mm | 0.005 |
| Positioning Accuracy (VDI 3441, 5 times) | mm | 0.020 |
| Repeatability Accurac (VDI 3441, 5 times) | mm | 0.010 |
| X/Y/Z Axes Motors | KW | 2/2/2 |
| Spindle Speed (Belt Driven) | RPM | 8000 |
| Spindle Nose Taper | - | BT40 |
| Spindle Motor Power | kw | 7.5/11.5 |
| Cutting Feed Rate (X, Y, Z) | mm / dk | 15/15/15 |
| Rapid traverse (X, Y, Z) | mm / dk | 20/20/20 |
| Tool Number | adet | 20(Umbrella Type) |
| Max. Tool Weight | kg | 7 |
| Max. Tool Size (Diameter and Length) | mm | 75x250 |
| Pull stud bolt | Â | P40T-1 |
| MITSUBISHI/SIEMENS | Â | M80,828D |
| Required air pressure | kg / cm2 | 6.5 |
| Electric Power Consumption | KVA | 30 |
| Machine Weight | kg | 10000 |
| Machine Floor Space | mm | 4500x3100 |
