Digital Micro Vickers Hardness Tester

Listing ID #4289652

Get Latest Price

Min. Measuring Unit0.25 μm
Light SourceLED Cold light source (can be continuous use for 24 hours, life 100,000 hours) Power Supply: 110V/22
X-Y Testing TableDim.:100×100 mm
Switch Type of Objective lens and IndenterManual Turret
Supply Type Exporter, Supplier
Preferred Buyer Location All over the world

View More Details

Send Enquiry

Product Details

Testing Force 10 g, 25 g, 50 g, 100 g, 200 g, 300 g, 500 g, 1000 g
Light Source LED Cold light source (can be continuous use for 24 hours, life 100,000 hours) Power Supply: 110V/22
Executed Standard GB / T4340.2 Chinese Standard, JJG151 Inspection Rules
Data Output Built-in Printer Hardness Value, The Max. And Min. Value, Testing times and Average Value) Built-in
Hardness Value of Reading Digital LCD Screen
Scale HV0.01, HV0.025, HV0.05, HV0.1, HV0.2, HV0.3, HV0.5, HV1, HV2
Switch Type of Objective lens and Indenter Manual Turret
Min. Measuring Unit 0.25 μm
Dwell time 1-99s
Loading Method Automatically Load, dwell and unload the testing force
Max. Travel Range 25×25mm Moving Resolution Ratio 0.01mm (X-Y Digital Testing Table with digital LCD Screen for Option
Instrument size 490 × 185 × 515 mm L × W × H
Throat Depth 120 mm
X-Y Testing Table Dim.:100×100 mm
Instrument weight 45kg
Specimen Allowing Maximum Height 85 mm
Total Magnification of Microscope 100X For Observation 400X (For Measurement)
Hardness Value Rang 1 HV - 4000 HV

Features :

The independent research and development of lifting system and positioning system, ensured the accuracy and repeatedly of the testing process
The optical system designed by senior optical engineer (who worked in the Shanghai Optics And Fine Mechanics Institute, Chinese Academy of Science) not only meet the definition of hardness testing requirements, but also can observe the micro structure of the material
With Vickers hardness and Knoop hardness testing capabilities, and testing force can be extended to 2 KG
Testing method, testing power and operation time can be displayed directly on the LCD screen
The hardness value can be displayed directly by entering the indentation diagonal length and avoid the complication of the look-up table
According to different visual habits of the operators, the strength of the light source can be adjusted. To avoid the visual fatigue for long time operation
The testing data able to be printed directly by the built-in printer
Reserved image channel can be connected with computer, used the image analysis software to analyzing the physical and chemical properties of the material

Standard Accessories : 1 piece: 10X micrometer eyepiece; 10X and 40X objective lens; Vickers indenter; X-Y Testing Table; Flat Fixture; Thin Fixture, Small Parts Fixture; Water level; Power cable; Dust cover; Instruction Book; Hardness Conversion Tables; Certificate of quality; Warranty Card; Accessory case; 2 pieces: Standard block of hardness; 4 pieces: horizontal adjusting screw
