View Head : Seidentopf Binocular Head, Inclined at 30°, interpupilary 75mm Distance 48 Seidentopf trinocular Head, Inclined at 30°
Eyepiece : WF 10X/18, P16x/11, Bridge full right image, split-image comparison, superimposed mode; +_3% magnification compensation of the right side; Magnification of relay system in the bridge 1x.
Objective : Achromatic objective 4x, 10x, 40x, 100x Achromatic Objective 20x, 60x Plan Achromatic Objective 4x, 10x, 20x, 40x, 60x, 100x. Nose piece : Quadruple Nose piece
Stage 75x50mm Double layers mechanical stage 140x140mm Focusing : Coaxial coarse & fine focus adjustment system Range 24mm, Fine division 0.004mm Condenser : NA 1.25 Abbe Condenser with iris diaphragm
NA 1.20 Abbe Condenser with iris diaphragm
Dark field condenser(Dry) NA 0.75 Dark Field Condenser(Dry) NA 1.25 Illumination : 3w LED illumination, brightness adjustable halogen lamp 6V/20W
Filter Blue filter, green filter, phase contrast kit, single phase contrast kit
Sliding phase contrast kit
Turret phase contrast kit Polarization set : Simple Fluorescent Attachment : Epi-florascent attachment, photo attachment Video Adapter : C Mount 1x, C Mount 0.5x
Company Details
We are a leading Manufacturer, Exporter, Trader and Supplier of IS: 4381 certified Fine Vision Pathological Microscope and Fine Vision Digital Microscope. Our array of microscopes is designed using highly durable and quality approved aluminum, steel and other raw materials. Our range is designed with cool and bright LED lamps to ensure maximum illumination features. Dust proof quadruple ball bearing nose piece has been used to ensure long lasting life and no maintenance. In addition to this, the observation head can be easily rotated up to 360o. Co-axial focusing system with bright field sub stage condenser with 1.2 N.A ensure maximum efficacy of the offered products.
Nature of Business Manufacturer / Exporter / Supplier / Retailer
