Dense phase conveying systems

Listing ID #3958402

Get Latest Price

Supply Type Manufacturer, Exporter, Supplier
Preferred Buyer Location All over the world

Dense phase conveying is a highly reliable pneumatic conveying system with a low velocity and a high product/air ratio, suitable to convey powders and granule. With Dense Phase Conveyors the....

View More Details

Send Enquiry

Product Details

Dense phase conveying is a highly reliable pneumatic conveying system with a low velocity and a high product/air ratio, suitable to convey powders and granule. With Dense Phase Conveyors the product is introduced into the conveying line through a pressure vessel and is suitable to convey products from a single point to one or more receiving points.

Advantages :

Low velocities
Little segregation and degradation
Smaller piping diameter
Low air consumption
Low investments
Conveying abrasive products, low wear
Conveying fragile products
Little maintenance
No moving or rotating part

In addition, the system has the following features also:

The material inlet valve provided with the system has a special inflatable rubber seal which is inflated with the help of air pressure on closure of the inlet valve, thus eliminating any chance of air leakage from the transporter top ensuring a 100% sealing at the vessel inlet.
In our standard equipments & design range bends provided are of converging - diverging type i.e. wherein bend area decreases (thus thickness increases) at the segment outlet, which keeps the material floating and unsettled, thus eliminating the chances of choking in the bend section.
The transporter is fitted with fluidizing nozzles, which produce a swirling air phenomenon, thus helping in prevention of bridging problem from fine power & adhering problem by hydroscopic elements.

Company Details

We, at ALIX, are proud to introduce ourselves as one of the top-notch companies holding a field of expertise in manufacturing & exporting finest quality machines.
ALIX automation system specialises in design, engineering & mfg. of cGMP grade mehcanical pneumatic material handling and ingredient processing system for Pharma, Food, Beverages, Chemical & Paint industries. The equipment manufactured by 'ALIX' are for conveying, storing, measuring, milling, screening, mixing & blending of dry materials.
We also expertising in design and manufacture of Centralised Dust Collection Systems and components for Bulk Solid handling systems.
The company offers state of the art Standard Model/ GMP Model with the option for fully automatic PLC (Programmable Logic Controls) for various process equipment's, designed to suit a specific and process as required by the clients product. We have suitable design of our products which are globally accepted, advanced international technology, steady performance, superior quality and best services. Our customer should see us as a professional partner & supplier.
At the ALIX automation system the efficient and academically team spares no stone unturned, to be the best in custom build engineering by combining state-of- the- Art design and technology. The company is committed to ensure that no trouble being spared to see that every user of companies product is satisfied with its equipment.
This products are of proven performance and can be seen in use to small scale industries, top loading Indian Comapanies and Multinationals. The products are also exported to various African, Gulf, Middle East & European etc. countries both directly and also through third party exports.
