Concrete Surface Shot Blasting Machine

Listing ID #4153418

Get Latest Price

Supply Type Manufacturer, Exporter, Supplier
Preferred Buyer Location All over the world

View More Details

Product Details

This machine is walk behind type, portable heavy duty self contained Shot blasting machine for surface preparation of plane surface, structure, concrete repair and restoration, general construction surface preparation prior to painting and coating, applying resin and tiles, to remove old coatings and rubber from roads and air port runways, asphalt cleaning etc. just to mention a few. The machine houses small size blast wheel to direct media at high velocity on the surface to be cleaned. The spent abrasive is recollected through vacuum pickup system inbuilt in the machine. The machine provides dust free working environment. The machine is easy to transport and use.
Model ASB-FB-101DT
Technical Specification

Working width	270mm
Blasting capacity	Up to 150m²/h on concrete
Motor	11kW / 380V – 50Hz / 22A – Three phases
Dimensions(LxWxH)	1880mm X 400mm X1060mm
Drive system/Speed	Electric /0-25m/min
Mode of operation	Horizontal movable self-propelled Backward(pull)
Surface	Steel/Concrete/Stone/Asphalt
Accessories
Suction hose	Diameter150mm X Length20m
Dust collector	Motor	6.2kw
	Airflow	1250m³/h
	Dimensions(LxWxH)	1860mmX880mmX1450mm

Company Details

Surface Finishing Equipment Company (SURFEX) Jodhpur Rajasthan India – leader in the design and manufacture of shot blast, shot peening, air operated and airless shot blasting machines.
The company has commenced production of Shot Blasting Machines in the year 1977. Since then it has delivered more than +6000 Shot Blasting Machines. Our manufacturing facility spread over a area of 50,000 sq feet with sales & marketing, design department, accounts, purchase & stores, after sales, quality control, R&D, production department, electrical department and modern workshop. The sales outlets are located in Mumbai, Chennai, Kolkata, Hyderabad and Bangalore. Surfex products are eco-friendly and provide the optimum economic solutions. The co. has a policy of continuous improvement on quality of the machine and strives for consumerism. The workshop is equipped with heavy duty overhead crane capacity 10 Ton and 15 Ton, sheet shearing machine, plate bending and rolling machine, mig welding machines,CNC Plasma Cutting Machine, Automatic Radial Drilling Machine, Automatic Tapping Machine etc just to mention a few. The Company owns prestigious ISO 9001-2008 for manufacturing and supply of these products. The company manufactures Shot Blasting Machine, Sand Blasting Machine, Shot Peening Machine, Abrasive Blasting, Grit Blasting, Surface Finishing Machine, and Construction Equipments.
