Contact SupplierStandard Features:
• Down stroking, Electric/Hydraulic closed loop servo valve controlled.
• Two axis independent ram control (Y1 & Y2), ram is fully guided throughout the entire stroke, guides do not require lubrication and linear encoders for ram feedback and positioning (.01mm/.0004")
•  High Speed, CNC back gauge (X), two finger stops with alenguide are standard (Optional R axis)
•  Esa 550c compact numerical control.
Machine Frame:Â
• The frame is an assembly of a heavy steel plate consisting of 2 side frames, a upper and lower cam plate, reinforced sheet-metal plate for the oil-tank and the hydraulic unit. After welding of the frame it is de-stressed. Some of the main features of this frame are:
• The machined cylinder mount is a integral part of the side-frame.
• The extra heavy side and rear plates provide superior frame stability.
• Ram electrical / hydraulic closed-loop servo system
