| Grinding range (LxW) | mm | 800x400 | |
| Distance from table to the underside of wheel | mm | 425 | |
| Table speed range - Longitudinal (X) | m/min | 0.01-25 | |
| Vertical (Y) - Grinding feed | m/min | 0.01-1 | |
| Vertical (Y) - Rapid feed | m/min | 4 | |
| Cross (X) - Grinding feed | m/min | 0.01-1 | |
| Cross (X) - Rapid feed | m/min | 5 | |
| Segmental grinding wheel dia. | mm | 320 | |
| Grinding wheel - Dia x Bore x Width | mm | 355x127x50 | |
| Grinding wheel speed | rpm | 1500 | |
| Parallelism of Ground surface with respect to reference surface | mm | 0.003 / 800 | |
| Surface finish in production run | µm Ra | 0.3 | |
| Max. material removal capability | 1cc / min / kW | ||
| Allowable absolute vibration Velocity | mm / sec | 0.4 | |
| Control system | SINUMERIK 810D | ||
