Circograph CI Eddy Current Crack Detection System

Circograph CI Eddy Current Crack Detection System

Listing ID #7280167

Get Latest Price

MOQ 1 Piece
Brand NameInstitut Dr. Foerster GmbH & Co. KG, Germany
Max. throughput3 m/s during continuous testing
Test materialFerromagnetic, austenitic, and non-ferromagnetic material
Model Name/NumberCircograph CI
Supply Type Supplier
Preferred Buyer Location All over the world

View More Details

Send Enquiry

Product Details

Brand Name Institut Dr. Foerster GmbH & Co. KG, Germany
Type of Testing Machines Eddy Current Crack Detection Machine
Test material Ferromagnetic, austenitic, and non-ferromagnetic material
Model Name/Number Circograph CI
Operating Frequency 30 kHz - 1 MHz
Sensor system Rotating sensor system with a maximum of two (Ro 20 and Ro 35) opposite test heads
Defect Display From 0.030 Mm At Ro 20 / Ro 35
Max. throughput 3 m/s during continuous testing

Compact test system for longitudinal surface defects

The CIRCOGRAPH CI combines a compact design with intuitive operation in one high-precision rotating test system. The CIRCOGRAPH CI features a user-friendly operation unit as well as easy "Turn-and-Push" rotary switch. The 2-channel system can be adjusted optimally to suit your test tasks thanks to a large range of different rotating heads. Longitudinal defects in the material surface can thus be detected from depths as low as 30 µm.

Your advantages at a glance:

Compact design
Simple operation thanks to integrated operation unit and "turn-push" operation
Universal testing system, can be adapted to individual applications and requirements
2-channel test system
Seamless, continuous testing
Defect depth resolution from 30 µm

Additional Information

Download Detail File : Click Here

Interested in this product? Ask for more details & Latest Price from seller

Send Enquiry

Product Images
