Contact SupplierPhysical Properties | CERA | CERA CHEM |
Classification Temperature C | 1260 | 1425 |
Al2O3 | 42 – 46 | 33 – 37 |
SiO2 | 54 – 58 | 48 – 52 |
ZrO2 | --- | 13 -- 17 |
Fe2O3 | 0.1 | 0.1 |
CaO + MgO | 0.08 | 0.08 |
Na2O + K2O | 0.40 | 0.40 |
Thermal Conductivity | ||
Densities Kg / m3 | 64 96 128 | |
400 Deg. C | 0.12 0.11 0.10 | |
600 Deg .C | 0.20 0.16 0.15 |
Grades | (1) Cera (2) Cerachem |
Classification Temperature(°C) |
(1) 1260 (2) 1425 |
Thickness | (1) 13,25,38,50 (2) 13,25,38,50 Other thickness on request |
Dimensions (mm) | (1) & (2) 610 x 7300 Roll size, Other sizes on request |
Density (kg/m2) | (1) & (2) 96 , 128 Others densities on request |
Thermal Conductivity (W/mK) (at mean temperature of 600°C depending on density ) | (1)0.150-128 kg/m3 (2)0.150-128 kg/m3 |
Application Areas |
Furnace, Kin, Fired Heaters, Hydrogen Reformer linings, Also insulation of Steam and Gas Turbines, Investment casting moulds, reusable insulation for field stress relieving, fire protection and acoustic insulation at high temperatures. High Temperature Pipe wrap Application. Used to make Modules for Tunnel & Roller Kiln |
Grades | (1) Standard (2) Zirconia |
Classification Temperature(°C) |
(1) 1260 (2) 1425 |
Thickness | (1) 12 & 25 (2) 12 & 25 Other thickness such as 6,38,50 etc. on request |
Dimensions (mm) | (1) & (2) 610 x 7300 Roll size, Other sizes on request |
Density (kg/m2) | (1)64, 96 & 128 (2)96 & 128 160 on request |
Thermal Conductivity (W/mK) (at mean temperature of 600°C depending on density ) | (1)0.126-128 kg/m3 (2)0.130-128 kg/m3 |
Application Areas |
Furnace, Kin and Heater, Low Thermal Mass lining for fuel savings, easy installation and maintenance benefits. High temperature pipe-wrap applications. |
