Contact SupplierCalifornia Bearing Ratio Test Apparatus :
Alpha Chem is manufactures,exporter & suppliers California Bearing Ratio Test Apparatus.
California Bearing Ratio Test Apparatus :
THE APPARATUS CONSISTS OF :
Load Frame, 50kn ( 5000 kgf) Capacity, 3 Speeds
Mould 150mm ID x 175mm high
Perforated Base Plate for ZI3074- 2 Mould
Extension Collar, 150mm ID x 50mm high
Penetration Piston, 50mm face dia
Adjustable Bracket, for Penetration Dial Gauge
Circular Metal Spacer Disc. With detachable handle, 148 mm dia x 47.7 mm high time.
Annular Metal Weight, 2.5kg, 147mm dia with 53 mm dia central hole
Perforated Metal Weight 2.5 kg. 147mm dia, with 53mm dia soft
Perforated Plate, 148mm dia, with adjustable stem and lock nut
Metal Tripod for Dial Gauge
Cutting Collar
Rammer 2.6kg, 310mm controlled drop
Rammer 4.9kg, 450mm controlled drop
Proving Ring Capacity 50 KN
Dial Gauge, 25 mm travel, 0.01mm least count
OPTIONAL :
Annular Metal Weight 5 kg, 147mm dia with 53 mm dia central hole
Slotted Metal Weight 5 kg 147mm dia with 53mm dia slot
