Contact SupplierCable Dimensions | Cable gland dimension | |||||||
Cable Gland Size |
Max | Armour Wire Diameter |
Thread | Gland Dia. | Gland Dia. | Part No. | ||
U.A.D | O.D | Size | Length | Across Flat | Across Corner | |||
20S | 11.8 | 16.1 | 0.90/1.25 | 20 | 9.5 | 21 | 23.8 | MBP-BW 20S |
20L | 14.1 | 18.4 | 0.90/1.25 | 20 | 9.5 | 22.5 | 23.5 | MBP-BW 20 |
25L | 20.2 | 25.2 | 1.25/1.60 | 25 | 9.5 | 31.5 | 35 | MBP-BW 25 |
32L | 26.4 | 32.4 | 1.60/2.00 | 32 | 10 | 40.4 | 44.8 | MBP-BW 32 |
40L | 32.3 | 38.6 | 1.60/2.00 | 40 | 15 | 46.5 | 51 | MBP-BW 40 |
50S | 38.2 | 46.2 | 2.00/2.50 | 50 | 15 | 54 | 60 | MBP-BW 50S |
50L | 44 | 52 | 2.00/2.50 | 50 | 15 | 60.5 | 66 | MBP-BW 50 |
63S | 50.4 | 58.1 | 2.5 | 63 | 15 | 66 | 73 | MBP-BW 63S |
63L | 56.3 | 64.3 | 2.5 | 63 | 15 | 72.5 | 81.5 | MBP-BW 63 |
75S | 61 | 70.9 | 2.5 | 75 | 15 | 80 | 90.5 | MBP-BW 75S |
75L | 68.3 | 78.2 | 2.50/3.15 | 75 | 15 | 85 | 93 | MBP-BW 75 |
90L | 80.5 | 92.7 | 3.15 | 90 | 15 | 102.5 | 112 | MBP-BW 90 |
