Automatic Wet Mix Plant

Listing ID #1714863

Get Latest Price

Supply Type Exporter, Supplier
Preferred Buyer Location All over the world

We are reckoned as one of the prominent Automatic Wet Mix Plant Manufacturers, Exporters and Suppliers from India. The Automatic Wet Mix Plant manufactured using high grade material using....

View More Details

Send Enquiry

Product Details

We are reckoned as one of the prominent Automatic Wet Mix Plant Manufacturers, Exporters and Suppliers from India. The Automatic Wet Mix Plant manufactured using high grade material using sophisticated technology is widely appreciated for offering hassle free functioning and good fuel efficiency. The Automatic Wet Mix Plant is widely used in road construction industry and efficiently facilitates construction of roads and pavements.

Specifications

Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â

Model Â		WM 60	WM 100	WM160	WM 200
Four Bin Feeder	Output	60 TPH	100 TPH	160 TPH	200 TPH
	Capacity	40 MT	40 MT	54 MT	54 MT
	Loding Width	3.02M	3.02M	3.66M	3.66M
	Auxiliary conveyor	W 450mm/1.5KW	W 450mm/1.5KW	W 450mm/2.25KW	W 450mm/2.25KW
	Gathering Conveyor	W600mm/3.7KW	W600mm/3.7KW	W600mm/5.6KW	W600mm/5.6KW
	Bin Vibrator	0.75 KW	0.75 KW	0.75 KW	0.75 KW
	Connected Load	10.45 KW	10.45 KW	15.35 KW	15.35 KW
	Shipping Dimension	13.5 x 2.55 x 2.45 M	13.5 x 2.55 x 2.45 M	16.25 x 2.55 x 2.75 M	16.25 x 2.55 x 2.75 M
	Shipping Weight	10.4 Tons	10.4 Tons	12.4 Tons	12.4 Tons
Vibreting screen	Screening Area	1.1 m2	1.1 m2	1.1 m2	1.1 m2
Vibreting screen	Bonnected Load	2.2 KW	2.2 KW	2.2 KW	2.2 KW
Charging Conveyor Â		W 600 mm/5.5 KW	W 600 mm/5.5 KW	W 600 mm/5.5 KW	W 600 mm/5.5 KW
Pug Mill	Capacity	1.38 Cu.m	1.62 CU.m	1.90 CU.m	2..40 CU.m
	No. Of arms	20	28	34	34
	Connnected Load	18.75 KW	22.5 KW	37.5 KW	45 KW
	Shipping Dimension	14000 x 2550 x 3200mm	14000 x 2550 x 3200mm	3955 x 1580 x 3018 mm	3955 x 1580 x 3018 mm
	Shipping Weight	6.8T	7.2T	4.2 T	4.55 T
Water Tank	Capacity	10,000 Litres	10,000 Litres	10,000 Litres	10,000 Litres
Water Pump	Connected Load	1.5 KW	1.5 KW	5.62 KW	5.62 KW
Hydraulic Power Pack	Connected Load	3.75 KW	3.75 KW	3.75 KW	3.75 KW
25 MT Storage Silo	Load Out Conveyor	-	-	W 800 mm / 11.2 KW	W 800 mm / 11.2 KW
	Shipping Dimension (LxWxH)	-	-	4140 x 2980 x 3000 mm	4140 x 2980 x 3000 mm
	Shipping Weight	-	-	5.15 T	5.15 T
40 MT filler Silo	Connected Load	-	-	4.45KW	4.45KW
40 MT filler Silo	Shipping Dimension	-	-	2420 x 10600 mm	2420 x 10600 mm
Total Connected Load Â		42 KW	45.8 KW	80.8 KW	88.2 KW
Genset	Recommended Capacity	70 KW	80 KVA	125 KVA	150 KVA
