Automatic Four Head Bottle Ropp Cap Sealing Machine

Listing ID #3829421

Get Latest Price

PhaseSingle Phase
BowlStainless Steel 304
Electrical WiringFerrule Numbering on all the wires with Proper Markings
Speed Synchronization of Star Wheel & Capping HeadVariable Frequency Drive
Supply Type Exporter, Supplier
Preferred Buyer Location All over the world

View More Details

Send Enquiry

Product Details

Phase Single Phase
Vibrator Pillar Mounting On main Platform
Proxy Autonix / Pulset
Production Speed Per Hour 4800 to 5400 Bottles per Hour (Speed Depends up on the size of caps & bottles).
Capping Head VFD Make 1 H.P Delta
Product Contact Parts Stainless Steel 304
Capping Unit Stainless Steel .304
Machine Platform Approx 1210mm (L) x 810mm (W)
Star Wheel with Back Guide 12 mm thick UHMW / Nylon
Capping Head Pillar Mild Steel with ENP / Hard Chrome
Wires & Cables Labb
Vibrator Stand Mild Steel with ENP Plating
Guide Size 100mm / 150mm
Power 1 H.P / 230 V.AC
Working Height 860 mm (+50 mm)
Guide Rod Stainless Steel 304 (10mm Round Bar)
Machine Coverings Complete in Stainless Steel 304
Bowl Stainless Steel 304
Machine Dimension Approx 1830mm (L) x 1220mm (W) x 2440mm (H)
Change Parts Required in case of change in Cap Size & Bottle Size
Bearings SKF / Nachi / Timken
Up-Down Movement Mechanical (Cam System)
Vibratory Bowl Feeder Mild Steel Cladded in Stainless Steel 304
Plating(Wherever Applicable) ENP / Zinc / Hard Chrome / Blackening
Electrical Wiring Ferrule Numbering on all the wires with Proper Markings
Suitable for Products PET / Glass/Aluminum/ HDPE Bottle
Electrical Components ABB / Delta /Spectra
Conveyor Shafts Mild Steel with Hard Chrome or Zinc Plating
Option With Bowl or With Cap Elevator
Machine Name Automatic Four Head ROPP Caps Sealing Machines
Capping Unit Roll Over Pilfer Proof capper designed to thread and seal aluminum cap
Control Panel Relay Card (Push Button Type )
Conveyor Sprockets Mild Steel or Nylon
Capping Head Gear Box Make Bonfiglioli Ratio: 20:1
Non Contact Parts Stainless Steel / Mild Steel / Aluminum / Teflon (Whichever is applicable)
Machine Motion Rotary Motion -Index Based
Capping Head Motor Make 1 H.P Bonfiglioli
Speed Synchronization of Star Wheel & Capping Head Variable Frequency Drive
(Whichever is applicable)
Conveyor Slat Stainless Steel 304 Slat with Nylon Strips on Side
Support Rod on Existing point of indexing Starwheel Stainless Steel 304
Conveyor Length 6 Feet Depending upon the product
Guide Brackets Spectra make – Plastic
Application To Tight & Seal the Caps on Bottles
Model SBCS-100R
Slat Chain Pitch 3.5” Stainless Steel 304 (3mm thickness)
Caps Feeding Vibratory Bowl Feeder
Sensor Make Sick / Leuze / Panasonic
Shute Stainless Steel 304
Machine Weight Approx 300 Kgs
Machine main frame Square Pipe, Stainless Steel 304

We are leading supplier of this product.
