Automatic 2 Head Piston Liquid Filling Machine

Listing ID #3828229

Get Latest Price

Machine WeightApprox 400 Kgs
Power2 H.P / 230 V.AC
PhaseSingle Phase
Machine DimensionApprox 8 (L) x 8 (W) x 10 (H) – in Feet
Supply Type Exporter, Supplier
Preferred Buyer Location All over the world

View More Details

Send Enquiry

Product Details

Machine Weight Approx 400 Kgs
Power 2 H.P / 230 V.AC
Phase Single Phase
Pneumatics SMC / Festo / Janatics
HMI + PLC Delta / Panasonic
Up Down Movement Pneumatic system
Conveyor Motor 0.5 HP 1440 RPM Bonfiglioli
Conveyor Guide Stainless Steel 304 Rod (10mm Round Bar)
Sensors Leuze /Sick / Panasonic
Hopper Capacity 200 liters
In let & Out Let Pipes Silicon Hose Pipes
Application Filling Liquid / Viscous Liquid/ Hot Liquid in to the Bottles /Containers
Machine Dimension Approx 8 (L) x 8 (W) x 10 (H) – in Feet
Air Pipes SMC / Festo / Janatics
No Bottle – No Filling With the help of Sensor
Machine main base frame Mild Steel Angles
Compressed Air Required 6 bar pressure 0.5 CFM
Plating(Wherever Applicable) Zinc / Hard Chrome / Blackening
Machine Name Automatic Piston Liquid Filling Machine
Non Contact Parts Stainless Steel / Mild Steel / Aluminum / Teflon (Whichever is applicable)
VFD Make Delta / ABB
Volume Capacity 100ml to 1000 ml with help of change parts
Machine Motor Make 2 KW Delta / Panasonic
Electrical Components ABB / Delta /Spectra
Number of Filling Heads 2 Heads
Electrical Wiring Ferrule Numbering on all the wires with Proper Markings
Operating Panel HMI + PLC
Bearings SKF / Nachi (USA) / Timken (USA)
Hopper Stainless Steel 316
Bottle Stopper Pneumatic Based
Slat Chain Size 97mm, Pitch - 3.5”, Stainless Steel 304
Suitable for Packing Material HDPE / PET / GLASS / METAL TIN / Aluminum Bottles
Filling Volume Accuracy +/-0.5 %
Level sensor for hopper Leuze /Sick / Panasonic
Upper and Lower Level for Hopper Level switch with Sensor
Proxy Autonix / Pulset
Volume Adjustment HMI + PLC (one time setting)
Conveyor Motor Make 0.5 HP Bonfiglioli
Hopper Specification Jacketed with stirrer
Material Collection Tray at the bottom of Conveyor Stainless Steel 304
Emergency Stop Emergency push button on conveyor
Slat Chain thickness 3mm
Filling System Servo base filling
Wires & Cables Labb
Conveyor Gear Box Make Bonfiglioli Ratio: 50:1
Working Direction Left to Right - Linear
By-Pass Pipes Silicon Pipes
Product Contact Parts Stainless Steel 316
Machine Coverings Complete in S.S. 304
Working Height 860mm ( +/-50 mm)
Production Speed Per Hour 1000 to 1200 containers per hour Speed Depends upon the Number of Filling Heads, Liquid Foaming Nature, Filling Volume, Neck Size)
Prevention of Dropping Pneumatic system
Suitable for Products Free Flowing Liquids
Conveyor Stainless Steel 304
