Contact SupplierARROW is as one of the leading supplier stockiest & exporter of high quality API 5L Pipe (Seamless Steel Pipe), Carbon steel is more commonly used than any other metal, and has long been admired for its versatility and low cost. As a specialist in scheduled and non-scheduled heavy wall pipe and tube, Federal Steel Supply stocks a complete size range of carbon steel pipe and tube. We offer multiple grades of carbon steel covered by ASTM, ASME and API specifications:
API 5L is the specification for line pipe. ARROW offers both seamless and welded API 5L line pipe. This carbon steel pipe is used for pipeline transportation systems. Our API 5L line pipe is only manufactured from premium mills in a variety of grades; B, X42, X52, X60, X65, X70 and X80 in both PSL-1 and PSL-2
The API SPEC 5L specification provides standards for pipe suitable for use in conveying gas, water, and oil in the natural gas and oil industries. The API SPEC 5L covers seamless and welded steel line pipe. It includes plain-end, threaded-end, and belled-end pipe, as well as through-the-flowline (TFL) pipe, and pipe with ends prepared for use with special couplings.
This API 5L specification Covers Seamless and Welded Steel Line Pipe. It includes standard-weight and Extra-Strong threaded Line Pipe. It includes standard-weight and extra-strong threaded line pipe; and standard-weight plain-end, regular-weight plain-end, special plain-end, extra-strong plain-end, special plain-end, extra-strong plain-end pipe; as as well as bell and spigot and through-the-flow line(TFL) pipe.
The purpose of this specification is to provide standards for pipe suitable for use in conveying gas, water, and oil in both the oil and natural gas industries
Grades covered by this specification are Gr. B (and the following “X” Grades), X42, X46, X52, X56, X60, X65, X70, X80. The two digit number following the “X” indicates the Minimum Yield Strength (in 000’s psi) of pipe produced to this grade.
API 5L Pipe (Seamless Steel Pipe) SpecificationAPI 5L Pipe (Seamless Steel Pipe)
API 5L Grade | Yield Strength min. (ksi) |
Tensile Strength min. (ksi) |
Yield to Tensile Ratio (max.) |
|
|
A | 30 | 48 | 0.93 | 28 | |
B | 35 | 60 | 0.93 | 23 | |
X42 | 42 | 60 | 0.93 | 23 | |
X46 | 46 | 63 | 0.93 | 22 | |
X52 | 52 | 66 | 0.93 | 21 | |
X56 | 56 | 71 | 0.93 | 19 | |
X60 | 60 | 75 | 0.93 | 19 | |
X65 | 65 | 77 | 0.93 | 18 | |
X70 | 70 | 82 | 0.93 | 17 | |
X80 | 80 | 90 | 0.93 | 16 |
