220V All Geared Vertical Milling Machine, For Industrial, Color : Grey

220V All Geared Vertical Milling Machine, For Industrial, Color : Grey

₹ 100 Lakh / piece

MOQ1 Piece
MaterialStainless Steel
Driven TypeElectric
CertificationCE Certified
ColorGrey
Supply TypeManufacturer, Exporter
Preferred Buyer Location All over the world

Company Information

Member Since 4 Years
Nature of Business Manufacturer
GST No. 03AUBPS0211N1ZX

Ask for more detail from the seller

Report incorrect details

Product Details
Company Details

MaterialStainless Steel
Driven TypeElectric
TypeAutomatic
CertificationCE Certified
ColorGrey
Voltage220V
Warranty1 Year
Country of OriginIndia
ApplicationIndustrial

STANDARD EQUIPMENTS :

Draw Bar
Power Pack with Cylinder
Electrical Control Panel with Switch Box & Motors
Machine Lamp
Bellow Covers & Base Splash Tray

OPTIONAL EQUIPMENTS :

Dividing Head
Rotary Table
Milling Machine Vice
DRO (Digital Read Out)
Electric Coolant Pump & whichever not mentioned in standard

Note :

Being committed to continual improvement, all specifications are subject to change without prior notice.
We always focus to do customization/ automation in machines as per our customer’s need.
Jig Fixtures, Tooling, Cutters & Inserts, Job Clamps etc. in buyer’s scope.
Final Inspection is mandatory once before despatch from our factory to avoid unsought advices.

Specifications

MODEL	VMG 700	VMG 850	VMG 1100	VMG 1200	VMG 1300
Work Table Size	1350×300	1600×350	1900×400	2100X400	2300×500
Swivel of Table	±45°	±45°	±45°	FIX	FIX
T-Slot Nos. / Bolt Size	03/16/23	03/16/23	05/16/23	05/20/23	05/20/23
T-Slot Centre Distance	65	90	80	90	95
Distance From Spindle to Table max/min	350-60	425-75	475-75	575-75	625-75
X-Longitudinal Table Travel	700	850	1100	1200	1300
Y-Cross Table Travel	225	325	450	500	550
Z-Knee Vertical Travel	410	500	600	650	700
Table Loading Capacity in (kgms.)	350	700	1100	1800	2500
FEEDS & RAPIDS IN X-Y-Z AXIS
No. of Feeds	18	18	18	18	18
Range of Longitudinal Feed/min	18 to 400	18 to 400	18 to 400	13 to 305	13 to 305
Range of Cross Feed /min	18 to 400	18 to 400	18 to 400	13 to 305	13 to 305
Range of Vertical Feed /min	2.5 to 62	2.5 to 62	2.5 to 62	4 to 90	4 to 90
No. Of Rapid Traverse	2	2	2	2	2
Longitudinal Rapid Feeds / min	900, 1500	900, 1500	735, 1065	500, 735	500, 735
Cross Rapid Feeds/ min	900, 1500	900, 1500	735, 1065	500, 735	500, 735
Vertical Rapid Feeds/min	147, 210	147, 210	147, 210	165, 250	165, 250
SPINDLE DETAILS
No of Spindle Speeds	12	12	12	12	12
Range of Spindle Speeds (RPM)	45-1120	45-1120	45-1120	45-1120	45-1120
Spindle Taper Standard	ISO 40	ISO 40	ISO 40	ISO 40	ISO 40
Quill Travel Manual (mm)	95	95	95	95	95
ELECTRICAL
Spindle Motor/ RPM’s	3HP/ 1440	5 HP/ 1440	7.5 HP/1440	10 HP/ 1440	10 HP/ 1440
XYZ Axis Feed Motor	2 HP	2 HP	3 HP	3 HP 935 RPM	3 HP 935 RPM
Coolant Motor	0.1 HP	0.1 HP	0.1 HP	0.1 HP	0.1 HP
FLOOR & PACKING DIMENSIONS (APPROX.)
Overall Length	2000	2050	2500	2700	2700
Overall Width	1750	1950	2500	2600	2600
Overall Height	1800	1880	2400	2700	2700
Net Weight kgms.	2500	3500	4200	5500	7000
Gross Weight with Wooden Packing	3500	4600	5500	6800	8500
