Passive Intermodulation Analyzer

Passive Intermodulation Analyzer

Listing ID #6012657

Get Latest Price
  • Weight8.5 to 12.5 kg,depending on model
  • Brand NameR&S
  • Battery Capacity5.8 AH
  • Power Resolution0.1 dB
  • Supply Type Manufacturer, Exporter, Supplier, Retailer, Trader
  • Preferred Buyer Location India only
View More Details
Send Enquiry

Company Information

Rohde & Schwarz India Pvt. Ltd.
Mathura Road, Delhi
View Number
  • Member Since 12 Years
  • Nature of Business Service Provider

Ask for more detail from the seller

Contact Supplier

Product Details no_img_icon

  • Weight 8.5 to 12.5 kg,depending on model
  • Brand Name R&S
  • Adjustable Power Range 24 dBm to 46 dBm x 2 (250 mW to 40 W x 2)
  • Display Size and Type 8.0" [203.2 mm] capacitive TFT (industrial grade)
  • PIM Location (PIMPoint) distance in meters or feet with VP Settings
  • Measurement Method one port,reverse PIM
  • PIM vs Time 3rd and 5th PIM
  • RX Interference receive only mode,noise floor measurement
  • Power Requirements AC and DC (AC: 90V to 256 V,50HZ to 60 Hz)
  • Noise Floor -136 dBm
  • Battery Operation >3 hours
  • Measurement Sensitivity -135 dBm
  • Battery Power 28 VDC
  • Reverse Power Protection 13 dBm (20 mW) continuous
  • RF Output Connector 7-16 DIN female
  • Real Time PIM 3rd and 5th PIM
  • Remote Control WiFi enabled (802.11)
  • Frequency Sweep frequency response
  • Alarms audio and visual
  • Storage Temperature Range -30 DegreeC,-60 DegreeC,85 % relative humidity
  • Accessories Included DC adapter,operation manual
  • Max. Power Consumption 340 W
  • Battery Type Li-polymer removable battery pack
  • Power Accuracy 0.3 dB
  • Residual Intermodulation Level -122 dBm (typ. -125 dBm)
  • Data Ports 3 x USB 2.0,1 x Ethernet LAN port
  • Dimensions (W x H x D) 350 x 230 x 114 mm
  • Operating Temperature range -10 DegreeC,-45 DegreeC,95 % relative humidity
  • Frequency Step Size 200 kHz
  • Frequency 5 ppm
  • Power Resolution 0.1 dB
  • Battery Capacity 5.8 AH
