Contact SupplierES1016 support 16 ports 10Base-T/100BaseTX ; no fan, low consumption, industry 4 grade design, can adapt rugged industry environment; 0???70� working temperature can satisfy some requirements of industry filed, can provide economical solution for your Ethernet connection. Features 1. Support IEEE802.3/802.3u/802.3x 2. Support auto-consult function 3. Support MDI/MDI-X self-adaption 4. Support 8K MAC address table 5. 0-70� working temperature 6. No fan, low consumption 7. IP40 protection class 8. 1U 19 inch rack mount Specification Technology: Standard: IEEE802.3, IEEE802.3u, IEEE802.3x Flow control: IEEE802.3x, back pressure Interface Electric port: 10Base-T/100Base-TX auto speed control, Half/full duplex and MDI/MDI-X auto detection Transfer distance: Twisted cable: 100M??? standard CAT5/CAT5e cable??? LED indicator: Power (PWR), RUN indicator, port status indicator Exchange attribute: 100M forward speed: 148810pps 100M maximum filter speed:148810pps Transmit mode: store and forward System exchange bandwidth: 12.8G MAC address table: 8K Memory: 4Mbits Power supply Input voltage: 100-240VAC/DC Input mode: 4 bits terminal block No-load consumption: 4.2W Full-load consumption: 6.7W Working environment: Working temperature: 0???70� Storage temperature:-40???75� Relative Humidity: 5%~95% (no condensation) Mechanical Structure: Shell: IP40 protect grade, metal shell Installation: 1U 19 inch rack mount Size (W�H�D): 441.6mm�45mm�208.9mm Certifications FCC, CE, UL508 (pending) EMI: FCC Part 15, CISPR (EN55022) class A EMS: EN61000-4-2 (ESD), Level 4 EN61000-4-4 (EFT) , Level 4 EN61000-4-5 (Surge) , Level 4 Shock: IEC 60068-2-27 Free fall: IEC 60068-2-32 Shake: IEC 60068-2-6
