Details :
| Image Sensor | 1/2.8” 4Megapixel progressive CMOS |
|---|---|
| Minimum Illumination | 0.003 lux@F1.0 (Color, 30I RE) 0.0003 lux@F1.3 (B/W, 30I RE) 0 lux (IR on) |
| Effective Pixels | 2560 x 1440 |
| Shutter Speed | Auto/Manual, 1/3~1/100000s |
| S/N Ratio | >56dB |
| White Balance | Auto/Natural/Street Lamp/Outdoor/Manual |
| Lens | 2.8mm/3.6mm/4mm/6mm/8mm/12mm (optional) |
| Close Focus Distance | 0.4 m–2.0 m |
| Gain Control (AGC) | Auto/Manual |
| Lens Type | Motorized/FIXED |
| Video Compression | H.265, Smart H.264+, H.264, H.264B, H.264H, MJPEG (sub stream) |
| Encode Strategy | Insta stream |
| Angle of View | H: 31°–9°, V: 23°–7° (2592 × 1944) ; H: 32°–9°, V: 18°–5° (2688 × 1520) |
| Back Light Compensation | BLC/ HLC/ WDR(120dB) |
| Max. Aperture | F1.3 (Constant) |
| Video Streaming | Main Stream: 2560 × 1440 (1 fps–25/30 fps) 1920 × 1080 (1 fps–50/60 fps) Sub Stream: D1 (1 fps–20/30 fps) D1 (1 fps–50 fps) Third Stream: 1080P (1 fps–17 fps) |
| Privacy Mask | 8 areas |
| DORI Distance | W– 190m (Detect) 76m (Observe) 38m (Recognize) 19m (Identify) T– 620m (Detect) 248m (Observe) 124m (Recognize) 62m (Identify) |
| ICR | Auto (ICR)/Color/B/W |
| Resolution | 2560 × 1440/2304 × 1296/1080P (1920 × 1080)/1.3M (1280 × 960)/720P (1280 × 720)/D1 (704 × 576/704 × 480)/VGA (640 × 480)/CIF (352 × 288/352 × 240) |
| ROI | Yes (4 areas) |
| Motion Detection | Off/On (4 Zone, Rectangle) |
| Audio Input | 1 Ch. |
| Audio Output | 1 Ch. |
| Audio Compression | G.711a, G.711Mu, G.726, G.723 |
| Alarm IN | 1 channel In: 5mA 5V DC |
| Alarm Out | 1 channel Out: 300mA 12V DC |
| Smart Detection | Object Abandoned/Missing, Heat Map |
| Protocol | IPv4; IPv6; HTTP;TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP; Bonjour, ONVIF (Profile S/Profile G/ Profile T), CGI, Milestone, Genetec, InstaOn |
| Ethernet | RJ-45 (10/100Base-T) |
| Bit Rate | H.264: 32 Kbps–8192 Kbps; H.265: 19 Kbps–8192 Kbps |
| Perimeter Protection | Tripwire; intrusion; fast moving (the three functions support the classification and accurate detection of vehicle and human); loitering detection; people gathering; parking detection |
| People Counting | Support the counting of enter number, leave number, and pass number, and displaying and outputting yearly/monthly/daily reports. Support the counting of number in area, and 4 rules configuration. Count number of people or stay time and link alarm. Support queue management, and 4 rules configuration. Count number of people or stay time and link alarm. |
| Event Trigger | Motion detection, Video tampering , Scene changing, Network disconnection , IP address conflict, Illegal Access, Storage anomaly |
| Face Detection | Face detection; track; optimization; snapshot; report high quality picture; face enhancement; face exposure; face attribute extract, 6 attributes and 8 expressions: Gender, age, glasses, expressions (anger, calm, happiness, sadness, disgust, surprise, confusion and fear), mask, beard; face matting setting: face, single inch photo; three snapshot methods: real-time snapshot, optimization snapshot, quality priority; face angle filter; optimization time setting |
| Alarm Event | No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; Defocus Detection; scene changing; intrusion; tripwire; abandoned object; missing object; fast moving; parking detection; loitering detection; people gathering; audio detection; people counting; face detection; People counting in area; Stay alarm; People No. exception detection; Queue Management |
| Cyber Security | Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade |
| SDK and API | Yes |
| Cloud Health Monitoring System (HMS) | Support |
| Smart Phone | iPhone, iPad, Android Phone |
| OTA (Online Device Upgrade) | Support |
| IR | IR Range of 30 Mtr., Smart IR |
| Micro SD | NAS; FTP; SFTP; Micro SD card 256GB (OPTIONAL) |
| Operating Temperature | -30° C to +60° C (-22° F to +140° F)/Less than 95% RH |
| Storage Temperature | -40° C to +60° C (-40° F to +140° F) |
| Power Source | DC 12V (±30%)/AC 24V (±30%)/PoE (802.3af)/ePoE |
| Power Consumption | 4.9W (12V DC); 5.1W (24V AC); 5.2W (PoE) |
| Weatherproof Standard | IP67 & IK10 |
| Casing | Metal/PLASTIC (OPTIONAL) |
| Dimension | Φ159.0 mm × 117.9 mm (6.26” × 4.64”) |
| Weight | 0.95 kg |
