Contact Supplier1. TECHNICAL DATA
1 Number of Operator 9 persons
Mill Roll stand & Single Facer: 1 Double Facer: 1 Slitter Scorer & Cut-off: 1
Stacker: 2 Boiler: 1 Glue system: 1 Chief:1
2 Running Width 1800mm
950mm
3 Max Speed 150 mmin
4 Working Speed 130mmin for 3 ply
100mmin for 5 ply
5 Monthly Output 1000~1500tons (1 shift with12 hours day, 24 working days month)
6 Maximum sheet size 1800mmX 3500 mm
7 Minimum sheet size 125mmX500mm
8 Paper Grades 90 gcsm - 180 gcsm (Medium)
110 gcsm - 400 gcsm (Liner)
9 Adhesives Required starch
10 Starch consumption 3 ply: 10-15g㎡
5 ply: 20-30g㎡
11 Steam Pressure 1.2 MPa
12 Steam Consumption Approx.3000~3600kgh
13 Occupied Space Approx. 10 m X 80m (Incl. operation space)
Highest point is 4.25m
14 Power Capacity Approx : 326Kw
15 Power Required 380V, 50HZ, 3 PHASE
16 Paper going Drive side (left hand or right hand)
17 Flute A, B, C or E (UV flute)
18 Delivery 120 days after the receipt of down payment
19 Quality Guarantee 1 year after installation
