Details
Applications:
Salient Features:
Pumped Liquids:
Clean, thin non-aggressive, non-explosive, clear, cold, fresh water without abrasives.
Power Range | 1 HP |
---|---|
Version | 180-240V 1Ph 50 Hz |
Speed | 2880rpm |
Flow Rate | Upto 35 lpm |
Head Range | Upto 38 meters |
Outlet size in inches | 1" |
Inlet size in inches | 1" |
Degree of Rotation | CCW, CW 1 Ph |
Type of duty | S1 (Continuous) |
PART NAME | MATERIAL |
---|---|
Impeller | HT Brass |
Delivery Casing | Cast Ironn (FG-200) |
Adaptor Motor Body | Extruded Aluminium |
Shaft Seal | Carbon-Graphite |
Pump Shaft | SS410 |
