1 Products availableWe offer a complete product range of Preethitech Accelerometer, Vibration Meter, solid flow meter and hand held vibration meter
Preethitech Accelerometer utilizes the spring-mass system for generating a force proportional to the amplitude of the input acceleration to the base of the system. Force is applied to the piezoelectric (PE) element made of leadzirconate titan ate (PZT) material that produces a charge output proportional to the force. The PE material is self-generating and does not require an external power source.
Our Accelerometers are single ended compression (SEC) design, which provides high sensitivity and high resonant frequency. A special type of base construction is used to minimize effects of base strain, which makes the device useful for reliable low signal level measurements. The Piezoelectric Accelerometer construction is entirely of stainless steel. It carries standard 10-32 UNF miniature connector for output connection and is suitable for application in low-level vibration measurements at frequencies down to 0.1 Hz in laboratory and industrial environments.These accelerometers are best suited for vibration analysis in harsh industrial environments
Vibration meter typeVM301A0is a portable instrument, which is used in conjunction with Piezo-electric accelerometers to measure mechanical vibrations in terms of acceleration, velocity & displacement. It is suitable for both laboratory and field conditions. This instrument can be used to monitor vibration levels in production machines on a periodic basis, so that action can be taken before a complete machine failure. Its operation is simple and quite suitable for use by non-scientific personnel not conversant with electronic instrumentation. In combination with PreethiTechPiezo electric accelerometers the unit provides direct read out of vibration parameters on a 3 digit LCD display. The unit is pow
These metering devices are used to measure the flow rate of very fine particles like fly ash, cement etc. The material flows by gravity through an air slide and flows over a plate which measures the impact which is proportional to the density of the material and the flow rate. The impact on the plate is measured by two high precision loadcells that give a very linear output proportional to the flow rate. The output of the loadcells are fed into the micro controller based flow rate indicator which gives the rate and totalized quantity of material.
The solid flow meters can be used in series with a rotary air valve or dozing valve to have a controlled feed of material. These metering devices are extensively used for truck loading and fly ash handling systems. Call us for quality solid flow meters in India.
Hand-held Vibration meter(VM516A0) is a portable and easy to use instrument which is used in conjunction with Integrated Electronics Piezoelectric (IEPE) accelerometers to measure mechanical vibrations in terms of acceleration, velocity and displacement. It is suitable for both laboratory and field conditions.This instrument can be used to monitor vibration levels in production machines on a periodic basis, so that action can be taken before a complete machine failure. Its operation is simple and quite suitable for use by nonscientific personnel not conversant with electronic instrumentation. In combination with IPA piezoelectric accelerometers the unit provides direct read out of vibration parameters on a LCD screen in both Metric and Imperial units. The device uses a 2200mah rechargeable battery which gives a battery life upto 70hrs continuously following a full charge. It features a dedicated power save button for extended battery life. An output of 2V DC (F.S) is available for recording purpose.
Industrial Blowers.Cooling Towers.Electric Motors.Diesel Engines.Small Turbines.Industrial Gearboxes.Centrifuges and Decanters.Centrifugal Pumps.Test Benches.Conveyers.
