NP TECHNOLOGIES

Bangalore, Karnataka

We are offering dc power supply. Prominent & leading manufacturer and exporter from bengaluru, we offer complete solution for dc power supply such as programmable dc power supply, programmable dc power supply ope-q series, laboratory power supply, switching type programmable dc power supply, dc power supply, regulated dc power supply and many more items.

Declaration of commercialization of the programmable DC Power Supply with the best technology! Supply of Programmable DC Power Supply at low price CV / CC mode operation OUTPUT ON/OFF function provided Able to store and recall up to five operation states (voltage, electric current) 19Half x 2U slim size (less than 300 W) RS-232C attached by default (RS-485 Option) Specification: Voltage Current 10A 20A 30A 50A 100A 200A 500A 9V OPE-910DI OPE-920DI OPE-930DI OPE-950DI OPE-9100DI OPE-9200DI OPE-9500DI 18V OPE-1810DI OPE-1820DI OPE-1830DI OPE-1850DI OPE-18100DI OPE-18200DI OPE-18500DI 30V OPE-3010DI OPE-3020DI OPE-3030DI OPE-3050DI OPE-30100DI OPE-30200DI OPE-30500DI 50V OPE-5010DI OPE-5020DI OPE-5030DI OPE-5050DI OPE-50100DI OPE-50200DI OPE-50500DI 120V OPE-10010DI OPE-10020DI OPE-10030DI OPE-10050DI OPE-100100DI OPE-100200DI OPE-100500DI 200V OPE-20010DI OPE-20020DI OPE-20030DI OPE-20050DI OPE-200100DI OPE-200200DI OPE-200500DI 250V OPE-25010DI OPE-25020DI OPE-25030DI OPE-25050DI OPE-250100DI OPE-250200DI OPE-250500DI 300V OPE-30010DI OPE-30020DI OPE-30030DI OPE-30050DI OPE-300100DI OPE-300200DI OPE-300500DI 500V OPE-50010DI OPE-50020DI OPE-50030DI OPE-50050DI OPE-500100DI OPE-500200DI OPE-500500DI

Declaration of commercialization of the programmable DC Power Supply with the best technology! Supply of Programmable DC Power Supply at low price CV / CC mode operation Two power modes (+), (-) each variable output provided 5 V/ 2 A & 15 V/ 1 A fixed output provided OUTPUT ON/OFF function provided Tracking Mode (two outputs controlled at the same time) provided Able to store and to recall up to five operation states (Voltage, Current) Slim 19Half x 2U size (less than 300 W) RS-232C attached by default (RS-485 Option) Use the communication interface that is provided in the OPE Series!: OPE Series provides RS-232C (RS-485 Option). This enables many functions such as control and data collection with the PC or PLC through RS-232C communication interface. Our company product enables programmer to produce application with ease by adopting standard SCPI programming language. Moreover, it is possible to develop the system with ease by using the application that is provided by our company Two channels can be controlled at once If single channel power supply was supplied for each producer when it comes to your companys mass production system, replace it with the power supply in two channels that supports our companys tracking mode! There is no need to set up two channels voltage and current which is cumbersome. Instead, pressing simply one button, the tracking mode button can set up two channels in the same way using only one setting for the voltage, current and all the functions. This supports the state storage function. OPE Series can store and recall the voltage and current set by user. Even when a user is not an engineer, the user can use it easily for the production, product inspection, reliability test etc., with the Store and Recall function that set up and stored in advance. Parameter Model OPE-185Q OPE-303Q OPE-305Q OPE-503Q Output rating 018V, 05A 2CH 030V, 03A 2CH 030V, 05A 2CH 050V, 03A 2CH Resolution Programming/Readback 6mV / 1.5mA 7.5mV / 1mA 7.5mV / 1.5mA 15mV / 1mA Display Meter 100mV / 10mA 100mV / 10mA 100mV / 10mA 100mV / 10mA Programming Accuracy (@25 5)(%of output + offset) Voltage 0.2% + 120mV 0.2% + 200mV 0.2% + 200mV 0.2% + 300mV Current 0.2% + 25mA 0.2% + 15mA 0.2% + 25mA 0.2% + 15mA OPTION Output at the rear side, input power (AC 100, AC 110, AC 230), RS-485 communication, RS-232C Cable, RS-485 Analog Signal Input, Analog Signal Output, V-Sensing, OVP, OCP, rack mount kit

Declaration of commercialization of the programmable DC Power Supply with the best technology! Supply of Programmable DC Power Supply at low price CV / CC mode operation Two insulated variable output provided Fixed output that enables the selection of 5 V/ 2 A & 3.3 V/ 2 A is provided Fixed output that enables the selection of 15 V/ 1 A & 12 V/ 1 A is provided OUTPUT ON/OFF function provided Tracking Mode (two outputs controlled at the same time) provided Able to store and recall up to five operation states (Voltage, Current) 19Half x 2U slim size (less than 300 W) RS-232C attached by default (RS-485 Option) Use the communication interface that is provided in the OPE Series! OPE Series provides RS-232C (RS-485 Option). This enables many functions such as control and data collection with the PC or PLC through RS-232C communication interface. Our company product enables programmer to produce application with ease by adopting standard SCPI programming language. Moreover, it is possible to develop the system with ease by using the application that is provided by our company. Two channels can be controlled at once. If single channel power supply was supplied for each producer when it comes to your companys mass production system, replace it with the power supply in two channels that supports our companys tracking mode! There is no need to set up two channels voltage and current which is cumbersome. Instead, pressing simply one button, the tracking mode button can set up two channels in the same way using only one setting for the voltage, current and all the functions. This supports the state storage function. OPE Series can store and recall the voltage and current set by user. Even when a user is not an engineer, the user can use it easily for the production, product inspection, reliability test etc., with the Store and Recall function that set up and stored in advance. ParameterModel OPE-185QI OPE-303QI OPE-305QI OPE-503QI Output rating 018V, 05A 2CH 030V, 03A 2CH 030V, 05A 2CH 050V, 03A 2CH Resolution Programming/Readback 6mV / 1.5mA 7.5mV / 1mA 7.5mV / 1.5mA 15mV / 1mA Display Meter 100mV / 10mA 100mV / 10mA 100mV / 10mA 100mV / 10mA Programming Accuracy (@25 5)(%of output + offset) Voltage 0.2% + 120mV 0.2% + 200mV 0.2% + 200mV 0.2% + 300mV Current 0.2% + 25mA 0.2% + 15mA 0.2% + 25mA 0.2% + 15mA Parameter Model OPE-802QI OPE-1001QI OPE-1201QI OPE-1501QI Output rating 080V, 02A 2CH 0100V, 01A 2CH 0120V, 01A 2CH 0150V, 01A 2CH

OPS Series offers next generation highly precise, highly responsive Programmable DC Power Supply that enables simple operation method, precise DC output, diverse PC applications, strong durability and diverse circuits for protection. Likewise, this product can be used at various places in the digital era including industrial fields, research centers. Protection against over-voltage (OVP) / over current (OCP) Able to store and recall up to 10 operation states (voltage, current, OVP, OCP) Able to store and confirm up to 10 error messages Self-diagnosis test mode Supports up to 100 cycling modes (voltage, current slope and delay time) Support for external software calibration without inside calibration. Factory function provided (memory initialization and correction date back-up and recovery) Specification I V 1A 2A 3A 5A 10A 30A 50A 100A 200A 500A 9V OPS-91 OPS-92 OPS-93 OPS-95 OPS-910 OPS-930 OPS-950 OPS-9100 OPS-9200 OPS-9500 18V OPS-181 OPS-182 OPS-183 OPS-185 OPS-1810 OPS-1830 OPS-1850 OPS-18100 OPS-18200 OPS-18500 30V OPS-301 OPS-302 OPS-303 OPS-305 OPS-3010 OPS-3030 OPS-3050 OPS-30100 OPS-18200 OPS-30500 50V OPS-501 OPS-502 OPS-503 OPS-505 OPS-5010 OPS-503 OPS-5050 OPS-50100 OPS-50200 OPS-50500 80V OPS-801 OPS-802 OPS-803 OPS-805 OPS-8010 0OPS-8030 OPS-8050 OPS-80100 OPS-80200 OPS-80500 100V OPS-1001 OPS-1002 OPS-1003 OPS-1005 OPS-10010 OPS-10030 OPS-10050 OPS-100100 OPS-100200 OPS-100500 150V OPS-1501 OPS-1502 OPS-1503 OPS-1505 OPS-15010 OPS-15030 OPS-15050 OPS-150100 OPS-150200 OPS-150500 200V OPS-2001 OPS-2002 OPS-2003 OPS-2005 OPS-20010 OPS-20030 OPS-20050 OPS-200100 OPS-200200 OPS-200500 300V OPS-3001 OPS-3002 OPS-3003 OPS-3005 OPS-30010 OPS-30030 OPS-30050 OPS-300100 OPS-300200 OPS-300500 500V OPS-5001 OPS-5002 OPS-5003 OPS-5005 OPS-50010 OPS-50030 OPS-50050 OPS-500100 OPS-500200 OPS-500500

Economically viable price, convenient method of use! ORS Series provides single variable output channel with regulated DC Power Supply. Select the ORS Series if you want simple power output. Supply of low price DC Power Supply CV / CC mode operation Stable Ripple & Noise Specification ORS-303A ORS-303CF ORS-305A ORS-305CF Output Rating 030V, 03A 030V, 03A 5V/1A Fixed Output 030V, 05A 030V, 05A 5V/1A Fixed Output Resolution 100mV / 10mA 10mV / 1mA 100mV / 10mA 10mV / 1mA Read-back Accuracy (@25 5)(%of output + offset) Voltage 0.4% + 2dgt 0.1% + 2dgt 0.4% + 2dgt 0.1% + 2dgt Current 0.4% + 2dgt 0.1% + 2dgt 0.4% + 2dgt 0.1% + 2dgt Ripple & Noise 0.5mVrms, 2mArms 0.5mVrms, 2mArms 0.5mVrms, 2mArms 0.5mVrms, 2mArms Load Regulation Voltage 0.1% + 20mV 0.1% + 20mV 0.1% + 20mV 0.1% + 20mV Curren 0.1% + 5mA 0.1% + 5mA 0.1% + 5mA 0.1% + 5mA Line Regulation Voltage 0.1% + 20mV 0.1% + 20mV 0.1% + 20mV 0.1% + 20mV Curren 0.1% + 5mA 0.1% + 5mA 0.1% + 5mA 0.1% + 5mA Voltage Programming Speed(No load) Rising time 100ms 100ms 100ms 100ms Falling time 1.2s 1.2s 1.2s 1.2s Common matters Dimension : 130mm(W) x 165mm(H) x 310mm(D) Power Cord, User Manual, Output Cable provided Our company offers ORS Series that is priced low and that is easy to use by leveraging accurate and optimal power supplier technology and that offers clean voltage and current. Moreover, this is a DC power supplier that can be trusted unlike other companies products. We adopted FND Display that is characterized by small size, convenient frontal display design, devoid of space limitations and that is comforting to the eyes. Enjoy it at low price.

Economically viable price, convenient method of use! ORT Series provides two variable output channels and one fixed output channel with regulated DC Power Supply. Select the ORT Series if you want to output power easily. Supply of low price DC Power Supply CV / CC mode operation Stable Ripple & Noise INDEPENDENT / SERIES / PARALLEL MODE Our company offers ORS Series that is priced low and that is easy to use by leveraging accurate and optimal power supplier technology. Specification ORT-183 ORT-185 ORT-303 ORT-305 Output Rating 018V, 03A, 2ch 018V, 05A, 2ch 030V, 03A, 2ch 030V, 05A, 2ch 5V/1A Fixed Output 5V/1A Fixed Output 5V/1A Fixed Output 5V/1A Fixed Output Resolution 100mV / 10mA 100mV / 10mA 100mV / 10mA 100mV / 10mA Read-back Accuracy (@25 5)(%of output + offset) Voltage 0.4% + 2dgt 0.4% + 2dgt 0.4% + 2dgt 0.4% + 2dgt Current 0.4% + 2dgt 0.4% + 2dgt 0.4% + 2dgt 0.4% + 2dgt Ripple & Noise 2mVp-p 2mArms 2mVp-p 2mArms 2mVp-p 2mArms 2mVp-p 2mArms Load Regulation Voltage 0.1% + 20mV 0.1% + 20mV 0.1% + 20mV 0.1% + 20mV Curren 0.1% + 5mA 0.1% + 5mA 0.1% + 5mA 0.1% + 5mA Line Regulation Voltage 0.1% + 20mV 0.1% + 20mV 0.1% + 20mV 0.1% + 20mV Curren 0.1% + 5mA 0.1% + 5mA 0.1% + 5mA 0.1% + 5mA Voltage Programming Speed(No load) Rising time 100ms 100ms 100ms 100ms Falling time 1.2s 1.2s 1.2s 1.2s Common matters Dimension : 130mm(W) x 165mm(H) x 310mm(D) Power Cord, User Manual, Output Cable provided

Product Specifications: This DC power supply is programmable to control up to 255 output channels. It insulates various output channels with strong anti-interference capability. It works as a main power controller at research and production sites. Over-voltage and over-current protection. Able to store and recall up to 10 operation states (voltage, current, OVP and OCP). Able to store and confirm up to 10 error messages. Self-diagnosis test mode. Supports external software calibration without inside calibration. 11 factory functions provided.
