Our Products
Our Complete range of products are Automatic Air Jet Cleaning Machine Inbuilt Unscrambler of 30 Dia, ablet/Capsule Counting, Automatic Single Head Screw Capping Machine GMP Model, Automatic Injectable Dry Powder Filling With Pick and Automatic High Speed Injectable Dry Powder Filling With Pick.
Granulation is one of the most important unit operations in the production of pharmaceutical oral dosage forms. However, there are many different technologies each having different strengths and weaknesses.
Granulation methods:
The fluid bed granulation process also known as agglomeration involves suspending particulates in an air stream and spraying aliquid from the top down onto the fluidized bed. Particles in the path of the spray get slightly wetted and become tacky. The tacky particles collide with other particles and adhere to them to form a granule.
Granulation can be performed using fluid beds fitted with spray nozzles. It is possible to have completely closed material handling by a closed linking with upstream and downstream equipment. Also, fully automatic cleaning in fluid beds using stainless steel filters now compares favorably with what is possible in a single pot. There are two different modes of fluid bed granulating:
Dry Stage:In Dry stage granulation, the particles only require a slight wetting to become tacky and stick to each other. The granulating solution is applied at a rate less than or equal to the evaporation rate. Thus the particles remain "dry" through the entire process.
Wet Stage:In Wet stage granulation, the particles require significant wetting before they become tacky enough to stick to each other. The granulating solution is applied at a rate higher than the evaporation rate until the particles build up enough moisture to granulate. The characteristics of the particles when wet and the type of granulating solution being used will determine which mode of granulating is most appropriate. While Dry stage is more common, Wet stage granulating allows for denser products.
Shree BHagwati Pharma Machinery Automatic Air Jet Cleaning Machine inbuilt Unscrambler of 30 Dia. is a compact unit used for cleaning of Dry Syrup bottles before filling.
This machine works on a principle of back pressure of Bottle which will be fed by the unscrambler to reach separator assembly, which transfer the Bottle on conveyor belt and pushes bottle to the cleaning section one after another. Machine consist of two inverters and one cleaning section. Bottle will be pushed by rotating separator towards the infeed inverter, which makes the Bottle in the wrong direction and push it to cleaning section through back pressure of other Bottle. Cleaning section is equipped with continuous vacuum system. Bottle reaches to the cleaning section, a pair of nozzle starts to flush the air inside the neck of the Bottle and simultaneously vacuum will suck the particle, disturbed by the air. Then Bottle passes to another inverter, where changes the direction to the right direction, further Bottle moves either to the filling machine.
BHAGWATIs Automatic Vertical Air Jet Cleaning Machine work on positive air pressure & vacuum cleaning. The unit is made compact, versatile and enclosed in stainless steel elegantly matt finish body, consists of S.S. Slat Conveyor & Reciprocating cleaning nozzles. No container No cleaning system arrangement is standard features of the machine.
The main drive of the machine and conveyor drive consist of A/c Motor with synchronized variable A/c Frequency Drive.
Automatic Vertical Air Jet Cleaning Machine can accomplish a task by a photoelectric system, all the bottle should be cleaned before being filled, when an empty bottle arrives at the specified position, a cleaner comes down automatically until at the mouth of the bottle, then pure air is pressed into the bottle, and the impurity inside of the bottle is removed by vacuum system. This product conforms to the requirements of GMP completely.
It is suitable to check weight of various product, over or less weight will be rejected out, qualify bags will be passed to next equipment.
Bhagwati Automatic Checkweigher / Check Weigher Machine is most suitable for online checkweighing machine of Cartons, Packet, Bottles, Pouches it is suitable for foods & Pharma Industries you know many same machines different name using like Check Weigher Conveying , Check Weigher , Flour Packing Check Weigher Big , Check Weigher Food bottle and boxes, Check Weigher Bottle and Jar , Carton Check Weigher Checkweighing Manufacturers , Bottle and Jar, Pouch , carton , box Check Weigher Manufacturers , Conveying with Check Weighing Machine Manufacturers , Flour Packing Check Weigher Manufacturers Big Size Packing Check Weigher Manufacturers , Food Check Weigher Manufacturers , Bottle Check Weigher Manufacturers India and UK, UAE Checkweighing Manufacturers , Check Weight Machine , Weight Check System.
Checkweigher is Bhagwati low cost, economical solution for fast, accurate checkweighing applications. Its simplified, modular design offers the ruggedness and durability for demanding production environments at significant savings, with no compromise in accuracy or weighing reliability.
The feed container moving on conveyor belt are feed into an in feed star wheel through In-feed worm, star wheel bringing the container below the sealing head in the subsequent indexing part, mean while the bottle pickup a cap from the delivery chute of cap filling bowl, where the body and the neck of the container are positioned below the rotating head, where the sealing head is performing perfect operation of threading & sealing.
Cotton inserting machine can automatically cut and insert cotton into containers quickly and accurately. The machine is designed with a programmable logic controller (PLC) and novel high precision electronic positioning system. It features variable frequency control of mainframe speed. It possesses many protective functions. For example, it will automatically stop when bottle or cotton is absent or bottles are jammed. The product is well up to GMP requirements.
Technical Specification
The unit is built on S. S. Square pipe and totally encompassed with S. S. Coverings. The S. S. cladded aluminium cast disc, soiled guide rails; helical gear housing provides a serials and noiseless performance for a long time.
The Packing conveyor belt is having stainless steel Table Top with moving PVC coated canvas belt in the centre. Tabletop is fixed to the same structure made out of S. S. square pipe & supported on adjustable bolts. Tabletop is of 9 inches working space on both side of the conveyor belt for final visual inspection & packing into the box.
Container inputs in turn table by manually or automatic will rotate on disk of turn table and exit through outlet, during rotation of Container will guided by a SS strip, which will guide the Container towards outlet path. The variable pitch pulley ensures total and finer synchronization for incoming and out-going Glass Containers.
The conveyor belt brings the container or products from the labelling/blister/strip machine, operator in turn pickup These bottles/products & visually inspect the bottles/products & doing necessary action like primary packing, secondary packing, picking & placing at proper place.
Automatic Screw Capping Machine is versatile, self-supported on stainless steel leg with height adjustable adjustment system. The machine is precision built on sturdy welded steel frame completely enclose in stainless steel sheet and doors are providing to facilitate the servicing of machine.
The feed container moving on conveyor belt are feed into an in-feed star wheel, bringing the container below the sealing head in the subsequent indexing part, mean while the rotating head pickup a cap from the cap star wheel which is receiving from delivery chute of cap filling bowl, where the body and the neck of the container are positioned below the rotating head, where the sealing head is performing perfect operation of sealing, rotating head is design to seal container according to pre-set torque.
Cotton inserting machine can automatically cut and insert cotton into containers quickly and accurately. The machine is designed with a programmable logic controller (PLC) and novel high precision electronic positioning system. It features variable frequency control of mainframe speed. It possesses many protective functions. For example, it will automatically stop when bottle or cotton is absent or bottles are jammed. The product is well up to GMP requirements
Technical Specification
Bhagwati tablet counting and filling machine adopts advanced vibration and multi-channel feeder, computer control, dynamic scan counting, transfer the bottle automatically, system test automatically. The machine With Stop automatically function and other advanced technology. This machine designed with GMP standard. Compose the light, electric machinery to one set, which is suitable for tablet or capsule counting and filling in pharmaceutical or food business.
Technical Specification of Tablet Counting And Filling Machine
| Model | Unit | SB-U-15 Automatic Suppository Filling Machine |
|---|---|---|
| Capacity | PCS/Hour | 18000-23000 (depending on producing) |
| Total Power | KW | 7.5Kw |
| Voltage, frequency | V | 3PH 380 +/-10% 50Hz |
| Dose per unit | ML | 0.5~5 (depending on product) |
| Deviation | % | ï¼±2 |
| Suppository shape | N/A | Bullet, torpedo, duck-mouth ect (depending on product) |
| Adapting | N/A | Fatty acid glycerin,gelatin,glycol,etc., (depending on product) |
| Volume | L | 50 |
| Air pressure | Mpa | More than 0.6 |
| Air consumption | m3 | 1.5 |
| Water consumption | N/A | 50kg per circle |
| Total weight | KG | 2600 |
| Machine dimensions | MM | SB-U: 4000*3500*2000mm |
Automatic Auger Type Dry Syrup Powder Filling Machine is a compact model used for filling Dry Syrup Powder in bottles.
The incoming dry bottle sterilized is fed through the in feed Turn Table with suitably guided on the moving delrin flat conveyor belt at the required speed for feeding. There are two separate filling head mounted on machine top plate in the same line. When bottle reaches to the first filling station, it will be held by the pneumatic bottle holder. Immediately it will be sensed by the bottle sensor as soon as it gets signals from sensor magnetic clutch starts to rotate which is mounted on auger shaft. It will fill the desired amount of powder to the bottle through auger, where rotation time is previously saved in PLC control. After filling of first bottle pneumatic piston goes back and release the first bottle to move on conveyor, By the same time second bottle also moves along with the first bottle in empty condition. In second filling head same operation will be performed but this time second bottle get filled and first bottle moves further for next operation. The main advantage of this machine is Pneumatic bottle holding system is directly connected with Auger rotation, so till bottle get filled with powder as per set value pneumatic system will not going to release the bottle.
Technical Specifications of Auger Type Dry Syrup Powder Filling Machine
| Model | SBAF-60 | SBAF-D-100 |
|---|---|---|
| Direction | Left To Right. | Left To Right. |
| Production Rate | Up to 30 to 40 Bottles / Min | Up to 60 to 80 Bottles / Min. |
| Fill Capacity | 10 grms to 50 grms. (with different set of Auger and funnel) Fill range depending upon Bottle opening and bulk density of powder. | 10 grms to 50 grms. (with different set of Auger and funnel) Fill range depending upon Bottle opening and bulk density of powder. |
| Accuracy | ± 2% depending upon consistency and the Uniformity of bulk density of powder under controlled level of Humidity (i.e.35%) | ± 2% depending upon consistency and the Uniformity of bulk density of powder under controlled level of Humidity (i.e.35%) |
| No. of Heads | Single | Two |
| Electrical Supply | 1.00 HP For Main Drive. 0.25 HP for conveyor | 2.00 HP For Main Drive. 0.25 HP for conveyor |
| Power Requirement | 440 Volts, 3 Phase (4 wire System) 50 Hz. | 440 Volts, 3 Phase (4 wire System) 50 Hz. |
| Height of Conveyor | Adjustable from 850 To 900 mm | Adjustable from 850 To 900 mm |
| Dimensions | 1524 mm (L) X 1105 mm(W) X 1800 mm (H) | 2200 mm (L) X 1102 mm (W) X 1817 mm (H) |
| Net Weight | 400 KGS. (Approx.) | 550 KGS. (Approx.) |
| Gross Weight | 600 KGS. (Approx.) | 800 KGS. (Approx.) |
| Bottle Diameter | 25 mmTo 70 mm MAX. | 25 mm To 70 mm MAX. |
| Height | 55 mm To 110 mm. | 55 mm To 110 mm. |
| Pneumatic Air | Filtered, oil free, sterile low pressure AIR at 5 kg / cm2 | Filtered, oil free, sterile low pressure AIR at 6 kg / cm2 |
Bhagwati Pharma is one of the most experienced storage vessel fabricator for biopharmaceutical and pharmaceutical industries in India. Our storage containers accurately maintain the temperature of the material inside it. Our skilled professionals are dedicated for building and finishing stainless steel mixing tank. We have wide range of SS containers in both Jacket and Plain form. Our jacket stainless steel mixer maintains the heating and cooling of material in it.Bhagwati Pharma provides high quality stainless steel tank with accurate result at very affordable price.
The Storage Tanks and Jacketed Vessels manufactured by us Shree Bhagwati Machtech (India) Pvt. Ltd are capable of satisfying your specific requirements. We also build storage vessels with customized designs and our tanks are available in diverse sizes with various storage capacities. Our storage tanks have a capacity of storing almost 100 to 25000 liters of liquid.
Storage Tanks and Jacketed Vessels are used to manufacture or store high quality liquids and solutions required by different industries like Pharmaceuticals, Chemical and Cosmetics etc. It can be provided either jacketed or non-jacketed versions. It can be also available in electric and steam heated versions. The storage tanks and jacketed vessels can be designed in different rage like, 100, LTR TO 25000 ltrs in any shape and size as per clients requirements.
The storage tanks and jacketed vessels, specially used in the pharmaceutical indutry, can either be horizontal or vertical in their orientation. Horizontal storage vessel is generally mounted on stands or saddles and have an access port either at the bottom or at the top. Vertical storage tanks are erected vertically and have access ports at bottom. These specialized tanks can either be placed above or underground, depending on the construction of the storage facility. The thickness of wall of these tanks/vessels also determine their application or use; while single wall storage tanks can be used for general application, double walled tanks/vessel are used for high pressure considerations. The Pressure vessels are designed to operate at above normal pressure
The Automatic 128 or 168 Rotary Monoblock Dry Syrup Powder Filling with Capping Machine is suitable for Glass, Plastic, PET, HDPE, and LDPE Bottles with maximum speed of 100 Bottles per minute depending on Powder Fill Volume, Type of Powder, Bottle Diameter and Bottle Neck Diameter.
Machine in Stainless Steel Finish with heavy duty frame structure with S.S, Cladding. All parts coming in contact with Powders are made from SS316 Materials and HDPE Funnels.
The Machine works on proven time tested Vacuum and Air Systems to Fill powder in Bottle achieving higher speed and higher accuracy. Machine with unique Bottle Lifting and Neck Holding system avoid spillage of powder on bottle shoulder, neck and body keeps bottle clean and also avoid wastage of powder.
Machines require small area due to Monoblock design with Filling and capping operation. Machine with complete synchronization of Bottle Infeed Star Wheel, Powder Wheel movement and out feed Star wheel as well as capping operation for smoother operation. Machine with Rotary Bottle Moving system ensures very high speed powder filing through independent moving funnel along with bottles for greater speed and performance without compromising speed and fill accuracy. Machines with unique vibratory system inside the funnel helps filling of semi free flow type powder at higher speed.
Machine can be used for ROPP (Alum. Cap) as well as Screw Cap with the help of change parts. However for common application of ROPP Cap and Screw Capping on same machine, please ensure that the thread of Screw Cap should not have more than 1.5 turn for Capping, for separate application any type of Cap can be used without limitation.
SHPF-100 Automatic Monoblock Dry Syrup Powder Filling Cap Sealing Machine is a Compact machine used for filling and sealing of Dry Syrup in bottles.
The incoming dry container (sterilized and siliconised) are fed through the infeed Turn Table with suitably guided on the moving delrin flat conveyor belt at the required speed for feeding to the feed worm for correct spacing between two bottles and get enter into the infeed starwheel, which will be transferred below funnel, 16 nos. of funnel is mounted on round plate and powder filling head is mounted from centre pipe, which gives the flexibility to adjust position of wheel as per requirements and consumes less space on machine. Machine will be having a lifter assembly on base of bottom plate, when bottle come below funnel, bottom platform will lift the bottle and insert the bottle tight fit inside funnel. The sterilized powder is stored in to powder hopper is agitated by pair of mechanical agitators for maintaining consistency and uniform bulk density, powder wheel rotates at the pre-determined speed below the powder hopper with practically no clearance. Powder wheel consist of Piston in each port and behind the powder wheel and vacuum plate is provided there is no clearance between powder wheel and avacuum plate due to back spring pressure. Precise volume of powder is sucked in to the port of powder wheel during vacuum according to the piston length different fill size can be achieved. The excess powder is doctored off by a doctor blade, now doctor blades can be adjusted from outside also without removing powder hopper, when powder wheel indexes further and remain in the port due to the vacuum till it reaches just vertical position. The time dose of Compressed air, sterilized low pressure air or Nitrogen Gas sequentially flushes out powder from the port of powder wheel in to the funnel. Funnel will be equipped with square rod to break the solid slug of powder and powder will start to fill inside bottle, which is moving along with funnel. In this model Bottle is getting around 5 to 6 second filling time. Bottles further move with funnel and reaches to exit starwheel, which is infeed starwheel for eight head ROPP cap sealing machine, while rotating with startwheel bottle picks up the cap from exit end of chute, ROPP caps kept in orientation unit, automatically orient caps in right direction before entering into delivery chute. And Bottle is entering below the sealing head, consisting of total four rollers, Two rollers properly Skirts, Spins and Seals the cap and simultaneously another two roller performs perfect threading according to bottle neck diameter. After sealing operation, sealing head moves upward with help of cam and bottle enters into exit starwheel. Move further on conveyor belt for next operation.
The Bhagwati make Automatic Volumetric Liquid Vial Filling with Rubber Stoppering Machine is suitable for Round Vials with maximum speed of 240 Vials per minute. The vial filling machine can give Maximum speed of 240 Vials per minute depending on nature of Liquids, Vial Neck Size and Fill Volume. Vial filling machine construction in fully Stainless Steel finish including machine frame structure. Machine with built-in Turn Tables at In-feed and Out-feed with individual drives to match the speed of incoming and outgoing vials for smoother operation. All parts coming in contact with Liquids and Rubber Stoppers are made from SS 316 Materials.
Technical Details of Volumetric Linear Vial Filling Machine
| Model | SBLF-100 | SBLF-150 | SBLF-200 |
|---|---|---|---|
| Output / Hour* | 2400 to 6000 | 3600 to 9000 | 5000 to 12000 |
| Direction of Movement | Left to Right | ||
| Number of head / Syringe | 4 Nos. | 6 Nos. | 8 Nos. |
| Fill Size*** | 1 ml to 100 ml | ||
| Electrical Specification** | |||
| Main Motor | 1 HP / 415Volts / 50 Hz. | 1.5 HP / 415Volts / 50 Hz. | |
| Cap Feeding Bowl | 0.5 HP / 415 Volts / 50 Hz. | ||
Specification of the equipment machines basics :
The semi automatic cap sealing machine is precision built on sturdy welded steel frame completely enclose in stainless steel sheet and doors are provided to facilitate the servicing of machine.
Require manually feeding & unloading container, where the body and the neck of the container are positioned below the rotating head, and sealing head is performing perfect operation of sealing.
BHAGWATIs Automatic Screw Capping Machineis versatile, self-supported on stainless steel leg with height adjustable adjustment system. The machine is precision built on sturdy welded steel frame completely enclose in stainless steel sheet and doors are providing to facilitate the servicing of machine.
The feed container moving on conveyor belt are feed into an in-feed star wheel, bringing the container below the sealing head in the subsequent indexing part, mean while the rotating head pickup a cap from the cap star wheel which is receiving from delivery chute of cap filling bowl, where the body and the neck of the container are positioned below the rotating head, where the sealing head is performing perfect operation of sealing, rotating head is design to seal container according to pre-set torque.
Automatic Screw Capping Machine is versatile, self-supported on stainless steel leg with height adjustable adjustment system. The machine is precision built on sturdy welded steel frame completely enclose in stainless steel sheet and doors are providing to facilitate the servicing of machine
The feed container moving on conveyor belt are feed into an in-feed star wheel, bringing the container below the sealing head in the subsequent indexing part, mean while the rotating head pickup a cap from the cap star wheel which is receiving from delivery chute of cap filling bowl, where the body and the neck of the container are positioned below the rotating head, where the sealing head is performing perfect operation of sealing, rotating head is design to seal container according to pre-set torque.
Automatic Screw Capping Machine is versatile, self-supported on stainless steel leg with height adjustable adjustment system. The screw capper machine is precision built on sturdy welded steel frame completely enclose in stainless steel sheet and doors are providing to facilitate the servicing of screw capper machine.
The feed container moving on conveyor belt are feed into an in-feed star wheel, bringing the container below the sealing head in the subsequent indexing part, mean while the rotating head pickup a cap from the cap star wheel which is receiving from delivery chute of cap filling bowl, where the body and the neck of the container are positioned below the rotating head, where the sealing head is performing perfect operation of sealing, rotating head is design to seal container according to pre-set torque.
BHAGWATIs Automatic Aluminum Cap Sealing Machineis versatile, self-supported on stainless steel leg with height adjustable adjustment system. The machine is precision built on sturdy welded steel frame completely enclose in stainless steel sheet and doors are providing to facilitate the servicing of machine.
The feed container moving on conveyor belt are feed into an in-feed star wheel through In-feed worm, star wheel bringing the container below the sealing head in the subsequent indexing part, mean while the vial pickup a cap from the delivery chute of cap filling bowl, where the body and the neck of the container are positioned below the rotating head, where the sealing head is performing perfect operation of sealing.
BHAGWATIs Automatic Aluminum Cap Sealing Machineis versatile, self-supported on stainless steel leg with height adjustable adjustment system. The machine is precision built on sturdy welded steel frame completely enclose in stainless steel sheet and doors are providing to facilitate the servicing of machine
The feed container moving on conveyor belt are feed into an in-feed star wheel through In-feed worm, star wheel bringing the container below the sealing head in the subsequent indexing part, mean while the vial pickup a cap from the delivery chute of cap filling bowl, where the body and the neck of the container are positioned below the rotating head, where the sealing head is performing perfect operation of sealing.
BHAGWATIs Automatic Aluminum Cap Sealing Machineis versatile, self-supported on stainless steel leg with height adjustable adjustment system. The machine is precision built on sturdy welded steel frame completely enclose in stainless steel sheet and doors are providing to facilitate the servicing of machine.
The feed container moving on conveyor belt are feed into an in-feed star wheel through In-feed worm, star wheel bringing the container below the sealing head in the subsequent indexing part, mean while the vial pickup a cap from the delivery chute of cap filling bowl, where the body and the neck of the container are positioned below the rotating head, where the sealing head is performing perfect operation of sealing.
Automatic Measuring / Dozing Cup Placement & Pressing machine is highly efficient machine with elegant look, consists of conveyor, vibrator, feed worm, container holding star plate, & pressing plate. All the exposed parts of the unit are in S.S., chrome platted or cladded with S.S. The machine is precision built on sturdy welded steel frame completely enclose in stainless steel sheet and doors are provided to facilitate the servicing of machine.
The feed container moving on conveyor belt are feed into an In-feed star wheel through In-feed worm, star wheel bringing the sealed container below the pressing plate, mean while the sealed bottle pickup a cup from the delivery chute of bowl, where the body and the neck of the container are positioned below the pressing plate, where the pressing plate press cup gradually & performing perfect operation of cup pressing.
Automatic Measuring / Dozing Cup Placement & Pressing machine is highly efficient machine with elegant look, consists of conveyor, vibrator, feed worm, container holding star plate, & pressing plate. All the exposed parts of the unit are in S.S., chrome platted or cladded with S.S. The machine is precision built on sturdy welded steel frame completely enclose in stainless steel sheet and doors are provided to facilitate the servicing of machine.
The feed container moving on conveyor belt are feed into an In-feed star wheel through In-feed worm, star wheel bringing the sealed container below the pressing plate, mean while the sealed bottle pickup a cup from the delivery chute of bowl, where the body and the neck of the container are positioned below the pressing plate, where the pressing plate press cup gradually & performing perfect operation of cup pressing.
AThe Automatic Linear Measuring Cap Pressing/ Cup Placement/Cap Pressing Machine Model SBCPP-300. Machine is suitable for Round or other shape of Glass, Plastic, PET, LDPE, and HDPE Bottles with maximum speed of 300 Bottles per minute depending on Bottle Diameter, Bottle Height, Bottle Shape and Measuring Cap Size.
Machine with special Linear Design with No Change Parts system for Change in Bottle Size. Machine with Totally Synchronized Front and Back Bottle Holding Belt with Top Stabilizing and Cap Pressing Belt System.
Specially Machine construction in Stainless Steel finish including machine M.S. frame structure with Stainless Steel Cladding/Enclosures. Machine is ideal for application in Pharmaceutical, Food, Pesticides, and Cosmetic & Other Industries. Machine with user friendly operation to handle various type and size of bottles.
The Machine is equipped with Orientation type Cap Feeder or Vibratory type Bowl Feeder depending on cap shape and size for continues feeding of Measuring Cap for online operation on any liquid of powder filling line. Machine suitable for various sizes of Bottles and Measuring Cap with the help of change parts. Machine is suitable for application in Pharmaceutical and other industries requiring higher production speed on automatic online operation.
The feed container moving on conveyor belt are feed into an In-feed star wheel through In-feed worm, star wheel bringing the sealed container below the Cap Pressing plate, mean while the sealed bottle pickup a cup from the delivery chute of bowl, where the body and the neck of the container are positioned below the Cap Pressing plate, where the Cap Pressing plate press cup gradually & performing perfect operation of cup /Cap Pressing.
AThe Automatic Linear Measuring Cap Pressing/ Cup Placement/Cap Pressing Machine Model SBCPP-300. Machine is suitable for Round or other shape of Glass, Plastic, PET, LDPE, and HDPE Bottles with maximum speed of 300 Bottles per minute depending on Bottle Diameter, Bottle Height, Bottle Shape and Measuring Cap Size.
Machine with special Linear Design with No Change Parts system for Change in Bottle Size. Machine with Totally Synchronized Front and Back Bottle Holding Belt with Top Stabilizing and Cap Pressing Belt System.
Specially Machine construction in Stainless Steel finish including machine M.S. frame structure with Stainless Steel Cladding/Enclosures. Machine is ideal for application in Pharmaceutical, Food, Pesticides, and Cosmetic & Other Industries. Machine with user friendly operation to handle various type and size of bottles.
The Machine is equipped with Orientation type Cap Feeder or Vibratory type Bowl Feeder depending on cap shape and size for continues feeding of Measuring Cap for online operation on any liquid of powder filling line. Machine suitable for various sizes of Bottles and Measuring Cap with the help of change parts. Machine is suitable for application in Pharmaceutical and other industries requiring higher production speed on automatic online operation.
The feed container moving on conveyor belt are feed into an In-feed star wheel through In-feed worm, star wheel bringing the sealed container below the Cap Pressing plate, mean while the sealed bottle pickup a cup from the delivery chute of bowl, where the body and the neck of the container are positioned below the Cap Pressing plate, where the Cap Pressing plate press cup gradually & performing perfect operation of cup /Cap Pressing.
Fully Automatic, User Friendly, Sticker (Self-Adhesive) Labelling Machine, Suitable to apply accurate Labels on Double Side (Front & Back) of Flat / Oval / Square shaped products having PET, Plastic, HDPE, LDPE, Glass or any other surface.
The Fully Automatic Front Back Sticker Labeler Machine incorporates latest sophisticated MicroProcessor Controlled Stepper Motor Drive, Fiber Optic Label and Container sensing system. SBMA-120F Sticker Labeling machines are 100% User Friendly, Virtually Maintenance Free and does not require Data Inputs for Label Size.
Shree Bhagwati Machtech (India) Pvt. Ltd emerges as the leading manufacturers of Shrink Sleeve Label Applicator having an input power of 2.0KW. By offering stable transmissions for packaging bottles, the machine finds perfect applications in the beverage, dairy, cosmetic and pharmaceutical industries. Our machine offers high precision, thus resulting in the accurate label casting.According to the characteristics of the shrink wrapping machine, we make improvement from the aspects of mechanical structure, circuit design, and intellectual control to improve the production efficiency. It can satisfy the demands of various beverage manufacturers as well as reduce the production cost for the clients and improve the production rate.Configuration of BHAGWATI SHRINK SLEEVE APPLICATOR -shrink sleeve Machine:
Applicable Varieties for wrapping Label:With a breakthrough of the traditional technology of casting label, the equipment can integrate three to four trapping label machine varieties into one. It only needs to change the modules to realize the casting label of different varieties & types.
Technical Specifications
Bhagwati Shrink-Sleeve Labelling Machine high speed uses newest shrink technology with MMI and PLC base control panel. The bary centre and base have been accurately design, even use this machine with high speed for long time machine running still very stable and smoothly.
Many model with all kind of speed selection from 50/minute to 200/minute and is suitable for wide range; it can be modified according to packages shape. Can meet, all kind of required no matter it is for cap or bottle. The machine is suitable for Pharmaceutical, food industries; it can be for health-food, medicines, Juices, Milk, Drinks, etc
Technical Specifications of Shrinkable Label Inserting Machine
We offer LVP IV bottle Leak check machine, IV bottle Inspection machine, IV bottle labelling machine, IV bottle Packing conveyor
IV BOTTLE LEAK TESTING MACHINE
IV bottle Leak testing machine pressure testing online thru rotating unit
IV bottle inspection machine , INSPECTION M/C for LVP IV BOTTLE
Top Side Labelling Machine, Top Label Applicator Application On Any Product
The same top side labellers model is used for FFS Ampoule cassettes for Top & Bottom labelling with special configuration.
PACKING CONVEYOR BELT.
ROLLER CONVEYORS
Traditional sugar coating is performed in what is generally described as a conventional coating pan. However, the desire to reduce the time needed for the sugar coating process has led to the trend towards side-vented pans, which can be modified to introduce the sugar syrup via a dosing bar, rather than spraying the tablets as with film coating. Sugar coating liquids used in preparing sugar coated tablets contain binders such as gelatin or gum arabic so as to increase strength of the sugar coating layer or to increase bonding strength between an uncoated tablet and the sugar-coating layer.
Film coating is the largest sector of the tablet colouring market in Phrama industries. Film coating techniques reduce process times, offer greater control over coating parameters and provide more opportunity for innovation. Film coating involves the deposition of a thin polymer layer onto the tablet core, usually by a spray method. Conventional sugar panning equipment can be used but more specialized machinery, such as the side-vented pan, is used to control the processing conditions, which include temperature, humidity, spray rate and mixing of the tablet bed. Industry developments have led to the simplification, where possible, of film coating systems for shade criteria, microbial control and processing improvements.
