Tandem cylinders have two pistons working in two different chambers but are connected by a common piston rod. The air is supplied to both the chambers simultaneously. Thus the tandem air cylinders are able to achieve twice the draw bar pull compared to the single chamber cylinder.

Almost all the components in these cylinder are made of light weight, high strength aluminium alloy, except for the pistons and the piston rod which are made of alloy steel.

These cylinders are ideal for machines where hydraulic systems are not available.

Cricle making machine is used to make various type of round bends in Section, Flats, Bars, Angles, Tees, Round, Square, Rectangular, Pipe & channels etc & it is Generally used for R > 5x. Its applications are Pipelines, Furniture, Doors/Window, Staircases, Railings, Table/Chairs/Cots, Heavy Duty Springs, Coil making, Arches Garden/Building, Artistic/Decorative shapes, Bridges, Amusement Parks, Dairy Equipment, Decorative Grill, Auto Parts, Coach Bodies, Boilers, Pharmaceutical/Chemical, Plants, Bicycles, Heat Exchanges, Stoves, Conveyers, Playground equipment, Garden equipment, Light fittings, Railway Tracks, Ship building, Defence equipment, Structural Fabrication, Hospital Cots etc.

A Forged Steel Hardened Jaws/Handle and strong flatlinks chain is mostly used in trench for all types of pipe fitting jobs, from oil field to general work.

Features

• Reversible type pullers.
• Drop forged chrome plated steel.
• Forged steel auto black finish.
• Available in 3 legs as well as 2 legs.
• Adjustable legs for internal and external pulling of gears and bearings ect.
• Size available 3" to 12" in drop forged. Size available 3" to 24" in forged steel.

Manual operated for mild steel , copper, brass and aluminum bar and strip bending .

For long Radius thin wall thickness bending 6 to 22 mm Copper, Aluminium, Stainless Steel and any light gauge tube up to 180⁰.

• Excellent for small line cleaning
• Clears 19 mm to 60 mm lines up to 35' long.
• Light weight, easy to use, not set up required.
• Forward and reverse motion by reversible electrical hand tool.
• Drum capacity 15 Meters of 8 mm or 11 mtrs of 10mm cable.

• Hand Spinner
• Clears 19 mm to 35 mm lines up to 15' long.
• Light Weight Aluminium Sheet body, easy to use, not set us required
• Works through traps and bends in sinks, tubs, lavatories, urinals, vent pipe etc.
• Totally enclosed cable container

This under pressure Drilling and Taping Machine is used to drill and tap in water line while under preserve. It makes the hole and tap up to 2 inches single operation without electricity. It covers the range size 4" to 48" of cast iron , ductile iron and M.S. Pipes . Its superior quality seals stop the water pressure while drilling. it is packed in metal box.

Compact structure made of cast aluminium alloy light weight body, easy operation, good safety & low noise, reffering to the international advanced technology suitable for threading of pipe thread BSPT & NPT thread on request. Profilling die head for standard taper pipe thread. Dependable clamping, fee from slip and deformation. Self lubricating die head & two more additional functions are pipe cutting & De-burring of pipe. There are disassemble stand & wheel stand.

Lapping Platesare made from close grained cast iron in round as well as in square pattern. Serrations are 3mm wide, spaced 25mm approx. Hardness - 200 BHN. These are

Used to lap wide range of materials like hand lapping of nylon, plastic, ceramics and other non ferrous materials.

Adjustable Pipe Die Stock is a economical , Most Convenient , and most versatile threader sets . Its adjustment can be set on different type of pipes . Parallel threads always have clearance for pipe fittings.

INDIA's first tapping & drilling machine (Ratchet drill machine) Manufactured with latest & advance technology . it is a multipurpose machine so it can complete the job of drilling and threading simultaneously on cast iron pipe , duck tile iron pipe M.S. Pipes reaming sleeves for drilling in girder , channel & poles etc.

Features:-

• Used for marking & transferring measurement.
• Ground base for accurate reference surfaces.
• V groove on the front end which allows the spindle to adjust to any angle above or below the base.
• V groove in the base for cylindrical work.
• A very positive fine adjustment through a rocker arm that makes smooth & accurate setting.
• Grooves on the side of the base for a sure & easy grip.
• Dial indicator can also be used.Two gauge pins facilitate easy linear marking.

Features:-

• Used for holding jobs together.
• Made from hardened steel & precision ground for parallelism.
• Designed for maximum strength & rigidity.
• A retaining strip hold loose job in alignment when clamp is tightened or loosened.
• The ends of the jaws are rounded to permit clamping under shoulder or in recess.

Features:-

• Used with boring bar presenting of cutting tool.
• Change in setting of the tool measures variation in bore dimension.
• Suitable clamp is provided for holding dial indicator.
• Powerful magnet with ON-OFF facility.
• "V" is hardened & ground within 5 microns.
• The included angle of V is 90.
• Hardness 52 - 56 Rc.
• Can be manufactured as per customer's requirement.

Features

• Used for Grinding, Light Milling, Drilling & Inspection of round & square jobs.
• Accuracy for Flatness, Squareness & Parellelism within+0.005 mm.
• ON-OFF is done by rotation of handle.
• Provides angle reference of 45, 90and 120.
• strong magnetic pull on all ground portions.
• Hardened strips provided on all working surfaces in hard blocks for wear resistance.

Features:-

• Used for Grinding, Light Milling, Drilling & Inspection of round & square jobs.
• Accuracy for parallelism is within +0.005mm.
• Provided with ON-OFF switch except for 1" block.
• Supplied in perfect matched pair. Harden Strips provided in hard pair.

RE Magnetic Separators are useful in processing industry for removing weakly magnetic or fine Iron impurities from Minerals, Refractories, Food Products, Glass, Slag, Ores etc.

For long radius heavy gauge bending ideally suitable for 'C' class (Sch. 40 pipe) size 3/8" to 6" gas , water steam DIN 2440/2441up to 90 degree

Features:-

• Used for balancing purpose.
• Compact design.
• Strong Rare Earth magnets.
• One side magnetic face.
• Weight is engraved.

Features:-

• Used for accurate & quick angle setting during Inspection, toolsetting & machining .
• Made from special quality alloy steel material.
• Hardness 60+2 Rc.

Features

• Used for supporting the job.
• Made from good quality alloy steel material.
• Safe & reliable adjustment of height.
• Locknut for adjustment.
• Can be used with different pads.

The Vertical Dividing Head can be conveniently employed for indexing up to 12 divisions and is ideallysuitablefor operations on drilling, jig boring and grinding machines where accuracy is indispensable. It is totally enclosed arid consists of:

• A close grained heavy-duty cast iron base with Brinell hardness of 180 and above, and machined to H7 tolerances.
• A dividing plate with 12 notches made of heat-treated alloy steel, hardened and ground.
• A three-jaw self-centringchuckof 39 mm in diameter with bore in spindle making it suitablefor holding jobs up to 19mm.
• A single indexing and clamping lever. By actuating the indexing lever, the dividing plate can be unlocked when the upper part is free to rotate through therequiredarc. As soon as the indexing lever is released, the indexing and lockingareautomatically done.

Features:-

• Used for Precision measurement, setting of angles.
• Made from high quality alloy steel.
• Accuracy for Flatness, Squareness & parallelism is within 0.005mm.
• Centre distance between rollers is within+0.005mm.
• Hardness - 60 + Rc & Tempered Accuracy as per IS Standard IS - 5259 - 1987.

Gear Testing attachement is unique in design and ment for inspecting concentricity and commulative errors of Gears with respect to gear axis.

Features

• A twin magnetic unit possessing a multi angle setting for Welding.
• It can be quickly locked at any angle by turning of wing nut, thus providing the simplest & most rapid means of clamping together.
• When Connected in series, complex arrangement is possible.

Flaring tools basically meant for soft pipe viz. Copper, Aluminium, Brass Tubing. It gives uniform & smooth flairs with minor force, even on large diameter of tubing. Its hardened steel flaring cone, gives uniform flare walls 45. size of tubing holes clearly marked on the bar & its 2 bars cover 9 sizes of flares & 5 swaging adopters for 3/16", 1/4", 5/16", 3/8", 1/2", 5/8", & 3/4" tubing sizes.

Features:-

• Used for lifting & handling of steel plates, heavy block & castingsas well as heavy round or cylindrical parts.
• The 1 : 3 safety factor of the recommended load to the Test loadensures use at optimal working conditions even with Substantial air gaps & surface conditions.
• Compact design, strong magnetic pull, total work safety
• Easy operated lever for ON-OFF.
• Spring loaded block at side for safety feature.
• Suitable for Flat & Round jobs.
• No damage on job during operation.

INDER HYDRAULIC POWER PRESS (MULTIPURPOSE) are manufactured under the most favorable manufacturing conditions under the strict supervision of our highly skilled workforce supported by qualified engineers. Our manufacturing range of Hydraulic power press is from 50 tons to 500 tons. capacity. Presses are motorised with power pack operated for deep drawing, bending, blanking, straighting, shearing, cutting & die pushing. These Hydraulic vertical down stroking compression moulding press presses have welded steel fabricated structure. The pressing cylinder is from forged steel accurately machined & ground . Piston is made of forged steel. It is machined, ground & hard chrome plated to ensure higher seal life. PU seals of high quality used in the cylinders.

• Economy auger operates in Basins, drains & toilet up to 3 fts.

Features

• Made of high grade ductile iron casting.
• Useful for wood working and metal working.
• Fine thread screw.
• Strong swivel pad applies pressure evenly.

BRIEF SPECIFICATIONS

Features

• Drop forged G clamps are very essential for fabrication work and metal working.
• Deep throat to hold the job properly.
• Available in copper finish fine thread screw as well black finish fine thread screw.
• Strong swivel pad to adopt any angle.

• A compact machine for intitutional, commercial or residential cleaning.
• Cleans from 32 mm to 100 mm drain lines up to 50' long
• Optional power feed arrangement, advances and retrieves the cable manually feeding
• Portable, light weight, easy to use, no set up required.
• Drum cap. 75' of 3/8" cable or of 1/2" cable.
• Accessories four piece of cleaning tools.

Gripping through manual screw adjustment and rigid clamping through Pneumatic Machine vises.

In-built sophisticated piston mechanism.

Clamping power of 4500 N at 7 bar (100 psi) air pressure.

Groundand hardened tool steel jaws for perfect parallelism.

Thread rolled screw with lock nut to clamp various length jobs. Steel moving jaw rules out pressure drop and air leakage.

Features:-

• Used as holding device for dial indicator.
• heavy & rigid construction.
• Column can move to & fro to full base length.
• Fine adjustment for accurate setting.
• Both faces of base can be used.

em manufacturesClamping nuts and Spannersof various sizes and shapes which are listed below. We can supply customised clamping nuts and spanners according to the customers' requirements

The advantages ofGem Clamping nutsandspannersare

The benefits ofGem Clamping nutsandspannersare

Compact tool for threading small pipes , suitable for use in difficult corners and close to walls . The Die Heads have large clearance holes to prevent chips out . Standard Tapper Pipe Threading in one cut . Die Heads are inter-changeable with other world popular brands. Compact Light weight packed in Metal and Plastic carrying box .

• Straight Edges are made Jrom close grained Cast iron conforming to Grade-20.
• Hardness 170-220 BHN.
• Castings internal Stresses are relieved either by natural ageing or by artificial seasoning.
• Straight Edges are finished by hand scrapping.
• Straight Edges have been designed well and ribbed in the best manner to retain thier accuracy under varying conditions andareas light as possible without sacrificing rigidity.
• Wooden Cover is provided with each Straight Edge to protect the working surface from rust and dust.
• Straight Edges are offered in two grades Grade-I and Grade-II
• All finished surfaces of Straight Edges are protected against climatic conditions by a suitable protective coating.
