Viscon Fluid Heaters High performance fluid heaters
Provides excellent temperature conditioning for high solids coatings and high viscosity materials

Graco's Viscon heaters maintain optimal temperatures to provide consistent control of fluid viscosity. With a wide temperature operating range, Viscon heaters are excellent for any coating, sealant, adhesive or lubricant you need to pump.

Viscon HF High Flow Fluid Heaters
- Designed for high flow rates, with more power for faster material heating

Viscon HF Fluid Heaters for Explosive Atmospheres
- Developed to handle the highest viscosity coatings such as 100% solids epoxies coatings and epoxy fireproofing materials

Viscon HP High Output Fluid Heaters
- Offers high pressure (7250 psi/500 bar) for use with most pumps

Features:

Viscon HF High Flow Fluid Heater:
Spiral passages provide three times the flow rate of standard Viscon heaters
Efficient and powerful for faster material heating - gets the job done faster
Available in manual thermostat or externally controlled versions
Excellent for high solids coatings and protective coatings materials
Easy to clean and maintain
7250 psi (500 bar, 50 MPA)
Temperature operating range: 84 to 219F (29 to 104C)

Viscon HF Fluid Heaters for Explosive Atmospheres:
The patent-pending design has a triple-path spiral core that can be easily disassembled for cleaning.
Increased flow capacity: The Viscon HF has over three (3) times more flow capacity compared to the standard Viscon HP heaters.
Increased heat capacity: The Viscon HF heaters have 35% more wattage; 5400 watts compared to 4000W for the standard Viscon HP heaters.
Available in manual thermostat or externally controlled versions.
Cleanable and replaceable fluid core repair instead of replace.
7250 psi (500 bar, 50 MPA) pressure rating handles the highest pressure rating of Graco protective coating sprayers.
Temperature operating range: 84 to 219F (29 to 104C)
Same mounting configuration as standard Viscon HP heaters Easy to retrofit onto existing equipment.

Viscon HP High Output Fluid Heater:
Higher pressure for use with most pumps
Excellent for high solids coatings, adhesives or resins
7/16 in (11 mm) diameter fluid passages
Stainless steel design
Available in standard or explosive atmosphere versions
7250 psi (500 bar, 50 MPa)
Temperature operating range: 84 to 219F (29 to 104C)

el and cycle count sensors, and stop and start the pump
Optional Light Tower accessory is available to indicate system diagnostics

Materials:
Sealants
Mastics
Epoxy Sealants and Adhesives
Silicones

Applications:
Bulk Supply System
Medium-Viscosity Material Transfer
Adhesive Bonding
Automotive Hem-Flange Bonding
Roll Coating
Curtainwall
Thermal Management
Composites Open Molding
Resin Batch Blending
Resin Saturation
Prepreg Supply

Industries:
Automotive Trim and General Assembly
Powertrain
Body Shop Sealing
Automotive Electronics / Under the Hood
Automotive Composites
Wind Power - Blades
Chemical Manufacturing
Electronics Manufacturing
Furniture Finishing / Manufacturing

LineLazer V 5900 Airless Line Striper
The LineLazer V 5900 is designed for 2-gun professional stripers, delivering the most precise and consistent lines in the industry.

The LineLazer V 5900 continues to be the mid to heavy-duty striping solution for professional contractors who recognize the increased productivity this leader delivers. With its ability to use 1 or 2-gun airless paint guns there are no jobs too big or small for the LineLazer V 5900 large parking lots, city streets and everything in between.
Known for years by professional contractors for its productivity, the innovations of this new generation positions the 5900 to again exceed all expectations.

Features:
1.Standard Series Features:
EasyMark Gun Adjustment System
Simple guide mark system
Easy gun on/off, front/back
Perfect gun set up - every time
EZ Align Front Wheel System
Keeps unit tracking straight
Intuitive design
DualComfort Handle Bar System
Fits all users
Easy to adjust
Solid 4-bolt design
LiveLook Display with SmartControl
Tracks all aspects of the job
Real-time information

2.HP Automatic Series Includes All Standard Series Features PLUS:
Automatic Guns
Push button control for accurate stripes every time
Auto-Layout II
Cuts layout time in half
Exclusive Green Laser Guidance (country dependant)
Data Logging with J-Log System
On-board job information for proof of completion
On-Board Power
12V battery for all your accessory items

Material:
Road-Marking Paint

Applications:
Parking Lots
Road Striping
City Streets
Bike Paths
Intersections

LineLazer 130HS
Hydraulic Airless Line Striper
The LineLazer 130 HS is a workhorse hydraulic airless striper for everyday pavement marking.

The LineLazer 130HS is the ultimate hydraulic airless striping unit that contractors rely on for their most challenging striping jobs.
Professional striping contractors wanting hydraulic performance
and proven power cannot go wrong with the LineLazer 130HS.
As the preferred hydraulic striper for everyday jobs, it consistently delivers solid performance day in and day out.

Includes the following features:
EasyMark Gun Adjustment SystemSimple guide mark and gun placement system allows for perfect gun set up every time
High-capacity Cooling SystemKeeps the system running cool
Storage CompartmentStorage area for tips, guards and miscellaneous items
DualComfort Handle Bar SystemFits all users and is easy to adjust
EZ Align Front Wheel SystemIntuitive design keeps unit tracking straight
QuickSelect Gun SelectorChrome gun lever for ease of use and dependable operation
Honda EngineExcellent power and proven reliability
Endurance Paint PumpIndutrsy best performance and proven design with 25 years of success

Material:
Road-Marking Paint

Applications:
Parking Lots
Road Striping
Airports
City Streets
Bike Paths
Intersections

Industries:
Traffic Marking and Removal
Airports

LineLazer V 250DC
Dual Color Line Striping System
Spray two colors simultaneously with the LineLazer V 250DC.

Ideally suited for airports, municipalities, DOTs or anyone who needs to spray highlight lines or other dual-color striping.
The LineLazer V 250DC rewrites linestriping productivity and flexibility by spraying two colors simultaneously in patterns as wide as 36 inches (90 cm).

Features:
1.HP Automatic Series Features:
EasyMark Gun Adjustment SystemSimple guide mark and gun placement system allows for perfect gun set up every time
Automatic Gun Control SystemManual or automatic paint and bead gun control with a push of a button
Auto-Layout IIExclusive Green Laser Guidance cuts layout time in half (country dependant)
Data Logging with J-Log SystemOn-board job information for proof of completion
On-Board Power12V battery for all your accessory items
Dual Graco Hydraulic MotorsNo-Stall design provides uninterrupted performance
Dual Endurance Displacement PumpsProvides precise flow for a wide range of striping materials
Exclusive Self-Centering Front WheelProvides simpler operation
Front or Rear Gun MountUse up to six guns to create straighter long lines
Honda 13 hp GX EngineElectric start for ease of use

2.HP Reflective Series Includes All HP Automatic Series Features PLUS:
EZ Bead Pressurized System
Innovative bead tank with unmatched performance
Provides perfect bead embedment
Air valves to dial in starts and stops
Installed and ready to go
Dual Bead Tanks hold up to 240 lbs of beads (120 lbs each)

Material:
Road-Marking Paint

Applications:
Parking Lots
Road Striping
Airports
City Streets
Bike Paths
Intersections

Industries:
Traffic Marking and Removal
Airports

LineLazer V 250SPS
Self-Propelled Line Striping System
The LineLazer IV 250SPS is a stand-on line striping solution for improved visibility and razor sharp lines.

High performance striping with the exclusive automatic paint guns makes the LineLazer V 250SPS the preferred striper for professional contractors who demand hydraulic power.
This striper is ideal for large, heavy-duty line striping jobs including parking lots and road jobs.

Features:
1.HP Automatic Series Features:
EasyMark Gun Adjustment SystemSimple guide mark and gun placement system allows for perfect gun set up every time
Automatic Gun Control SystemManual or automatic paint and bead guns with the push of a button
Auto-Layout IIExclusive Green Laser Guidance cuts layout time in half (country dependant)
Data Logging with J-Log SystemOn-board job information for proof of completion
On-Board Power12V battery for all your accessory items
Graco Hydraulic Motor SystemNo-Stall design provides uninterrupted performance
25-Gallon (95 L) Paint HopperExtended striping time with large capacity hopper
Endurance Piston Pump SystemLong life pump provides precise flow for wide range of striping materials
Exclusive Self-Centering Front WheelProvides simpler operation
Rear Gun Mount SystemProvides straighter long lines
Honda 13 hp GX EngineElectric start for ease of use

2.HP Reflective Series Includes All HP Automatic Series Features PLUS:
EZ Bead Pressurized System
Innovative bead tank with unmatched performance
Provides perfect bead embedment
Air valves to dial in starts and stops
Installed and ready to go
Dual Bead Tanks hold up to 240 lbs of beads (120 lbs each)

Material:
Road-Marking Paint

Applications:
Parking Lots
Road Striping
Airports
City Streets
Intersections
Sports Field Marking

Merkur ES Spray Packages Air-Assist and Airless Spray Packages
Choose between air-assist and airless spray technologies in 15:1 or 30:1 ratios

The Merkur ES is one of the most efficient sprayers designed to use less material than the competition and to reduce air usage and pulsation.

Features:
Quick flush system requires less than 1 minute to flush
45% less material to fill the system than the leading competitors
2 to 10 years of proven reliability on key system components
Delivers a superior, consistent spray finish
Low profile spray package makes it easy to transport
Easily set and monitor air control, plus an integrated carrying handle for transport
Air motor provides consistent finishes with smooth, rapid changeover
Suction hose and strainer leaves less material in the supply container
Lightweight, flexible 1/8 in fluid hose reduces material and solvent usage

Material:
Solvent Based-Paint
Waterborne
Solventborne
Single Component
Varnishes
Lacquers
Acid Catalyst
Enamels

Applications:
Light Commercial Painting
Moderate Commercial
Heavy Commercial
General Metal Finishing-Pumping
General Metal Finishing-Spraying
Wood Finishing-Pumping
Wood Finishing-Spraying
Plastic Finishing-Pumping

Industries:
Furniture Finishing/Manufacturing
General Metal Finishing/Manufacturing
Wood Products Manufacturing
Marine
Railroads
Trucking
Fleets
Wood & Wood Products-Pumps
Wood & Wood Products-Spray guns
Heavy equipment Manufacturing

Merkur ES Spray Packages Air-Assist and Airless Spray Packages
Choose between air-assist and airless spray technologies in 15:1 or 30:1 ratios

The Merkur ES is one of the most efficient sprayers designed to use less material than the competition and to reduce air usage and pulsation.

Features:
Quick flush system requires less than 1 minute to flush
45% less material to fill the system than the leading competitors
2 to 10 years of proven reliability on key system components
Delivers a superior, consistent spray finish
Low profile spray package makes it easy to transport
Easily set and monitor air control, plus an integrated carrying handle for transport
Air motor provides consistent finishes with smooth, rapid changeover
Suction hose and strainer leaves less material in the supply container
Lightweight, flexible 1/8 in fluid hose reduces material and solvent usage

Material:
Solvent Based-Paint
Waterborne
Solventborne
Single Component
Varnishes
Lacquers
Acid Catalyst
Enamels

Applications:
Light Commercial Painting
Moderate Commercial
Heavy Commercial
General Metal Finishing-Pumping
General Metal Finishing-Spraying
Wood Finishing-Pumping
Wood Finishing-Spraying
Plastic Finishing-Pumping

Industries:
Furniture Finishing/Manufacturing
General Metal Finishing/Manufacturing
Wood Products Manufacturing
Marine
Railroads
Trucking
Fleets
Wood & Wood Products-Pumps
Wood & Wood Products-Spray guns
Heavy equipment Manufacturing

Xtreme-Duty Hose Airless High-Pressure Hose
For high-pressure spraying applications

Xtreme-Duty Airless High-Pressure Hose is designed to withstand the rigors of high-pressure spraying.
Its durable design meets exacting standards ultimately reducing downtime due to hose failure.

Features:
A complete line of hoses for all your high pressure spraying up to 7250 psi (500 bar)
Passes rigorous tests for quality and performance standards
Hose cover is chemical resistant withstands a variety of solvents, acids and bases
Hose cover stands up to sunlight, ozone, oxygen and extreme weather conditions
Color-coded by pressure to take the guesswork out of using the right hose

G15/G40 manual air-assisted spray guns deliver superior spray performance while improving transfer efficiency and reducing material usage.
G15/G40 manual spray guns have increased durability and efficiency.

AAF tip line is designed for soft spray and improved transfer efficiency
Longer-lasting needle packing even with abrasive materials
More robust aircap retaining ring threads
All tips have a ring to retain the tip in the aircap
Easier removal of the integrated gun fluid filter no threads or tools needed
G15 aircap indexing offers increased durability

G15/G40 Manual Spray Guns Technical Specifications
Maximum Working Fluid Pressure
Model G15: 1500 psi (10 MPa, 105 bar)
Model G40: 4000 psi (28 MPa, 280 bar)
Maximum Working Air Pressure: 100 psi (0.7 MPa, 7 bar)
Maximum Working Fluid Temperature: 110 F (43 C)
Fluid Inlet: 1/4-18 npsm*
Air Inlet: 1/4-18 npsm (R1/4-19) compound male thread**
Gun Weight: 16 oz (450 g)
Sound Pressure at 20 psi: 66.9 dB(A)
Gun Body: Forged Aluminum
Fluid Filter: 100 mesh
Trigger Pull: 3.9 lbs
Wetted Parts: SST, Carbide, Ultra High Molecular Weight Polyethylene, Acetal, PTFE, Nylon

Triton Pump Packages Fine Finish Spray Packages
Apply a high quality, decorative finish to wood and metal parts with this double diaphragm pump package

Triton is an air-operated diaphragm spray package that applies a high quality, decorative finish to wood and metal parts. It is a more effective alternative to traditional pressure pots and standard diaphragm pumps.

Supplies up to 35% extra air flow to gun for superior atomization
Saves material and time during flushing, priming and color changes
Delivers a consistent spray pattern and uniform film thickness
Sprays a wide variety of material viscosities
Reduces operator fatigue

Features:
High quality finish, low pulsation output and smooth pump changeover deliver a consistent spray pattern
Quick color changes and fast material refills save time and money
Rugged, stainless steel or aluminum construction pump handles a wide variety of fluids

Material:
Solvent Based-Paint
Solventborne
Single Component
Varnishes
Lacquers
Enamels
Latex
High solids
CARC
Metallics
Stains
Epoxies

Applications:
Light Commercial Painting
Moderate Commercial
Heavy Commercial
General Metal Finishing-Pumping
General Metal Finishing-Spraying
Wood Finishing-Pumping
Wood Finishing-Spraying
Plastic Finishing-Pumping

Industries:
Furniture Finishing/Manufacturing
General Metal Finishing/Manufacturing
Wood Products Manufacturing
Marine
Railroads
Trucking
Fleets
Wood & Wood Products-Pumps
Wood & Wood Products-Spray guns
Heavy equipment Manufacturing
Agricultural Equipments/Manufacturing
Automotive Manufacturing
CARC
Personal Recreation Vehicles
RVs
Aerospace Finishing
Forestry Equipments

Ambient Supply Systems
Bulk unloaders for ambient sealants, adhesives and other medium to high-viscosity materials

Graco Supply Systems reliably deliver one-component sealants, adhesives and other medium to high-viscosity materials from pails or drums to metering and dispensing systems.
For magnadrums & tote drums up to 1200 liter (300 gal)

The Uni-Drum supply system evacuates 300 gallon (1200 liter) magnadrums and other tote drums of the same size and capacity.
Pumps and transfers highly viscous materials from bulk drums with maximum efficiency
Built to work with other high pressure equipment to optimize material use

For large drums up to 200 liter (55 gal)
Graco D200 - For high-volume in-plant applications
Graco D200s - For heavy-duty, high-volume applications of high-viscosity materials.Provides more down-force for difficult-to-move materials

For pails up to 60 liter (16-gal)

For 20, 30 and 60 liter (5, 7, and 16-gal) pail sizes. Provides the same proven technologies as the larger systems, but with small NXT Air Motors.

Graco L20c - A lightweight, elevator ram on a cart
Graco S20 - For low-volume applications of medium to high-viscosity materials
Graco S20c - Same as the S20, but includes a cart
Graco D60 - Provides higher down-force and 60-liter pail capacity

For 1 quart (0.95l) or 1 gallon (3.79l) containers

The Graco DynaMite Pump utilizes the NXT air motor to provide the power necessary to move viscous materials from small containers.
Manual or automatic valve applications
Ideal for small manufacturing workcells and industrial workbench applications
Typical fluids handled:
Sealants and Adhesives
Potting and Heatsink Compounds
Encapsulants
Grease
Inks and Colorants

Features:
Industry-first controls give you immediate and important information at the touch of a button
Quick placement of drum or pail
Platen wipers can be replaced in seconds
Pump's quick-disconnect coupler, turbuckle mount and pump cartridge packings let you service the pump without removing it from the ram
High-quality, durable parts reduce maintenance time, maximize uptime

Materials:
Contact Cements
Sealants
Mastics
Epoxy Sealants and Adhesives
Silicones

Applications:
Bulk Supply System
Medium-Viscosity Material Transfer
Adhesive Bonding
Automotive Hem-Flange Bonding
Roll Coating
Curtainwall
Thermal Management
Composites Open Molding
Resin Batch Blending
Resin Saturation
Prepreg Supply

Industries:
Automotive Trim and General Assembly
Powertrain
Body Shop Sealing
Automotive Electronics / Under the Hood
Automotive Composites
Wind Power - Blades
Chemical Manufacturing
Electronics Manufacturing
Furniture Finishing / Manufacturing

Two-component spraying made easy and affordable
High-pressure performance for two-part high-solids coatingsA smart alternative to hand mixing

The Graco XP70 Plural-Component Sprayer is designed to pump, mix and atomize high to 100% solid coatings with superior results.
In addition, the XP70s design allows you to gravity feed, which may eliminate the need for feed pumps, saving you money.
When you upgrade from hand mixing, you'll find that the XP70 provides excellent return on investment, by reducing material waste and by using less clean-up solvent.
The XP-hf system combines the popular XP70 Sprayers with the powerful XL 10000 air motor.
Combining these two technologies, you get more flow - getting jobs done faster and with less wear and tear.
Engineered for more flow capacity, the Graco XP70-hf is great for applications where you want to spray with multiple guns or larger tip sizes.
Flexible options for mix ratio, pressure and flow rate choose the right system for the application. If you occasionally change materials, the Graco XP Sprayers are the right choice.
Thats because you can change the ratio by simply changing out one or two pump lowers. Available in 1:1, 1.5:1, 2:1, 2.5:1, 3:1 and 4:1 mix ratios.

Features:
Switch from hand-mixing and see the benefits
Graco XP50 protective coatings application
Reduced material waste
No more throwing away unused mixed material at the end of the day
Save money by using less clean-up solvent
Consistent material quality - no more guesswork or human error in measuring materials
Easy to operate - minimal training required
Reduced maintenance costs
Rated for 7250 psi (500 bar, 50 MPa) to handle viscous materials and long hose lengths

Materials:
Polyurethane
Plural Component Protective Coatings
Epoxy Coatings
High Solids Coatings
100% Solids Coatings
Polyurethane Coatings
Urethanes

Applications:
Roof Coatings
Rust Proofing
Towers For Wind Turbines
Structural Steel Coatings
Waster Water Treatment
Manhole & Sewer Reconditioning
Secondary Containment Spill Prevention
Corrosion Control
Offshore Rigs
Ship Building & Marine
Bridge Protective Coatings
Railcar Manufacturing & Repair
Pipe & Tank Coating
Water tower Protective Coatings

Industries:
Bridge Construction & Maintenance
Roofing Construction
Wind Power-Towers
Marine
Railroads

XP70 and XP70-hf Plural-Component Sprayers
Two-component spraying made easy and affordable
High-pressure performance for two-part high-solids coatings

A smart alternative to hand mixing
The Graco XP70 Plural-Component Sprayer is designed to pump, mix and atomize high to 100% solid coatings with superior results.
In addition, the XP70s design allows you to gravity feed, which may eliminate the need for feed pumps, saving you money.
When you upgrade from hand mixing, you'll find that the XP70 provides excellent return on investment, by reducing material waste and by using less clean-up solvent.
The XP-hf system combines the popular XP70 Sprayers with the powerful XL 10000 air motor.
Combining these two technologies, you get more flow - getting jobs done faster and with less wear and tear.
Engineered for more flow capacity, the Graco XP70-hf is great for applications where you want to spray with multiple guns or larger tip sizes.
Flexible options for mix ratio, pressure and flow rate choose the right system for the application. If you occasionally change materials, the Graco XP Sprayers are the right choice.
Thats because you can change the ratio by simply changing out one or two pump lowers. Available in 1:1, 1.5:1, 2:1, 2.5:1, 3:1 and 4:1 mix ratios.

Features:
Switch from hand-mixing and see the benefits
Graco XP50 protective coatings application
Reduced material waste
No more throwing away unused mixed material at the end of the day
Save money by using less clean-up solvent
Consistent material quality - no more guesswork or human error in measuring materials
Easy to operate - minimal training required
Reduced maintenance costs
Rated for 7250 psi (500 bar, 50 MPa) to handle viscous materials and long hose lengths

Materials:
Polyurethane
Plural Component Protective Coatings
Epoxy Coatings
High Solids Coatings
100% Solids Coatings
Polyurethane Coatings
Urethanes

Applications:
Roof Coatings
Rust Proofing
Towers For Wind Turbines
Structural Steel Coatings
Waster Water Treatment
Manhole & Sewer Reconditioning
Secondary Containment Spill Prevention
Corrosion Control
Offshore Rigs
Ship Building & Marine
Bridge Protective Coatings
Railcar Manufacturing & Repair
Pipe & Tank Coating
Water tower Protective Coatings

Industries:
Bridge Construction & Maintenance
Roofing Construction
Wind Power-Towers
Marine
Railroads

APEX On-Demand Dispensing Pumps
Electrical powered pumps and packages
Electrical pump with an on-demand sensing system

Keep air available for shop tools with this on-demand pump! With output up to 650 psi (44 bar) and 4 gpm (15 lpm), you can easily add oil dispense to your operation without replacing your compressor.
Our line of APEX pumps are available in AC and DC configurations to meet your fluid transfer needs!

Features:
On-demand sensing system automatically starts and stops the pump
Low operating and installation costs
Available in 12 VDC and 115 VAC
TENV electric motor for demanding environments
Extremely quiet pump operation
Output flow is continuous and non-pulsating
Inlet and outlet check valves with thermal relief valves included

Materials:
Antifreeze
Motor Oil
Gear Oil
Used Oil
Hydraulic Fluid
Cutting Oil
Oil

Applications:
Chemical Transfer
Oil Transfer
Pumping
Fluid Transfer

Industries:
Mining
Upstream: Drilling and Completions
Upstream Production Equipment for Oil and Gas
Chemical Dosing Pumps for Refineries
Waste Management
Dealerships and Quick Lubes - Pumps

APEX On-Demand Dispensing Pumps
Electrical powered pumps and packages
Electrical pump with an on-demand sensing system

Keep air available for shop tools with this on-demand pump! With output up to 650 psi (44 bar) and 4 gpm (15 lpm), you can easily add oil dispense to your operation without replacing your compressor.
Our line of APEX pumps are available in AC and DC configurations to meet your fluid transfer needs!

Features:
On-demand sensing system automatically starts and stops the pump
Low operating and installation costs
Available in 12 VDC and 115 VAC
TENV electric motor for demanding environments
Extremely quiet pump operation
Output flow is continuous and non-pulsating
Inlet and outlet check valves with thermal relief valves included

Materials:
Antifreeze
Motor Oil
Gear Oil
Used Oil
Hydraulic Fluid
Cutting Oil
Oil

Applications:
Chemical Transfer
Oil Transfer
Pumping
Fluid Transfer

Industries:
Mining
Upstream: Drilling and Completions
Upstream Production Equipment for Oil and Gas
Chemical Dosing Pumps for Refineries
Waste Management
Dealerships and Quick Lubes - Pumps

Gun Splitter Quick-flush feature saves time and material
Lets you use two spray guns with one XP Sprayer

The Graco Gun Splitter lets you use two spray guns with one XP Plural-Component Sprayer.
In addition, you can independently clean and flush one gun, while the other gun remains in use.
If youre using a higher production XP machine such as the XP50 or XP70, the Gun Splitter helps you become even more productive.

Features:
Independently sprays or flushes two guns for faster-setting materials
Saves time, improves uptime
Less solvent waste
Designed with minimal dead space, greatly reducing material build-up inside the splitter

fatigue

Features:
High quality finish, low pulsation output and smooth pump changeover deliver a consistent spray pattern
Quick color changes and fast material refills save time and money
Rugged, stainless steel or aluminum construction pump handles a wide variety of fluids

Material:
Solvent Based-Paint
Solventborne
Single Component
Varnishes
Lacquers
Enamels
Latex
High solids
CARC
Metallics
Stains
Epoxies

Applications:
Light Commercial Painting
Moderate Commercial
Heavy Commercial
General Metal Finishing-Pumping
General Metal Finishing-Spraying
Wood Finishing-Pumping
Wood Finishing-Spraying
Plastic Finishing-Pumping

Industries:
Furniture Finishing/Manufacturing
General Metal Finishing/Manufacturing
Wood Products Manufacturing
Marine
Railroads
Trucking
Fleets
Wood & Wood Products-Pumps
Wood & Wood Products-Spray guns
Heavy equipment Manufacturing
Agricultural Equipments/Manufacturing
Automotive Manufacturing
CARC
Personal Recreation Vehicles
RVs
Aerospace Finishing
Forestry Equipments

CH20 is a series of hydraulic powered high-pressure water-blasters from 350 to 500 Bar and 16 to 23 L/min in flow capacity.
The machine are with pneumatic rear wheels with parking brake, castor front wheel.
The frames are made up in hot-dip galvanized and powder coated pressed sheet metal parts with all enclosing side frames in stainless steel.
It measures 1060 x 760mm and 850mm high. One central lifting eye.

High performance abrasive blasting of metal constructions andbuildings, bridges, reservoirs, piping, concrete surfaces.- Cleaning up to grade SA-3, 0.- Performance up to 37 m2/h.- Designed for working with any dry abrasives, max. grain size 3, 5 mm.

100- /200-liter capacity tank, screen, cap, sand valve, highperformance moisture separator, inspection door, quick hose couplings Remote control device (RC) with a pneumatically-operated RC main valve, deadman handle, 40-meter twin-line hose, hose fittings.

All Contracor abrasive blasting machines are equipped on standard delivery with a highly efficient CAF-3 moisture separator to prevent the entry of moisture and oil from the compressor into the tank.

The CD100 range of water-blasters and water-jetting machines goes from 250 to 200 Bar with pump flows from 21 to 167 L/min.
The pump are driven by a 4 cylinder water cooled Turbo charged SISU diesel engine and the all enclosing frame is made in hot dip galvanized steel for durability and corrosion resistance and is primed and painted for a nice appearance.
The machine foot print is 2100 x 950mm of floor space. The frame are equipped with rubber feet under all four corners and the machine have forklift pockets as well as lifting eyes in all four corners.
The machines have galvanized roof plates with side railings for protection and storage of forexample high pressure hoses.

XHD RAC SwitchTip
High-Pressure Airless Spray Tip for XTR Guns

Increase spraying productivity and reduce downtime
Designed for spraying high-solids coatings at high pressures.
With its Reverse-A-Clean (RAC) Tip, its easy to clear clogs.
The Switch Tip design lets you change tip sizes in seconds without removing the tip guard and housing.

Features:
Saves time no screwdriver required
Change tip sizes in seconds
For heavy-duty applications up to 7250 psi (500 bar)
Recommended for use with Xtreme Sprayers and XTR Guns
Heavy-duty carbide tip

The CD100 range of water-blasters and water-jetting machines goes from 250 to 200 Bar with pump flows from 21 to 167 L/min.
The pump are driven by a 4 cylinder water cooled Turbo charged SISU diesel engine and the all enclosing frame is made in hot dip galvanized steel for durability and corrosion resistance and is primed and painted for a nice appearance.
The machine foot print is 2100 x 950mm of floor space. The frame are equipped with rubber feet under all four corners and the machine have forklift pockets as well as lifting eyes in all four corners.
The machines have galvanized roof plates with side railings for protection and storage of forexample high pressure hoses.

General specifications:
Max pump speed- 750 rpm
Engine- 4 Cyl. Sisu Turbo Diesel Water cooled
Engine power- 100 Hp
Engine rpm- 1800 rpm
Tank- 140 L
Max fuel consumption- 16.0 L/h
Noise (1m)- 84 dBa
Dimensions- 2250mm x 950mm x 1300 mm
Weight- 2000 kg

The frames are made from hot dip galvanized pressed sheet metal parts and stainless steel perimeter frame rails.
Front castor wheel and two big pneumatic wheels with brake for easy maneuvering and stable parking. One hook lifting eye.

HOSE SAFETY CABLES
Attach blast hose safety cables at all coupled connections.
Before connecting the couplings, pull back the spring-loaded loop, slip it over the blast hoses only (not the remote control lines).
Connect the hose coupling and slide the ends of the safety cable back until the cable is straight and the hose is slightly bent.

Contracor blast hose Whipcheck Safety Cables are used at all blast hoses for the safe holding of coupled connections in case of accidental separation.
The Whipcheck Safety Cables relieve the couplings of the weight of the hose and reduce the danger caused by hose couplings failure.
The Cables also help keeping the blast hose from whipping about in the event of a coupling failure.

Hose couplings may separate from air and blast hoses for a variety of reasons:
- Coupling screws may lose their holding power due to internal wear on the hose tubing
- Use of improper coupling screws may interfere with the proper fit between couplings and hose
- Hose outer diameter may be too small for the coupling
- The continual strain caused by pulling hoses around job sites can weaken the couplings grip on the hose
- Couplings can also have been damaged by vehicles or other equipment.

Whipcheck Safety Cables are strongly recommended by vertical applications, when air and blast hoses are suspended.
Hose couplings are not designed to support the weight of the hose.
Additional supports are required to relieve the added tension.
Constructed of corrosion resistant, high strength steel, Whipcheck Safety Cables may be installed on hose-to-hose and hose-to-fixed coupling connections.

PORTABLE SUCTION BLAST TOOL POWER GUN
- Lightweight, portable and easily transportable tool
- Suitable for use with all media containers, or even straight out of the bag
- Simple work principle just plunge the suction lance into the container of abrasive and pull the trigger
- Easy to use and maintain

The Contracor Power Gun is a suction blast tool ideally suited to small jobs or locations with limited air supplies.
Thanks to its light weight and compact dimensions, the Contracor Power Gun can be used in places where erecting a conventional pressure blast machine would be awkward or inconvenient.
The Power Gun can be used with all common blast media, to clean or etch metal, glass, stone or other hardwearing surfaces.
To operate the Power Gun, just connect it to a compressed air source, and submerge the suction lance to which the abrasive hose is connected partially into a container of blast media.
To commence blasting, simply depress the lever on the Power Gun.
The tool operates according to Bernoullis principle, where a low-pressure area is created by the compressed air rushing past the abrasive-injection point, where the abrasive hose is connected to the gun.
This low-pressure area draws abrasive into the airstream, where mixing takes place. The air-abrasive mix is then exhausted out of the gun and strikes the blasting surface.

STANDARD DELIVERY
Power Gun, suction lance and 5m suction hose with hose clamps.

CLOSED CIRCUIT BLAST TOOL EDUCT-O-MATIC
The Educt-O-Matic is the compact hand-portable closed-circuit blast tool, which can be transported everywhere and required just 2.5m3/min of air at 6bar.
Blasting and media recovery are controlled just with one trigger. Media recovery is initiated by slightly pulling the trigger, while pulling the trigger fully starts the suction blast system.
Abrasive is stored in a compact conical hopper from where it is metered into the blast apparatus.
Abrasive is drawn into the mixing chamber of the Educt-O-Matic by the high speed airstream, where it is mixed with air, and is then propelled out of the nozzle.
The blast head is adjustable and swivels to allows blasting at any angle. Abrasive and dust are captured in the rubber attachment.
Reusable abrasive is drawn back to the hopper, whereas broken abrasive and dust are directed to the dust bag.
An area about 30mm wide can easily be cleaned with an Educt-O-Matic.
When finished with blasting, just release the trigger to half-way for two to three seconds, and the vacuum recovers the remaining dust and abrasive.
Vacuuming is stopped by fully releasing the trigger. The Educt-O-Matic works best with with steel or iron grit. Dust and broken abrasive are captured in a simple cotton bag.

STANDARD DELIVERY
EDUCT-O-MATIC, 6 attachments and dust bag.

BLAST HELMET ASPECT
This very comfortable, lightweight and value-for-money helmet is suitable for any kind of abrasive blasting work.
The helmet is designed with a wide viewing window.
This is an important feature when the operators movement is limited,
e.g. in blasting rooms, while cleaning the internal surfaces of reservoirs, holds, etc.

Advantages
1. The robust, durable shell of the Aspect blast helmet ensures operator security and a long service life of the helmet, whilst an air baffle delivers a constant flow of air to the operators head and face to reduce fatigue, prevent misting and increase productivity and safety.
2. The top of the cape is protected from ricochet of blast material by an extended window frame
3. The embedding of media between the lenses is prevented by an integral 1-deep visor.
4. Easy closing of the window through a slot which aligns the closing latch and tab.
5. The cape is fixed to the bottom rim of the helmet via an adjustable ratchet buckle, which ensures a secure fit and easy replacement.
6. High operator visibility and security are provided by two lenses and a wire mesh screen.

Disposable lenses
In Aspect blast helmet disposable clear acetate lenses protected by a stainless steel wire mesh screen are used.
Disposable lenses can be exchanged in a matter of seconds, and are available in practical packs with 50pcs.

CE20 is a series of electrical driven high-pressure water-blasters from 200 to 500 Bar and 16 to 38 L/min in flow capacity.
The standard machine are with pneumatic rear wheels with parking brake, castor front wheel.
The Slim version is narrower and has solid rear wheels with parking brake instead.
The frames are made up in hot-dip galvanized and powder coated pressed sheet metal parts with all enclosing side frames in stainless steel.
The standard model with pneumatic tyres measures 1060 x 760mm. The Slim model are 1060 x 500mm. Both are 850mm high.
The standard and slim versions share all other specifications.

BLAST HOSE QUICK COUPLINGS CQP
For abrasive blasting hoses with.
Compatible with hose couplings CFT on CONTRACOR abrasive blasting machines.

Characteristics
Material: Nylon.
Equipped with a rubber washer, a steel safety clip and screws.

BLAST LIGHT ABL
- 800 lumens, concentrated light cone
- Modern LED technology
- Light housing is specially designed for blast hose mounting
- Mounted ABL light will not interfere with the normal operation of DMH handle
- Simple and fast exchange of the disposable glass

The ABL blast light is designed for illuminating a working area during sandblast cleaning operations.
The lamp runs on 12-24 volts and provides a bright concentrated light which can be directed at the working area.
It utilizes an approximately 800-lumen bright LED module to produce a concentrated light cone.
The ABL blast light attaches to the sandblast hose and does not interfere with operation of the DMH handle.
The operator does not have to hold the light in one hand in order for it to work effectively.
The modern LED light runs on a 12-24 V DC battery or other 12-24 V DC source.
The lamp has a hermetically sealed design and is protected against dust and abrasive material.
A stable and replaceable deflector glass protects the lamp against abrasive material damage.
The disposable glass can be easily replaced once the rubber cover is removed.
The LED light is supplied with a 1.5-m power cord.

STANDARD DELIVERY
Assembled 12-24V LED light with 1.5-m power cord.

BREATHING AIR CONDITIONER CCT
The output temperature of the CCT air conditioner is up to 20C below or above the input temperature.
The CCT breathing air conditioner functions according to the principle of airflow separation.
It is intended for heating or cooling breathing air which travels from the breathing air filter to the blasting hood.

WATER BLAST ATTACHMENT WBA
Contracor water blast equipment has been specifically designed to meet growing customer demand for a multi-purpose cleaning system that is fast, economical and environment-friendly.

Field of Application
Dust-reducing high-performance cleaning of steel, stone and concrete surfaces. Cleaning up to grade SA-3.0.
Performance up to 20% higher than dry blasting. Designed to work with any water matching abrasives, max. grain size 3.5 mm.

Characteristics
Universal Water Blast Attachment. Sleeve made from high grade tungsten carbide.
Fits all Contracor blast nozzles. Jacket: Aluminium. Thread: 50-mm coarse aluminium thread.

remote control system for blast vessels
the remote control system is used by a single abrasive blasting operator for starting up and shutting down the blast machine.
the remote control system comprises a remote control rcv valve and remote control dmh handle, which are connected by a twin hose.
rcv remote control valve
the rcv remote control valve is used for controlling the compressed air feed to the machine while simultaneously controlling air blow-out from the machine.
both control functions run concurrently when the dmh handle is pressed or released by the abrasive blasting operator. Air is bled from the tank via a damper, which is included in the delivery set.

dmh remote control handle
the dmh remote control handle
is fastened to the nozzle and connected
to the rcv remote control valve
using a dual hose.

design features
the rcv remote control valve responds when the dmh handle is pressed.
the blast machine's tank is pressurized and the abrasive blast cleaning process begins.
when the dmh handle is released, the rcv remote control valve closes, the abrasive blast cleaning process terminates and the machine's tank depressurizes.

Elcometer Blasting Inspection Kits
The Elcometer Blasting Inspection Kit is a surface preparation inspection kit providing a range of inspection equipment to test surface profile and surface contamination of blasted profiles.

An Elcometer 456 Gauge and probe can also be supplied. (Order separately if required).

Measurement parameters include:
Surface assessment
Blast equipment inspection
Surface profile
Surface contamination

Elcometer Digital Inspection Kits

Available as a Basic or Top version, these digital inspection kits have been specifically designed to undertake the
three principal inspection requirements in the Protective and Industrial Coatings Industry climate, surface profile and dry film thickness.
Ideal for paperless quality assurance systems the kits come complete with ElcoMaster Data Management Software for professional reporting and analysis.

Ferrous Digital Inspection Kit; Basic Version
Inspection kit containing entry level digital inspection equipment designed for users who want to carry out key inspection tasks.
Kit Contents:
Elcometer 224 Model B Integral Digital Surface Profile Gauge, 0 500m (0 20mils)
Elcometer 319 Standard Dewpoint Meter
Elcometer 456 Model B Ferrous Separate Coating Thickness Gauge with standard separate probe; 0- 1500m (0 60mils)
Gauges have on-screen statistics and a rolling memorya for storing up to 10 readingsb.

Ferrous Digital Inspection Kit; Top Version
Contains higher specification instruments with greater functionality for more advanced inspection processes and measurements.
Kits Contents:
Elcometer 224 Model T Integral Digital Surface Profile Gauge, 0 500m (0 20mils)
Elcometer 319 Top Dewpoint Meter with Magnetic Surface Probe
Elcometer 456 Model T Ferrous Separate Coating Thickness Gauge with standard separate probe; 0- 1500m (0 60mils)
ElcoMaster Data Management Software & USB Cable
Gauges have memory which can store up to 150, 000b readings and Bluetooth technology for cable free data transfer and are compatible with ElcoMaster Software, ideal for creating detailed, professional reports.

FNF Digital Inspection Kits; Basic Version
Kit Contents:
Elcometer 224 Model B Integral Digital Surface Profile Gauge, 0 500m (0 20mils)
Elcometer 319 Standard Dewpoint Meter
Elcometer 456 Model B FNF Separate Coating Thickness Gauge with standard FNF separate probe; 0- 1500m (0 60mils)

FNF Digital Inspection Kits; Top Version
Kit Contents:
Elcometer 224 Model T Integral Digital Surface Profile Gauge, 0 500m (0 20mils)
Elcometer 319 Top Dewpoint Meter with Magnetic Surface Probe
Elcometer 456 Model T FNF Separate Coating Thickness Gauge with standard FNF separate probe; 0- 1500m (0 60mils)
ElcoMaster Data Management Software & USB Cable
You can connect Elcometer Bluetooth enabled inspection gauges directly to iPhone, iPad and iPod or Android mobile phones and tablets via ElcoMaster Mobile App.
a The Elcometer 224 Model S does not store readings but does have rolling statistics.
b The actual number of readings depends on the instrument.

Elcometer Protective Coating Inspection Kit 1

Available as metric or imperial kits and housed in a sturdy, light-weight carry case, Elcometer Protective Coatings Inspection Kits are invaluable to the operator in the field to ensure the coating is, or has been, applied correctly and is fit for purpose, removing the need for guesswork.

Protective Inspection Kit 1
An entry level inspection kit containing profile, climate, wet and dry film thickness.

Elcometer Blasting Inspection Kits
The Elcometer Blasting Inspection Kit is a surface preparation inspection kit providing a range of inspection equipment to test surface profile and surface contamination of blasted profiles.

An Elcometer 456 Gauge and probe can also be supplied. (Order separately if required).

Measurement parameters include:
Surface assessment
Blast equipment inspection
Surface profile
Surface contamination

Elcometer Protective Coating Inspection Kit 2

The Elcometer range of Protective Coatings Inspection Kits provide all the tools required for onsite inspection of a coating, including surface profile, dewpoint, relative humidity, adhesion and both wet and dry film thickness.

Available as metric or imperial kits and housed in a sturdy, light-weight carry case, Elcometer Protective Coatings Inspection Kits are invaluable to the operator in the field to ensure the coating is, or has been, applied correctly and is fit for purpose, removing the need for guesswork.

Protective Inspection Kit 2
Like the Protective Inspection Kit 1 but with the addition of the Elcometer 224 digital surface profile gauge with data collection functionality and the Elcometer 319 digital dewpoint meter. Reports via ElcoMaster can include data from both profile and climate inspections as well as dry film thickness.

Technical Specs:
Item- Industrial Portable Dehumidifier
Capacity/24 Hrs. @ 60% RH 70 pt.
Capacity/24 Hrs. @ 90% RH 150 pt.
Voltage- 115V
Hz- 60

NEMA Plug Configuration 5-15P
Application- Removes Excess Moisture From The Air To Prevent Mildewing, Musty Odors, Sweating On Walls And Windows, And Damage To Exposed Surfaces
Agency Compliance- cETL
Includes 2 Casters, 20 ft. Drain Hose, Collapsible Handle

Silver Plus Gun
Manual Airless Guns Known for its durability, long life, spraying performance, and comfortable design, it is the preferred gun for high pressure applications

Graco's Silver Plus Gun is known for its durability, long life, spraying performance, and comfortable design.
It is the preferred gun for high pressure applications.

Silver Plus Product Highlights
Reverse-A-Clean tip design to reduce downtime caused by frequent tip plugging
5000 psi (345 bar, 34.5 Mpa) fluid rating for spraying the toughest materials
SST wetted parts for material compatibility

Features:
Lightweight, Rugged Design - Forged aluminum is durable to withstand harsh work environments
Exclusive needle design - no trigger adjustments needed
2-Finger trigger design and handle is form fitted for less fatigue
Stainless steel fluid tube - ability to spray heavier materials such as high solid coatings
RAC X Switchtip and Handtite guard provides exceptional life, pattern and finish

SURFACE ROUGHNESS COMPARATOR GRIT, SHOT

A precision nickel comparator plate which conforms to International Standard ISO 8503 for grit and shot blast surface roughness comparison measurement.
Comparators allow the estimation of surface roughness by touch and sight.
They are split into four sections, each with a different and defined roughness.
Comparators are available in both grit and shot blasted versions.
The grit version is split into sections equivalent to 25, 60, 100 and 150 microns.
The shot version is split into sections equivalent to 25, 40, 70 and 100 microns.

HOSES FOR COMPRESSED AIR AIRFLEX

Special build for heavy duty applications such as sandblasting.

For connection between blasting hood and airline filter BAF.

Characteristics

Special thick-wall hose made from non-toxic materials.
Thick-walls prevents the hose from buckling and pinching.

BRS BLAST RECOVERY SYSTEM (CLOSED CIRCUIT)
The BRS Blast Recovery System is an electrically operated, pressure-feed closed-circuit blast machine, which can be used where open-air blasting is prohibited, or is not possible or practical.
Blasting and simultaneous media recovery are initiated by pulling the DMH handle.
Keeping the blast area clean allows the operator to blast without the need to encapsulate the area or wear respiratory protective equipment.

APPLICATION
Closed-circuit abrasive blast cleaning, ideal for indoor blasting where dust and abrasive contaminants should be avoided, for the blasting of welding seams and for spot repairs.
Used blast media are recyclable non-metallic media: glass bead, aluminum oxide (corundum).

STANDARD DELIVERY
BRS systems are mounted on the portable frame and include a cyclone dust separator and media reclaimer, a dust collector with a cartridge filter and automatic pulse jet filter cleaning, a fully pneumatic remote control and blast pressure control, an adjustment device and a compressed-air moisture filter. The BRS system includes a combined blast and vacuum head, fitted with a nylon-bristle brush that presses against the blast surface. The BRS recovery head assembly comprises a blast nozzle and a vacuum hose, which evacuates dust and the rebounding abrasive following its contact with the blast surface. This BRS recovery head contains the abrasive and keeps the surrounding area clean. DMH handle.

FUNCTIONAL CHARACTERISTICS
- portable design
- electrically driven powerful vacuum
- dust cyclone separator with removable screen
- dust collector with cartridge filter
- pulse jet filter cleaning with timer control
- adjustable blasting pressure
- compressed air filter /moisture separator

HK series are the most ideal airless pump for rough painting job. This pump used in construction, cleaning and container. The best price and good quality.

• Roof Coating
• Steel Structure
• Shipyard Painting
• Marine Painting
• High Viscosity Coating
• Construction
• Protective Coating
• Container Coating
