Our Products
Hydraulic Shearing Machine
2 Products availableWe offer the best product range of Wooden Router Machine.
We are the prominent Manufacturer, Supplier, and Exporter of Hydraulic Shearing Machine. We use the finest quality components for assembling high performance and energy efficient Hydraulic Shearing Machine. Due to high stroke length and sheet clamped hydraulically before cut starts make it an ideal choice to buy to get maximum satisfaction. Silent Features
Standard Accessories
Technical Specifications
| Model | Shearing Length mm | Shear Thickness Rake Angle (Min./Max.)M.S. | Shear Thickness Rake AngleS.S | Rake Angle | Rake Angle Range | Strokes/Minute at Min. & Max. Rake Angle | Hold downs | Holding Force Kgs | Power H.P | Over all Dimension in mm (L x W x H) | Approx. Weight Kgs |
|---|---|---|---|---|---|---|---|---|---|---|---|
| HVR253 | 2500 | 3.15/4 | 2/3 | 1o15' | 0.5-2” | 28-13 | 13 | 2500 | 5 | 3150*2000*2400 | 3800 |
| HVR303 | 3000 | 3.15/4 | 2/3 | 1o15' | 0.5-2” | 24-9 | 16 | 2500 | 5 | 3500*2000*2400 | 4400 |
| HVR124 | 1250 | 4/6 | 3/4 | 1o37' | 0.5-3” | 33-17 | 5 | 4000 | 5 | 2000*2000*2400 | 2700 |
| HVR154 | 1500 | 4/6 | 3/4 | 1o37' | 0.5-3” | 30-15 | 8 | 4500 | 5 | 2250*2000*2400 | 3200 |
| HVR204 | 2000 | 4/6 | 3/4 | 1o37' | 0.5-3” | 28-13 | 11 | 6200 | 7.5 | 2750*2000*2400 | 3500 |
| HVR254 | 2500 | 4/6 | 3/4 | 1o37' | 0.5-3” | 26-8 | 13 | 8000 | 7.5 | 3400*2350*2450 | 5200 |
| HVR304 | 3000 | 4/6 | 3/4 | 1o37' | 0.5-3” | 24-6 | 16 | 10000 | 10 | 4000*2350*2450 | 6000 |
| HVR404 | 4000 | 4/6 | 3/4 | 1o45' | 0.5-3” | 22-6 | 20 | 12000 | 10 | 4500*2350*2450 | 8500 |
| HVR156 | 1500 | 6/8 | 4/6 | 1o45' | 0.5-3” | 24-8 | 9 | 6600 | 10 | 2250*2350*2500 | 4000 |
| HVR206 | 2000 | 6/8 | 4/6 | 1o45' | 0.5-3” | 22-7 | 11 | 6500 | 10 | 2750*2350*2500 | 4300 |
| HVR256 | 2500 | 6/8 | 4/6 | 1o45' | 0.5-3” | 28-8 | 14 | 8500 | 15 | 3400*2350*2500 | 6200 |
| HVR306 | 3000 | 6/8 | 4/6 | 1o45' | 0.5-3” | 24-6 | 16 | 10800 | 15 | 4000*2350*2500 | 7000 |
| HVR406 | 4000 | 6/8 | 4/6 | 2o | 0.5-3” | 24-6 | 20 | 13600 | 20 | 5100*2700*2800 | 8400 |
| HVR158 | 1500< | 8/10 | 6/8 | 2o | 0.5-3” | 22-10 | 9 | 10500 | 15 | 2250*2600*2650 | 5000 |
| HVR208 | 2000 | 8/10 | 6/8 | 2o | 0.5-3” | 18-8 | 11 | 12500 | 15 | 2750*2600*2650 | 5500 |
| HVR258 | 2500 | 8/10 | 6/8 | 2o | 0.5-3” | 24-8 | 14 | 16300 | 20 | 3500*2600*2650 | 6800 |
| HVR308 | 3000 | 8/10 | 6/8 | 2o | 0.5-3” | 20-6 | 16 | 18500 | 20 | 4200*2600*2650 | 7700 |
| HVR408 | 4000 | 8/10 | 6/8 | 2o | 0.5-3” | 20-8 | 20 | 23000 | 25 | 5200*2900*2800 | 13500 |
| HVR1510 | 1500 | 10/13 | 8/10 | 2o | 0.5-3” | 20-10 | 9 | 10500 | 15 | 2250*2650*2700 | 5500 |
| HVR2010 | 2000 | 10/13 | 8/10 | 2o | 0.5-3” | 18-8 | 11 | 12600 | 15 | 2750*2650*2700 | 6000 |
| HVR2510 | 2500 | 10/13 | 8/10 | 2o | 0.5-3” | 24-8 | 14 | 17500 | 20 | 3600*2650*2700 | 8000 |
| HVR3010 | 3000 | 10/13 | 8/10 | 2o | 0.5-3” | 20-6 | 16 | 20000 | 20 | 4200*2650*2700 | 10500 |
| HVR4010 | 4000 | 10/13 | 8/10 | 2o | 0.5-3” | 18-6 | 20 | 25000 | 30 | 5200*2900*2900 | 15200 |
| HVR2013 | 2000 | 13/16 | 10/13 | 2o | 0.5-3” | 13-5 | 11 | 16500 | 20 | 2750*2650*2950 | 7000 |
| HVR2513 | 2500 | 13/16 | 10/13 | 2o | 0.5-3” | 15-10 | 13 | 32000 | 25 | 3600*2650*2950 | 9600 |
| HVR3013 | 3000 | 13/16 | 10/13 | 2o | 0.5-3” | 12-6 | 16 | 37000 | 25 | 4200*2650*2950 | 11800 |
| HVR4013 | 4000 | 13/16 | 10/13 | 2o | 0.5-3” | 10-4 | 20 | 22000 | 30 | 5200*3000*3050 | 17800 |
| HVR2016 | 2000 | 16/20 | 13/16 | 2o | 0.5-3” | 13-7 | 11 | 20000 | 25 | 2750*2950*3150 | 12000 |
| HVR2516 | 2500 | 16/20 | 13/16 | 2o | 0.5-3” | 15-8 | 13 | 40000 | 30 | 3600*2950*3150 | 12000 |
| HVR3016 | 3000 | 16/20 | 13/16 | 2o | 0.5-3” | 12-6 | 16 | 43500 | 30 | 4250*2950*3150 | 15300 |
| HVR4016 | 4000 | 16/20 | 13/16 | 2o | 0.5-3” | 10-4 | 20 | 30000 | 30 | 5200*3050*3500 | 21500 |
| HVR2020 | 2000 | 20/25 | 16/20 | 2o | 0.5-3” | 16-8 | 11 | 32000 | 40 | 2900*2950*3150 | 17000 |
| HVR2520 | 2500 | 20/25 | 16/20 | 2o | 0.5-3” | 15-8 | 13 | 48000 | 40 | 3600*2950*3150 | 18000 |
| HVR3020 | 3000 | 20/25 | 16/20 | 2o | 0.5-3” | 12-6 | 16 | 52000 | 40 | 4250*2950*3150 | 20000 |
| HVR4020 | 4000 | 20/25 | 16/20 | 2o | 0.5-3” | 10-4 | 20 | 30000 | 50 | 5200*3050*3500 | 24000 |
With us, buyers can stay completely assured for top-notch products as we make use of the premium material and modern work methods for preparing them. Besides, the material is sourced from the genuine places. We have a capacious warehouse facility that assists us completely in making stock and furnishing varied requirements of the clients. Also, our facility is equipped with modern storage amenities.
We have a well-developed all the in-house storage facility, laced with all the modern facilities. Also, we have hired a team of professionals who efficiently manage and maintain it. Offering Hydraulic Sheet Cutting Machine, we are eminent Suppliers catering efficiently to the demands of the customers.
We are supported by a team of professionals who ensure that the offered lot is prepared using the best quality raw material. Also, they confirm that the material is sourced from the certified places. We are backed by a quality control wing that comprises experienced quality inspectors who strictly check all the products before making the final dispatch.
The high performer Heavy Duty lathe Machine is compromised of finest quality components that enhance its performance and service life. Our Heavy Duty lathe Machine contains various accessories such as centre adaptor, gear set, dial indicator and many others that make the work efficient and effective. The Heavy Duty lathe Machine, offered by us, is known for its excellent capacity to drill, sand, turn, or face the object. Standard Accessories
Optional Accessories
Technical Specifications
| Particulars | Unit | HD - 1 | HD - 2 | HD - 3 | HD - 4 | HD - 5 | HD - 6 |
|---|---|---|---|---|---|---|---|
| Bed Length | Feet | 5.6 | 7 | 9 | 10 | 12 | 14 |
| Admit Between Center | Mm | 550 | 1000 | 1550 | 1930 | 2400 | 3000 |
| Bed Width | Mm | 323 | 323 | 323 | 323 | 375 | 375 |
| Height of Center | Mm/Inch | 254/10” | 254/10” | 254/10” | 304/12” | 304/12” | 304/12” |
| Swing over bed | Mm | 490 | 490 | 490 | 596 | 736 | 736 |
| Swing over cross slide | Mm | 290 | 290 | 290 | 393 | 533 | 533 |
| Spindle Bore | Mm | 52 | 52 | 52 | 80 | 105 | 105 |
| Lead Screw TPI | 4 TPI | 4 TPI | 4 TPI | 4 TPI | 4 TPI | 4 TPI | |
| Tail Stock Sleeve | MT-4 | MT-4 | MT-4 | MT-4 | MT-4 | MT-4 | |
| Main Motor | HP | 2 HP | 2 HP | 3 HP | 3 HP | 5 HP | 5 HP |
We are the prominent Manufacturer, Exporter, and Supplier of Light Duty Lathe Machine. Our Light Duty Lathe Machine is highly efficient in terms of producing quality and quantity goods that find diverse application in various industries. Our Light Duty Lathe Machine comprised of various accessories such as chuck plate, gear set, dead centers, and many others. Our clients can avail these at the market leading prices from us. Standard Accessories
Optional Accessories
Technical Specifications
| Particulars | Unit | LD - 1 | LD - 2 | LD - 3 |
|---|---|---|---|---|
| Bed Length | Feet | 4.6 | 5.3 | 6 |
| Admit Between Center | Mm | 740 | 960 | 1190 |
| Bed Width | Mm | 225 | 225 | 225 |
| Height of Center | Mm/Inch | 165/6.5” | 165/6.5” | 165/6.5” |
| Swing over bed | Mm | 320 | 320 | 320 |
| Swing over cross slide | Mm | 180 | 180 | 180 |
| Spindle Bore | Mm | 40 | 40 | 40 |
| Lead Screw TPI | 4 TPI | 4 TPI | 4 TPI | |
| Tail Stock Sleeve | MT-3 | MT-3 | MT-3 | |
| Main Motor | HP | 1 HP | 1 HP | 1 HP |
The company is engaged in manufacturing, supplying, and exporting of Medium Duty Lathe Machine that is fabricated in accordance with industry norms. We use the high quality components that are procured from the leading vendors in the industry who meet the company quality standards. Due to high tensile strength, updated technology, and hardened & ground bed & spindle make our Medium Duty Lathe Machine the best among other available options. Standard Accessories
Optional Accessories
Technical Specifications
| Particulars | Unit | MD - 1 | MD - 2 | MD - 3 |
|---|---|---|---|---|
| Bed Length | Feet | 4.6 | 5.3 | 6 |
| Admit Between Center | Mm | 470 | 770 | 920 |
| Bed Width | Mm | 280 | 280 | 280 |
| Height of Center | Mm/Inch | 215/8.5” | 215/8.5” | 215/8.5” |
| Swing over bed | Mm | 415 | 415 | 415 |
| Swing over cross slide | Mm | 250 | 250 | 250 |
| Spindle Bore | Mm | 53 | 53 | 53 |
| Lead Screw TPI | 4 TPI | 4 TPI | 4 TPI | |
| Tail Stock Sleeve | MT-4 | MT-4 | MT-4 | |
| Main Motor | HP | 1.5 HP | 1.5 HP | 1.5 HP |
We are offering Mechanical Shearing Machine to our esteemed clients, which are fabricated in accordance to industry norms. Our Mechanical Shearing Machine finds application in various industries for molding products of all types as per the requirements. Due to dimensional accuracy, durability, and cost effective features this Mechanical Shearing Machine gets highly demanded by our clients. We provide it in various different grades and dimensions to meet the multiple needs industrial demands.
Technical Specifications
| Model | Cutting Capacity MS Length - * Thickness | Stroke Per Minute | Table Height | Table Width | Front Gauge | Rear Gauge | Motor HP/KW |
|---|---|---|---|---|---|---|---|
| UC - 122 | 1270 * 2 | 45 | 800 | 350 | 750 | 500 | 2 |
| UC - 155 | 1525 * 2 | 45 | 800 | 350 | 750 | 500 | 2 |
| UC - 202 | 2030 * 2 | 45 | 800 | 350 | 750 | 500 | 3 |
| UC - 252 | 2540 * 2 | 45 | 45 | 825 | 430 | 980 | 5 |
| UC - 312 | 3150 * 2 | 45 | 825 | 430 | 980 | 500 | 7.5 |
| UC - 124 | 1270 * 4 | 50 | 825 | 430 | 980 | 500 | 5 |
| UC - 154 | 1525 * 4 | 50 | 825 | 430 | 980 | 500 | 5 |
| UC - 204 | 2030 * 4 | 50 | 825 | 430 | 980 | 500 | 7.5 |
| UC - 254 | 2540 * 4 | 50 | 925 | 460 | 980 | 600 | 10 |
| UC - 314 | 3150 * 4 | 50 | 925 | 460 | 980 | 600 | 12.5 |
The C Type Mechanical Power Press Machine, offered by us, is highly acclaimed in manufacturing industry for doing symmetry of work piece. Our C Type Mechanical Power Press Machine is strictly made by using the high quality special alloy steel, which enhance the strength and service life. Due to high accuracy & precision operation it gets highly acclaimed in all industries for multiple purposes. Moreover, our C Type Mechanical Power Press Machine contains gears & clutch, table & ram that are made by using the high grade Cast Iron.
Additional Information:
Payment Terms : T/T
We are the leading Manufacturer, Supplier, and Exporter of Mechanical Press Brake Machines, which are designed and developed through years of experience in Sheet Metal working machines. Our Press Brakes are widely accepted in industries for continuous production runs and in areas requiring and repeatability coupled with high production. FrameFrame is of robust steel construction of rigid and interlocked design. It is strain-free and supports the Ram and Bed against undesired deflection under permissible load condition. Ram And BedMade from Steel Plates of suitable thickness. Machines for straightness and parallelism of the working surface. Ram is guided and supported throughout the stroke by accurately machines guide ways. Drive SystemPower is transmitted to the Ram through two individual Gear drives for uniform load distribution throughout the length. This also reduces the torsion stresses on the eccentric shaft electric motor used is of sufficient H.P. Which reduces slowdown of flywheel and increases energy available per stroke. The Gear and pinion are made out of carbon / alloy steel. Ram AdjustmentMotorized Ram Adjustment through a simple drive mechanism facilitates quick bending angle adjustment is made simple by incorporating a spring loaded dog clutch. Clutch And BrakeAll series of Press are provided with high torque how-inertia Friction Clutch, Synchronized with heavy duty mechanical Brake ensuring immediate braking of Ram on releasing the Pedal. Clutch operating levers are designed in such a way that minimum, engaging force is required of the pedal. Standard AccessoriesFoot Pedal and Die Block Lifting Link, Fly Wheel & Gear Guard, Self Lubrication System, Motor Pulley, Standard Block and Punch, Motor Mounting Bracket.
We are offering router machine. Manufacturing & supplying of router machine (wood working machine) in various type of model available
With our expertise in the industry, we are engaged in offering the best range of Workshop Machinery at very affordable rates. Buyers can approach us, if looking for obtaining first-class products in Ahmedabad(India).
This is due to our rich industry experience and knowledge; we are able to offer optimum quality Sheet Metal Machinery. Our team of quality analysts ensures that the offered product is of unmatched standard and free from any kind of flaws.
