Our Products
Our offered Product range includes Jewelry Mini Bench Rolling Mill, 3 Meter x 1.0mm Guillotine Shearing Machine, Gold Sheet Rolling Mill, 2-hi Precision Sheet Rolling Mill and Heavy Duty Sheet Rolling Mill.
Additional Information:
Payment Terms : T/T
Packaging Details : strong carton packing.
Delivery Time : one week
Additional Information:
Payment Terms : T/T
Packaging Details : wooden base with gunny plastic packing
Delivery Time : three to six weeks
Additional Information:
Payment Terms : T/T
Packaging Details : Wooden Case Packing.
Delivery Time : 8 to 12 weeks
This is 2-Hi Cold Precision Sheet Rolling mill with Coiler and De-Coiler having HCHCr Steel rolls with hardness of 62-63 HRC fitted on Roller bearings and housed inside heavy MS Plate fabricated body. The machine is having three gear type roll lifting arrangement with fine battler thread 1.5 pitch screw for fine adjustment. The rolls are driven through suitable pinion gearbox with universal joints and a worm type gear box for excellent and smooth working.
Machine will be fitted with fixed Coiler & De coiler such that your material will be fed through and wound on interchangeable bobbins mounted on spools fitted on both sides. Spools will be such as to facilitate easy removal and fixing of bobbins for multiple pass rolling. The coiler will have its drive through the main motor and the de coiler will be fitted with clutch type brake for tension setting for proper feeding into the rollers. The machine will be controlled for variable speed through VFD digital electronic controller. The machine will have a front panel electric control panel housing the On/Off switch, speed regulator and inching control switch.
This particular rolling mill is designed for rolling of gold and silver strips of 5.0mm thickness down to 0.10mm thickness and 32mm maximum width with very high accuracy
We can supply you this type of precision sheet rolling mill in any roller size as per your exact requirement and can also supply reversible type coiler decoiler rolling mills.
This is Traditional type Rolling Mill in Double Gear Design for Heavy Work Mountd on Suitable Stand. This is available in six inch to triple Gear Design Rolling Mill for upto Twelve inch Roller Length.
Additional Information:
Payment Terms : T/T
Packaging Details : wooden case packing.
Delivery Time : four to eight weeks
Treadle guillotine shearing machineare indispensable in sheet metal industries as they lead amongst all on account of versatile design, rigid construction, rigorous tests for the capacities and appearance. Tredle shears are specially designed for rapid and continuous cutting of steel sheets of varied widths andtrimming them in unlimited lengths. | |
Features: *High tensile springs for quick return of treadle.*4 Cutting edged hardened & ground qualityblades.*Rigid and streamlined construction.*Spring loaded sheet holding device.*All steel fabricated construction body. | |
In every treadle shearing machine, the bed and top beam havefull adjustments for correct setting and easy removal of blades for accurate cutting and forregrinding. The spring loaded pressure pad holds theThe spring loaded pressure pad holds theperfect parallalism of cutting on either side.The adjustable front and back guages withrunning Tee slots facilitate adjustment ofvarious widths of the cuts and avoid any kind of twistings, turning of sheets while cutting.Square guide on the side of the tablefacilitates square cuts. The cutting edgeblades avoid frequent grinding & adjustmentand also very easy to grind to the rectangularshape. These blades can be used with slight change in cutting angle to ribs, plastics, card board, rubber, mica etc., without any sign ofsqueezing or crushing.
|
This is bench model hand operated shearing machine. This machine is designed to give high degree of stability and cutting process is CAM actuated ensuring precise burr free and accurate cutting. This machine makes cutting process very simple, safe and effortless. The machine uses C.I. bush bearings to ensure cutting accuracy.
These shearing machines are available in various sizes starting from 310mm upto 610mm width and maximum cutting capacity of 1.6mm in M.S. sheet.
Additional Information:
Payment Terms : T/T
Packaging Details : wooden case packing.
Delivery Time : three to four months.
Additional Information:
Payment Terms : T/T
Packaging Details : full wooden case packing.
Delivery Time : two weeks
This is extra heavy duty 2500 x 1.0 mm in mild steel capacity hand operated shearing machine. This is well constructed and ideal basic machine for various shear able materials like M.S., S.S., Aluminium, Mica, Copper, Plastic, Gaskets, Fiber etc.
These hand operated shearing machines are designed and constructed to provide high degree of stability ensuring precise burr free and accurate cutting. Cutting process is CAM actuated, very simple, safe and effortless. The machine is equipped with C.I. slides wherever required. Spring loaded hold down devices are also provided for firm clamping of sheets while cutting to ensure parallel out.
Both lower and upper blades of machines are proper alloy steel, properly hardened and ground, having four cutting edges.
These manual shearing machines are available in various sizes from 1000mm upto 2500mm width and having maximum cutting capacity in MS of upto 1.6mm.
Additional Information:
Payment Terms : T/T
Packaging Details : Full Wooden Case Packing.
Delivery Time : six weeks
MASTER4-hi and 2-hi Special Purpose Precision Rolling Mill with Coiler and De-coiler. This machine has rollers on roller bearing and housed inside heavy steel fabricated body. De-coiler is fitted with clutch type brake for tension setting for proper feeding into the rollers.
We request you to kindly contact us with your specific requirements.
This is Specially Designed 175mm Length X 95mm Diameter Roller Size wire Mill with 15mm size First Wire Groove Powered by a 3.0HP 440 Walt 3 Phase AC Electric Motor Fitted with Special Wire Drawing taper Drum for Wire Drawing and Supplied with die Holding Attachment. The Rolling Mill also has extended rollers for Fixig Side Rollers.
Additional Information:
Payment Terms : T/T
Packaging Details : wooden case packing.
Delivery Time : six to eight weeks
This is a power operated over crank type guillotine shearing machine similar in construction and features to the above described under crank shearing machine. The over crank design offers larger capacity machines and the range of available models starts from 1250 x 6 mm size to 3125 x 16 mm cutting capacity in mild steel with T.S. 42 kg/sq. cms.
The different shearing lengths size available is: 1250, 1500, 2000, 2500 and 3125 mm with the cutting thickness available in 6, 8, 10, 12 and 16mm.
This is a power operated over crank type guillotine shearing machine similar in construction and features to the above described under crank shearing machine. The over crank design offers larger capacity machines and the range of available models starts from 1250 x 6 mm size to 3125 x 16 mm cutting capacity in mild steel with T.S. 42 kg/sq. cms.
The different shearing lengths size available is: 1250, 1500, 2000, 2500 and 3125 mm with the cutting thickness available in 6, 8, 10, 12 and 16mm.
This is a power operated under crank type guillotine shearing machine featuring all steel body solid construction for accuracy and dependability. The crankshaft runs in gun metal bushes and fly wheel shaft runs in ball bearings for smooth trouble free operation. It is supplied complete with four edge HCHC shearing blades, electric motor, hand operated back gauge, front gauge, side gauge, belts, guards and shot lubricator. It is available in various sizes from 1250 x 4 mm to 3125 x 5 mm cutting capacity in mild steel with T.S. 42 kg/sq. cms. |
This is a power operated under crank type guillotine shearing machine featuring all steel body solid construction for accuracy and dependability. The crankshaft runs in gun metal bushes and fly wheel shaft runs in ball bearings for smooth trouble free operation. It is supplied complete with four edge HCHC shearing blades, electric motor, hand operated back gauge, front gauge, side gauge, belts, guards and shot lubricator.
It is available in various sizes from 1250 x 4 mm to 3125 x 5 mm cutting capacity in mild steel with T.S. 42 kg/sq. cms.
Additional Information:
Payment Terms : T/T
Packaging Details : full wooden case packing.
Delivery Time : four to eight weeks
The 8"Floor model Rolling Mill is a heavy duty single head gear box fitted 8"roll length sheet rolling mill complete with suitable 3 phase AC electric motor, automatic lubricating pump and emergency stop generally as shown above. It is also available with wire rollers instead of sheet rollers. We can also supply similar design mill with 6"roll length.
We also have specially designed 5"length x 5" diameter precision sheet rolling mill. Similarly we can also supply you 6"x6" size rolling mill as per your requirement.
Kindly note that we also have 8"extra heavy duty triple geared rolling mill. This is a very dependable sturdy and long lasting rolling mill. The rolling mill is equipped with heavy fly wheel on one side and motorization wheel on the other side. Due to heavy fly wheel giving momentum to the rolls, this rolling mill is also widely used for rolling of low purity hard silver and similar hard metal. This rolling mill is powered by a 5.0 HP 440 volts / 380 volts 3 phase AC electric motor fitted with suitable ON/OFF push button starter and a Reverse / Forward switch
The 8"Floor model Rolling Mill is a heavy duty single head gear box fitted 8"roll length sheet rolling mill complete with suitable 3 phase AC electric motor, automatic lubricating pump and emergency stop generally as shown above. It is also available with wire rollers instead of sheet rollers. We can also supply similar design mill with 6"roll length.
We also have specially designed 5"length x 5" diameter precision sheet rolling mill. Similarly we can also supply you 6"x6" size rolling mill as per your requirement.
Kindly note that we also have 8"extra heavy duty triple geared rolling mill. This is a very dependable sturdy and long lasting rolling mill. The rolling mill is equipped with heavy fly wheel on one side and motorization wheel on the other side. Due to heavy fly wheel giving momentum to the rolls, this rolling mill is also widely used for rolling of low purity hard silver and similar hard metal. This rolling mill is powered by a 5.0 HP 440 volts / 380 volts 3 phase AC electric motor fitted with suitable ON/OFF push button starter and a Reverse / Forward switch
MASTER4-hi and 2-hi Special Purpose Precision Rolling Mill with Coiler and De-coiler. This machine has rollers on roller bearing and housed inside heavy steel fabricated body. De-coiler is fitted with clutch type brake for tension setting for proper feeding into the rollers.
We request you to kindly contact us with your specific requirements
This is a 5 inch roll length combined sheet & wire rolling mill. The rolls are made of high chromium special steel, hardened and ground finished. They are housed in extremely strong frame to overcome all the vibrations and stresses developed during working. The rolls are running in special anti friction phosphor bronze alloy. The gears are made of case hardened steel and immersed in oil for noiseless and smooth operation. Various components are standardised and are interchangeable. This assures easy maintenance.
|
This is a 5" roll length combined sheet and wire rolling mill with provision to mount side grooving rolls. The rollers are housed in strong solid steel housing. The machine is fitted with oil gear box system and supplied with heavy duty 1.0 HP 220 volts single phase AC electric motor and R/F switch for both forward and reverse operation. |
This is a 5" roll length combined sheet and wire rolling mill with provision to mount side grooving rolls. The rollers are housed in strong solid steel housing. The machine is fitted with oil gear box system and supplied with heavy duty 1.0 HP 220 volts single phase AC electric motor and R/F switch for both forward and reverse operation. |
This is a 6" x 3" roll size bench rolling mill with heavy duty roll housing and bigger gears. It is provided withEXTRAgears to provideHIGHER ROLL OPENINGi.e. it allows thicker plates to be rolled due to higher roll opening as a result of extra gears. Also this model is provided withTWObig size roll driving gears instead of onlyONEas in other Bench model rolling mills. |
This is a 6" x 3" roll size bench rolling mill with heavy duty roll housing and bigger gears. It is provided withEXTRAgears to provideHIGHER ROLL OPENINGi.e. it allows thicker plates to be rolled due to higher roll opening as a result of extra gears. Also this model is provided withTWObig size roll driving gears instead of onlyONEas in other Bench model rolling mills.
MASTERExtra heavy duty single head gear box fitted precision sheet rolling mill complete with suitable HP 960 rpm AC electric motor, automatic Lubricatingpump andemergency stopgenerally as shown above. Approximate dimensions /specifications are as under:
MODEL | GD 250S | GD 300S |
Rolling Mill Details | 10" x 5" | 12" x 6" |
Rolls | 10" x 5" | 12" x 6" |
Rolls Length | 10 inch | 12 inch |
Rolls Diameter | 5 inch | 6 inch |
RPM of Rolls | 20 RPM | 18 RPM |
Electric motor |
7.5 HP 440 V/ 3 phase/ 50 Hz |
10 HP 440 V/ 3 phase/ 50 Hz |
Rolling Mill Dimensions Inch CMs |
L x B x H 42" x 35" x 65" 107cm x 58cmx 165 cm |
L x B x H 56" x 29" x 69" 140cm x74cmx 175 cm |
Net weight | 850 Kgs | 1250 Kgs |
Wooden case Dimensions |
50" x 29" x 74" 127cm x 74cm x 188 cm |
65" x 36" x 78" 165cm x 92 cm x 198 cm |
Gross weight | 1125 Kgs | 1650 Kgs |
MASTERExtra heavy duty single head gear box fitted precision sheet rolling mill complete with suitable HP 960 rpm AC electric motor, automatic Lubricatingpump andemergency stopgenerally as shown above. Approximate dimensions /specifications are as under:
MODEL | GD 250S | GD 300S |
Rolling Mill Details | 10" x 5" | 12" x 6" |
Rolls | 10" x 5" | 12" x 6" |
Rolls Length | 10 inch | 12 inch |
Rolls Diameter | 5 inch | 6 inch |
RPM of Rolls | 20 RPM | 18 RPM |
Electric motor |
7.5 HP 440 V/ 3 phase/ 50 Hz |
10 HP 440 V/ 3 phase/ 50 Hz |
Rolling Mill Dimensions Inch CMs |
L x B x H 42" x 35" x 65" 107cm x 58cmx 165 cm |
L x B x H 56" x 29" x 69" 140cm x74cmx 175 cm |
Net weight | 850 Kgs | 1250 Kgs |
Wooden case Dimensions |
50" x 29" x 74" 127cm x 74cm x 188 cm |
65" x 36" x 78" 165cm x 92 cm x 198 cm |
Gross weight | 1125 Kgs | 1650 Kgs |
This is a lightweight portable mill, which can also be fitted with bangle design roll. It has been redesigned to facilitate working by removing the front support bars in front of rolls and taking the same underneath in the base. |
This is a lightweight portable mill, which can also be fitted with bangle design roll. It has been redesigned to facilitate working by removing the front support bars in front of rolls and taking the same underneath in the base. |
The GD-160 is a 6 inch roll length Combined Sheet & Wire rolling mill similar to model GD 125. It is designed for continuous working with automatic lubrication as standard. Solid heavy construction is guaranteed to give years of trouble free service.
Features / Accessories supplied with the machine:a. Roll size of 6" x 3" made from HCHC Special Steel.b. 3.0 HP 440 or 380 Volts, 3 phase, 50 or 60 Hz. AC electric motor, complete with Control panel box.c. Automatic Lubrication system with flow control arrangement.
Following optional features are available at additional cost.1. TWO SPEED 3.0 HP / 5.0 HP 960 rpm / 1440 rpm AC electric motor with necessary Control Panel for the same including two forward and two reverse speed control switch.2. Foot operated Emergency Stop System.
Similar 8" x 4" roll size machine is also available inmodel GD-200with TWO SPEED 5.0 / 7.5 HP motor, Emergency Stop, automatic lubrication system and side grooving rolls is also available.
The GD-160 is a 6 inch roll length Combined Sheet & Wire rolling mill similar to model GD 125. It is designed for continuous working with automatic lubrication as standard. Solid heavy construction is guaranteed to give years of trouble free service.
Features / Accessories supplied with the machine:a. Roll size of 6" x 3" made from HCHC Special Steel.b. 3.0 HP 440 or 380 Volts, 3 phase, 50 or 60 Hz. AC electric motor, complete with Control panel box.c. Automatic Lubrication system with flow control arrangement.
Following optional features are available at additional cost.1. TWO SPEED 3.0 HP / 5.0 HP 960 rpm / 1440 rpm AC electric motor with necessary Control Panel for the same including two forward and two reverse speed control switch.2. Foot operated Emergency Stop System.
Similar 8" x 4" roll size machine is also available inmodel GD-200with TWO SPEED 5.0 / 7.5 HP motor, Emergency Stop, automatic lubrication system and side grooving rolls is also available.
4Hi Cold Rolling mill with coiler and de-coiler having excellent quality hardened and ground HCHCr Steel rolls with hardness of 62-63 HRC fitted on Roller bearings and housed inside heavy MS Plate fabricated body with rigid construction.
The machine is having three gear type roll lifting arrangement with fine battler thread 1.5 pitch Screw for fine adjustment and precise rolling.
The Rolls are driven through suitable pinion gearbox with universal joints and a worm type gear box for excellent and smooth working.
Machine is fitted with fixed Coiler & De coiler such that your material will be fed through and wound on interchangeable Bobbins mounted on Spools fitted on both sides. Spools will be such as to facilitate easy removal and fixing of Bobbins for multiple pass rolling. The Coiler will have its drive through the main motor and the De coiler will be fitted with Clutch type brake for tension setting for proper feeding into the rollers.
The machine will be driven by suitable HP 440 volts three phase 1440 rpm AC electric motor and will be controlled for variable Speed through VFD digital electronic controller.
The machine will have a front panel electric control panel housing the On/Off Switch, Speed Regulator, digital display, Inching Control switch and EMERGENCY stop system for safety.
The machine will have Spools on both sides with Bobbins and additional two numbers extra Bobbins will be supplied to speed up production.
This is a light duty motorized mechanical undercrank guillotine shearing machinesuitable for production work. It is a steel fabricated machine having acapacity to cut 3000 mm length x 1.0 mm thickness mild steel sheets.
The machine is equipped with:
This bench model rolling mill is provided with lever system so that either sheet rolls or the wire rolls can be used at any one time with provision to fit side rolls. This machine is also available with a specially designed steel fabricated stand with 1.0 HP 220 volts single phase Cast Iron body TEFC AC electric motor, R/F switch and V belt. The R/F switch is provided complete with wiring to allow both reverse and forward operation.
This bench model rolling mill is provided with lever system so that either sheet rolls or the wire rolls can be used at any one time with provision to fit side rolls. This machine is also available with a specially designed steel fabricated stand with 1.0 HP 220 volts single phase Cast Iron body TEFC AC electric motor, R/F switch and V belt. The R/F switch is provided complete with wiring to allow both reverse and forward operation. |
This is a bench rolling mill with roll size of 5" x 2.1/2" and is available in three models. It is available with either the sheet rolls, or wire rolls or can be supplied with combined sheet and wire grooves in one single roll. Similar rolling mill is also available with roll size of 4" x 2.1/4" and 6" x 3" in the three different versions as for the 5" size rolling mill. Specially designed 6" x 3" roll size bench rolling mill is also available with higher roll opening for thicker sheet work |
This Rolling machine isthe most popular model amongGoldsmiths and Jewellers.It is combined sheet andwire rolling mill having 5" length of rolls with provision to fix extension rollers at the end of wire rollers.
The rolls are made of high carbon high chromium special steel, hardened and ground finished. They are housed in extremely strong frame to overcome all the vibrations and stresses developed during working. The rolls are running in special anti friction phosphor bronze alloy bushing. The gears are made of case hardened steel and immersed in oil bath for noiseless and smooth operation. Various components are standardised and are interchangeable. This assures easy maintenance.
This MASTER rolling machine is powered by a 1.5 HP strong TEFC type AC electric motor running on 220 volts 50 cyclesSingle Phase supply. It is also offered with a 2.0 HP 440 volts Three Phase motor for larger factory with continuous use.
The machine is supplied with side rollers with standard half round grooves. Other grooves and designs are possible against order.
We also offer automatic lubrication and foot operated Emergency STOP system as extra optional features. Machines with different type of electric voltage and frequency for export are supplied against order.
