RF Cables & Assemblies RF Cables and Assemblies (upto 12GHz) Lambdoid Wireless Communications offer a full range of standard cable assemblies for use in the Commercial, Industrial and Defence segment. Various fast moving standard cables and connectors are stocked in-house where the assemblies are produced using the latest technology and highly skilled labour. We take up custom assembly requirements and RoHS shall be maintained, if need be. Applications: Telecommunication Industry Defence and Military Applications Medical Industry Broadcast and Entertainment Industry Notes: Male and Female of most connectors available. Reverse Polarity connectors available. Straight and Right Angle connectors available. Technical Specifications

• Cable Length10cm or as required
• Frequency (MHz)2400-2500 MHz
• Gain3 dBi
• Impedance (Ω)50
• VSWR< 2.0
• PolarizationLiner
• Power Handling (w)10
• CableMini Coax 1.13mm
• ConnectorMHFI (U. FL) or as required

Chip Antennas LWC-2400-CHIP-03: 2400 MHz, 3dBi   Model: LWC-2400-CHIP-03 Salient Features: Compact Size Low Cost Available with 1.13 cable or as specified. Available with open end or with connector of your choice. Applications: Bluetooth Wi-Fi Zigbee 2.4GHz ISM Technical Specifications

• Connector2 x N(F)
• Frequency (MHz)2400 – 2500 MHz
• Gain2 x 15 dBi
• Impedance (Ω)50
• VSWR< 1.8
• PolarizationLinear (V & H)
• Power Handling (W)100
• HPBWH: 140 ; V:140
• FBR (dB)>27
• Port to Port Isolation (dB)> 25

Notes: For cables RG-174, RG-316, LMR-100 For cables RG-58, LMR-195 Crimp Straight and Right Angle connectors PCB Mount Straight and Right Angle connectors PCB Jack MCX (F) Straight PCB Jack, 50 ohm MCX (F) Right Angle PCB Jack, 50 ohm Crimp Plug Straight MCX (M) Straight Crimp Plug for RG-174, RG-316, LMR-100, 50 ohm MCX (M) Straight Crimp Plug for RG-58, LMR-195, 50 ohm Crimp Plug Right Angle MCX (M) Right Angle Crimp Plug for RG-174, RG-316, LMR-100, 50 ohm MCX (M) Right Angle Crimp Plug for RG-58, LMR-195, 50 ohm Crimp Jack Straight MCX (F) Straight Crimp Jack for RG-174, RG-316, LMR-100, 50 ohm MCX (F) Straight Crimp Jack for RG-58, LMR-195, 50 ohm Crimp Jack Right Angle MCX (F) Right Angle Crimp Jack for RG-174, RG-316, LMR-100, 50 ohm MCX (F) Right Angle Crimp Jack for RG-58, LMR-195, 50 ohm

• Frequency1575 +/- 5 MHz
• Gain> 30 dBi (with LNA)
• Impedance50 Ω
• VSWR< 1.5
• PolarizationRHCP
• Power Handling50 watts
• CableRG174 or as required
• Cable Length3m or as required
• ConnectorSMA(M) or as required
