Keshkamat and company

Prabhadevi, Mumbai, Maharashtra

• Length529 mm
• Rear Flange Diameter173 mm
• Front Flange Diameter173 mm
• Height192 mm
• Base Plate180 mm.x 182 mm
• Weight7 Kg

The various standard racks like 3U, 4U, 6U, 9U, 12, 15U etc; which are manufactured have following Salient Features. Material of Fabrication : M.S. Poweder coated racks as per the sizes mentioned above. Power distribution unit (PDU), Mounting Tray, Cooling Fan & Cable Manager are supplied as per standard requirement of respective racks. Adequate Ventilation is provided to take care of power dissipation of equipments installed inside the racks by using fans of adequate capacity. Toughened Glass Duty Polished is utilised for clear monitoring inside the rack. Wiring material, mains cord and sockets, switches used are of standard rating and adequate capacity.   We also manufacture custom built racks as per the requirement.

• Supply Voltage240 V. AC 50 Hz.
• Connectionsthrough 6 core cable
• ConstructionMain Body – Aluminium Casting Cover - M.S. Sheet Fabricated Platform- Cast Iron & Cast Aluminum  (In two Parts)  Or in One part in Alum casting depending Upon Enclosure Finish - Dimond White/ Siemens Grey -Matt Finish
• Power Consumption250 Watts Max. (Total when Panning & Tilting together)
• ModelEM-70
• Load capacity25 Kg. Balanced
• Pan Angle/ 350 Degrees
• Overall Dimensions240 MM(Height) X 235 MM(Width) X 295 MM (Depth) (Overall Dimensions likely to change by 10mm + OR - to improve design)
• Tilt Angle+ - /90 Degrees
• MountingWall Mount on the bracket  OR Pedestal  Mount
• Back Lash/6 Degrees
• ApplicationsSuitable for Mounting Water Cooling Jacket, Weatherproof enclosure, in CCTV System for Housing Camera & Lens of any type
• SpeedPan /6  Degrees per Sec. Tilt  /6  Degrees per Sec.
• Motor SpecificationsSynchronous Motors Two nos. 240V. 50Hz. Torque, Panning- 10Kg.CM, Tilting.  - 20 Kg. CM.  Motors Totally Enclosed, Phase Splitting by RC Network. Operating Temp.  0 - 50 Deg.
• TorquePan - 300 Kg. CM  at 1 RPM Tilt -  600 Kg. CM  at 1 RPM
• Weather ProofIP: 65 as per IS: 13947 –Part 1 (1993)
• Over RunNone

WCJ03 WATER/AIR COOLED HOUSING > Products > WeatherProof CCTV equipment for Steel and Other Engineering Unit >  WCJ03 Water/Air Cooled Housing     Material of Construction : SS sheets of 10, 14 & 19 SWG in 304 grade Nozzles, Pipes, in SS 304 grade, Rubber Hose for Water & Air circulation suitable for Water and Air Pressure up to 4.5Kg/cm2. Rubber Hoses in ½” &¼” to withstand Temperature up to 120º C (See attached table below) Air Purging System Nozzle is provided. Toughened glass 150 MM Dia. X 10 mm thick Gasket on front & rear flanges between the BODY and the Covers. Degree of Protection IP: 65 as per IS: 13947 (part-I) 1993 Cable Entry from rear flange Cover is provided. Overall Dimensions: Front 220 mm X Rear 220mm X Over all Length 550 mm Inner shell Ø150-mm, Mid Shell Ø 190–mm, Height from the Ground level 250mm We are offering following with the Air/Water cooled Housing WATER/AIR Cooled Housing in SS 304 Grade for ambient temperature up to 120Deg. Centigrade IP: 65 protection. Air purging arrangement, with maximum pressure of 2.5KG/CM2. Provided with the WATER/AIR cooled housing are Inlet, Outlet Hoses and Air Hose attached to Air Purging Nozzle. Digital Temperature Indicator along with Temperature Sensor. This will Monitor Temperature inside the Cooled Housing. This is set at 40 Deg. Cent.

• Finish :Off white OR Dimond white
• Solonoid Valve:For sprinkling water over the front glass to clean it before wiping.  Supply Voltage 240V. 50 Hz. Connections  Input/Output connection to the valve- ½” BSP
• Main Enclosure : Main enclosure , Front Cover, Rear Cover with Platform, Wiper Enclosure in Aluminium Casting, Canopy in Aluminium Sheet Toughened Glass 8 mm Thick 130 mm Ø
• Cable Entries :2-nos of ½” or ¾” NPT / ½” or ¾” ET
• Heater Blower Kit :Heater 10 Watts, Blower Fan3”, Thermostat for  adjusting Temperature, installed on the platform of the main enclosure, Voltage 240V. 50Hz.
• Wiper Enclosure :Enclosure, front & rear covers in Aluminium Casting Wiper Motor 240V. AC 50Hz. With Gears & shaft.
• Cable Entries : 1 cable entry ½” or ¾” NPT /ET trough rear side of the enclosure.
• Overall Dimensions :588 mm (Length) X 350 mm (Height) X 248mm (Width)  mounted with  Sun shroud/canopy of  788 mm length
• Weight :12 Kg.

• Weight10 Kg. (Approximately
• As to Waterproof protectionIS/IEC: 60529 2001 IP: 65
• Material of Construction of the Junction BoxAluminium Casting
• OVERALL DIMENSIONS
• Height450 mm
• Width450 MM
• Depth235MM
• Opening400MM x 400MM
